FlowT 1.3.0

FlowT - High-Performance Orchestration Library for .NET

FlowT is a high-performance orchestration library for .NET that implements the Chain of Responsibility pattern with a fluent API. Build maintainable, testable, and ultra-fast pipelines with specifications, policies, and handlers.

📚 Full Documentation: https://github.com/vlasta81/FlowT

📦 Package Information

✨ Key Features

🚀 Performance

• ⚡ 2.7× faster than DispatchR - The fastest .NET orchestration library
• ⚡ 9× faster than MediatR - Singleton architecture with cached pipelines
• 💾 84% less memory than MediatR - Zero-allocation fast paths
• 🔥 Thread-safe - Lock-free operations with compile-time safety

🎯 Developer Experience

• 🧩 Modular Architecture - IFlowModule for clean feature organization
• 🔄 Chain of Responsibility - Composable pipeline with specs, policies, handlers
• 🎨 Fluent API - Intuitive pipeline configuration
• 📝 Automatic Context - No manual FlowContext creation needed
• 🛡️ 27 Roslyn Analyzers - Compile-time safety for threading & DI

💡 Advanced Features

• 🔍 FlowInterrupt - Type-safe error handling without exceptions
• 🧩 FlowSpecification<TRequest> - Optional abstract base class: Continue(), Fail(), Stop() helpers (zero-allocation cached path)
• 🔌 Plugin System - PerFlow services with 8.7× warm-path speedup, 10 built-in plugins
• 📊 Named Keys - Store multiple values of same type
• 🎭 Scoped Services - Safe ctx.Service<T>() in singleton handlers
• 🏷️ Feature Flags - FeatureFlagPlugin wraps IVariantFeatureManager with per-flow cache
• 📝 Audit Trail - AuditPlugin accumulates structured events per flow execution
• ⏱️ Performance Metrics - PerformancePlugin measures named code sections with Stopwatch
• 🏢 Multi-tenancy - TenantPlugin resolves tenant from claim → header → route → default
• 🔑 Idempotency - IdempotencyPlugin reads X-Idempotency-Key header once per flow
• 🔭 DI Scope Control - FlowScopePlugin for explicit scopes in background/non-HTTP flows

🚀 Quick Start

Installation

dotnet add package FlowT

Basic Example

// 1. Define request/response
public record CreateUserRequest(string Email, string Name);
public record CreateUserResponse(Guid Id, string Email);

// 2. Create handler
public class CreateUserHandler : IFlowHandler<CreateUserRequest, CreateUserResponse>
{
    public async ValueTask<CreateUserResponse> HandleAsync(
        CreateUserRequest request, FlowContext context)
    {
        var db = context.Service<AppDbContext>();
        var user = new User { Email = request.Email, Name = request.Name };
        db.Users.Add(user);
        await db.SaveChangesAsync(context.CancellationToken);
        return new CreateUserResponse(user.Id, user.Email);
    }
}

// 3. Define flow with pipeline
[FlowDefinition]
public class CreateUserFlow : FlowDefinition<CreateUserRequest, CreateUserResponse>
{
    protected override void Configure(IFlowBuilder<CreateUserRequest, CreateUserResponse> flow)
    {
        flow
            .Check<ValidateEmailSpecification>()
            .Use<LoggingPolicy>()
            .OnInterrupt(interrupt =>
                new CreateUserResponse(Guid.Empty, interrupt.Message))
            .Handle<CreateUserHandler>();
    }
}

// 4. Register module
[FlowModule]
public class UserModule : IFlowModule
{
    public void Register(IServiceCollection services)
    {
        services.AddFlow<CreateUserFlow, CreateUserRequest, CreateUserResponse>();
    }

    public void MapEndpoints(IEndpointRouteBuilder app)
    {
        app.MapPost("/api/users", async (
            CreateUserRequest request,
            CreateUserFlow flow,
            HttpContext httpContext) =>
        {
            return await flow.ExecuteAsync(request, httpContext);
        });
    }
}

// 5. In Program.cs
builder.Services.AddFlowModules(typeof(Program).Assembly);
app.MapFlowModules();

📊 Performance

📊 Detailed Benchmarks: https://github.com/vlasta81/FlowT/tree/main/benchmarks/FlowT.Benchmarks

📚 Core Concepts

Modules (IFlowModule)

Organize features into cohesive modules with [FlowModule] attribute for auto-discovery.

Flows (FlowDefinition<TRequest, TResponse>)

Define reusable orchestration pipelines with [FlowDefinition] attribute.

Context (FlowContext)

Per-request execution context with scoped service resolution, storage, and events.

Specifications (IFlowSpecification<TRequest> / FlowSpecification<TRequest>)

Reusable validation and business rules that can interrupt flow with FlowInterrupt. Inherit from FlowSpecification<TRequest> for Continue(), Fail(), and Stop() helpers.

Policies (FlowPolicy<TRequest, TResponse>)

Cross-cutting concerns as reusable middleware (logging, caching, transactions).

Plugins (Plugin<T>())

PerFlow services shared across all pipeline stages with automatic caching. Register with services.AddFlowPlugin<IMyPlugin, MyPlugin>(), resolve with context.Plugin<IMyPlugin>().

Built-in Plugins

Example — FeatureFlagPlugin + AuditPlugin

// appsettings.json
{
  "FeatureManagement": {
    "NewCheckout": true
  }
}

// Program.cs
builder.Services.AddFeatureManagement();
builder.Services.AddFlowPlugin<IFeatureFlagPlugin, FeatureFlagPlugin>();
builder.Services.AddFlowPlugin<IAuditPlugin, AuditPlugin>();

// Handler
public async ValueTask<Response> HandleAsync(Request req, FlowContext ctx)
{
    var ff = ctx.Plugin<IFeatureFlagPlugin>();
    if (!await ff.IsEnabledAsync("NewCheckout", ctx.CancellationToken))
        return new Response { Skipped = true };

    var audit = ctx.Plugin<IAuditPlugin>();
    audit.Record("CheckoutStarted", new { req.UserId });

    // ... business logic ...

    audit.Record("CheckoutCompleted", new { req.UserId, OrderId = order.Id });
    return new Response { OrderId = order.Id };
}

📖 Complete Guide: https://github.com/vlasta81/FlowT/blob/main/README.md#-core-concepts

🛡️ Compile-Time Safety

FlowT includes 27 Roslyn analyzers that catch issues at compile-time:

🔴 Errors (Build fails - must fix!)

• FlowT002: Non-thread-safe collections (List, Dictionary, etc.)
• FlowT003: Captive scoped dependencies (DbContext in constructor)
• FlowT004: Static mutable state
• FlowT006: FlowContext stored in field
• FlowT007: Request/Response objects in fields
• FlowT010: Thread.Sleep() in async methods
• FlowT011: Missing .Handle<T>() in FlowDefinition.Configure()
• FlowT012: IServiceProvider stored in field
• FlowT013: CancellationTokenSource stored in field
• FlowT015: Mutable public/internal properties
• FlowT018: Lazy<T> without thread-safety mode
• FlowT019: State leak types (StringBuilder, Stream, Stopwatch, arrays)
• FlowT021: FlowPlugin stored in singleton field
• FlowT022: Multiple .Handle<T>() calls in Configure()
• FlowT026: Thread.Sleep() in synchronous flow methods

⚠️ Warnings

• FlowT001: Mutable instance fields
• FlowT005: Async void methods
• FlowT008: Lock on this or typeof(T)
• FlowT010: Synchronous blocking (.Result, .Wait())
• FlowT016: Task/ValueTask storage
• FlowT017: Manual Thread creation
• FlowT020: ConfigureAwait(false) loses HttpContext/FlowContext
• FlowT023: new HttpClient() in flow component (socket exhaustion)
• FlowT024: Synchronous file I/O in async flow method

ℹ️ Info (Suggestions)

• FlowT009: Missing CancellationToken propagation
• FlowT014: Empty catch blocks
• FlowT025: Direct IServiceProvider access (prefer context.Service<T>())

📖 All Analyzer Rules: https://github.com/vlasta81/FlowT/blob/main/src/FlowT.Analyzers/README.md

Example:

// ❌ FlowT003: Build fails!
public class BadHandler : IFlowHandler<Request, Response>
{
    private readonly AppDbContext _db; // Captive dependency!
    public BadHandler(AppDbContext db) { _db = db; }
}

// ✅ Correct pattern
public class GoodHandler : IFlowHandler<Request, Response>
{
    public async ValueTask<Response> HandleAsync(Request req, FlowContext ctx)
    {
        var db = ctx.Service<AppDbContext>(); // Safe!
        return await db.ProcessAsync(req);
    }
}

🔄 Migration Guides

UserIdentityPlugin Removal (v1.2.0)

The UserIdentityPlugin and IUserIdentityPlugin interface have been removed. User identity functionality is now provided by built-in methods on FlowContext:

📖 Migration Guide: https://github.com/vlasta81/FlowT/blob/main/docs/MIGRATION_UserIdentityPlugin.md

📖 Documentation

🧪 Testing

• 277+ unit tests with full coverage
• xUnit test framework
• Thread-safety and concurrency tests
• Analyzer verification tests

📖 Test Suite: https://github.com/vlasta81/FlowT/tree/main/tests/FlowT.Tests

🤝 Contributing

Found a bug or have a feature request? Please open an issue: https://github.com/vlasta81/FlowT/issues

Deprecation Policy

For future breaking changes, FlowT follows a deprecation-first approach:

1. Features are marked [Obsolete] with migration guidance in a minor version
2. Deprecated features are removed in the next major version
3. Migration guides are provided in docs/MIGRATION_*.md

📄 License

MIT License - see LICENSE file for details.

Made with ❤️ by vlasta81
