BlueprintShell 0.1.2

BlueprintShell

BlueprintShell is an embeddable editor shell built on BlazorBlueprint. Add it to any .NET application and get a fully themed, dockable editor UI - panels, toolbars, dark-mode, hot-reload - served on a configurable port from your own process.

Packages are published to GitHub Packages.

Installation

Add the GitHub Packages feed to your NuGet.config (or ~/.nuget/NuGet/NuGet.Config):

<packageSources>
  <add key="EggyStudio" value="https://nuget.pkg.github.com/EggyStudio/index.json" />
</packageSources>

Then add the package:

dotnet add package BlueprintShell

Usage

Standalone mode - dedicated port

Spin up a separate Kestrel server inside your existing process. The shell runs independently and doesn't interfere with your app's own HTTP stack.

using BlueprintShell;

// Start the shell server (non-blocking).
var shell = await EditorServerHost.StartAsync(new BlueprintShellOptions
{
    Url      = "http://localhost:5100",
    AppTitle = "My Engine Editor",
});

// ... run your loop ...

// Shut down cleanly when done.
await shell.StopAsync();

Open http://localhost:5100 in a browser to see the shell.

Embedded mode - same ASP.NET Core app

If your host is already an ASP.NET Core app, register the shell services and map its hub into your existing pipeline:

// Program.cs
builder.Services.AddBlueprintShell(o =>
{
    o.AppTitle = "My Editor";
});

// After builder.Build():
app.MapBlueprintShell();   // maps /shell-hub SignalR endpoint

Then add the shell's App, Routes, and ShellLayout into your Razor routing as needed.

Configuration - BlueprintShellOptions

Writing panels

Decorate any Blazor component with [EditorPanel] to register it as a dockable panel. The attribute is discovered at startup by StaticShellLoader via reflection.

@* MyPanel.razor *@
@attribute [EditorPanel("my-panel", "My Panel", DockZone.Right,
    Icon    = "settings",
    Route   = "/my-panel",
    Visible = true)]

@inject ShellRegistry Registry

<div class="p-4">
    <h3 class="text-sm font-semibold">Hello from My Panel</h3>
</div>

Writing shell builders

For code-driven layout (no Razor), implement IEditorShellBuilder and decorate with [EditorShell]:

using BlueprintShell.Shell;

[EditorShell]
public class MyShell : IEditorShellBuilder
{
    public int Order => 0;   // lower runs first

    public void Build(IShellBuilder shell)
    {
        shell.Panel("toolbar", "Toolbar", DockZone.Top, p => p
            .Content(c => c
                .Row(null, row => row
                    .Button(null, "Save",  onClick: OnSave,  icon: "save")
                    .Button(null, "Build", onClick: OnBuild, icon: "hammer", variant: "secondary")
                    .Spacer()
                    .DarkModeToggle())));
    }

    private static void OnSave()  { /* ... */ }
    private static void OnBuild() { /* ... */ }
}

Multiple builders coexist: Order controls execution order; higher-precedence sources (dynamic hot-reload) override lower ones on panel-id collisions.

Multiple shell sources

ShellRegistry supports multiple named sources that are merged at runtime. This lets an engine contribute a static source at startup and a hot-reload compiler contribute a dynamic source later:

var registry = new ShellRegistry();

// Static source - built-in panels:
registry.RegisterSource("static", new ShellSource
{
    Builders   = new[] { new MyShell() },
    Precedence = 0,
});

// Dynamic source - runtime-compiled panels override static ones on id collision:
registry.RegisterSource("dynamic", new ShellSource
{
    PanelComponents = discoveredPanels,
    Precedence      = 100,
});

var shell = await EditorServerHost.StartAsync(registry: registry);

CSS / theming

The shell uses BlazorBlueprint's OKLCH-based CSS variable system. Override variables in your own stylesheet or supply raw CSS snippets via the builder API:

// Custom CSS injected into every page:
registry.RegisterSource("my-theme", new ShellSource
{
    CustomCss = new[]
    {
        ":root { --primary: oklch(0.55 0.2 260); }",
    },
});

License

MPL 2.0
