Icod.Widgets 1.5.0

Icod.Widgets

Icod.Widgets is a managed, cross-platform .NET terminal UI control library for applications and games. It provides reusable forms, lists, menus, dialogs, filesystem pickers, and game UI controls above Icod.DCurses, without taking ownership of the application's event loop or business logic.

Status

Widgets provides reusable controls and editing behavior; applications own terminal sessions, document lifetime, file writes, and search. See the changelog for versions and release history.

Support the Project

Icod.Widgets and its ecosystem packages (Icod.TermInfo, Icod.Terminal, and Icod.DCurses) are built and maintained by a solo developer. If these packages save you or your team time, please consider supporting their continued development and maintenance.

Architecture

The production dependency direction is Icod.Widgets → Icod.DCurses → Icod.Terminal → Icod.TermInfo. Widgets has one direct runtime package dependency: Icod.DCurses.

Quick Start

Install the latest published package:

dotnet add package Icod.Widgets

For reproducible restores, add --version with a published package version.

For a runnable first step, clone the repository and launch the gallery from its root in an interactive terminal with the .NET 10 SDK:

git clone https://github.com/uniblab/Icod.Widgets.git
cd Icod.Widgets
dotnet run --project samples/Icod.Widgets.Gallery.Sample -c Release -f net10.0

Use Ctrl+N/Ctrl+P to visit its seven pages and Ctrl+Q to exit. Ctrl+T cycles capability-aware dark and light palettes and terminal-default styling. Try the forms, selected lists, framed popups, dialog captions, and game status under each palette. On the workspace page, F6 and Shift+F6 move among the tabs, editor, and actionable status.

To exercise multiline editing, run the editor sample:

dotnet run --project samples/Icod.Widgets.Editor.Sample -c Release -f net10.0

Use Ctrl+O to load a file into memory, F7/F8 to change future newline and indentation edits, F6 to move focus, and Ctrl+Q to exit. With no selection, Copy/Cut use the current logical line; a locally retained linewise paste inserts at a line start. The sample never writes files.

To try multi-document controls, run the in-memory workspace sample:

dotnet run --project samples/Icod.Widgets.Workspace.Sample -c Release -f net10.0

It starts with three documents and demonstrates stable-key tabs, close decisions, Find/Find Next, Save As inspection, and actionable status. Use F6 to move between the editor, tabs, and status fields. It never writes files.

Applications create a WidgetHost, attach a widget tree, and supply input and time. This is an excerpt from an application loop, not a standalone program: session is an open CursesSession, inputEvent is the current normalized input event, and elapsed is a monotonic TimeSpan such as Stopwatch.Elapsed. Host creation and attachment happen once; input processing and refresh repeat.

using Icod.Widgets;

// Once, after opening the application's DCurses session:
using WidgetHost host = new(session, WidgetTheme.Default);
WidgetButton save = new("save", "Save", "file.save");
host.Attach(save);
host.Arrange(session.Screen.Bounds);

// Within the application's input/render loop:
WidgetDispatchResult result = host.Process(inputEvent, elapsed);
foreach (WidgetAction action in result.Actions) {
    // Execute application commands or update application state.
}
host.Render();
await session.RefreshAsync();

See the shared sample loop for complete session setup, input, resizing, rendering, and cleanup.

Feature Inventory

• Labels, buttons, single-line text input, checkboxes, radio groups, borders, scroll indicators, and stack/grid layout.
• Exact mixed-EOL text documents, immutable snapshots, checkpoint identity, bounded undo/redo, independent view state, and Unicode-aware multiline editing.
• Selection, indentation, insert/overwrite mode, read-only operation, captured pointer drag/autoscroll, both-axis scrollbars, explicit bounded clipboard requests, and focused terminal-caret intent.
• Stable-key document tabs, replaceable caller-owned active content, dynamic menu presentation, focused edit commands, and actionable status fields.
• Single- and multi-select lists, keyboard search, and framed drop-down popups.
• Menu bars, framed popup menus, submenus, separators, disabled/checkable items, scoped mnemonics, and independent command shortcuts.
• Captioned, framed OK, Yes/No, OK/Cancel, and Previous/Next/Cancel dialogs with explicit results and modal focus restoration.
• Composable forms with Save/Don't Save/Cancel decisions, separate save-target inspection, and typed Find/Replace/Go To Line requests.
• Provider-backed folder selection and single/multiple existing-file selection.
• Inventory/action lists, bounded message history, status bars, help overlays, and text/number prompts.

Themes and terminal colors

Widgets provides full CursesStyle roles for widget parts: each style carries foreground, background and attributes. Use WidgetPalette.Create(session.PresentationCapabilities) after opening a DCurses session, or supply your own WidgetTheme with immutable Parts overrides. Change a live host's theme with host.SetTheme(nextTheme) and render again. Scoped widget.Styles overrides take precedence on that widget's subtree; the six original theme roles remain supported.

WidgetTheme dark = WidgetPalette.Create(session.PresentationCapabilities);
WidgetTheme light = WidgetPalette.Create(session.PresentationCapabilities, WidgetPaletteVariant.Light);
using WidgetHost host = new(session, dark);
// Attach, arrange and run the application loop as in Quick Start.
host.SetTheme(light);
host.Render();

To customize a part, reuse a style from the capability-aware palette. For example, this gives one button the palette's selected style when focused; other buttons retain the theme's ButtonFocused role:

WidgetButton action = new("action", "Apply", "document.apply") {
    Styles = WidgetStyles.Empty.With(WidgetStyleRole.ButtonFocused, host.Theme.Selected)
};
host.Attach(action); // Arrange and render in the application loop.

Use host.Theme with { Parts = host.Theme.Parts.With(WidgetStyleRole.DialogBorder, host.Theme.Focused) } with host.SetTheme to override a role across the theme. Scoped styles resolve before theme parts; switching themes does not clear a widget's scoped overrides. Reapply palette-derived overrides when changing palettes if they should follow the new palette.

Color requests follow DCurses' public capability observations. Unsupported foreground and background axes revert independently to terminal defaults; RGB and indexed colors are requested only when advertised. A terminal that advertises neither color nor attributes may display identical cell styles; text markers, borders, labels and focus navigation still work. The terminal controls its physical palette, so exact colors vary by profile. Tab/Shift+Tab traverses controls unless a control consumes Tab; the multiline editor uses Tab/Shift+Tab for indent/outdent, so the samples use F6 to leave it. Arrows navigate; Enter activates or commits; Space toggles. Menu mnemonics navigate structure (Alt+V, then plain F), while shortcuts invoke commands directly. Escape cancels the top dialog/menu; even an OK-only dialog returns Cancel on Escape, not acknowledgement.

The controls and interaction guide contains menu and dialog examples, picker keys, configuration, errors, and limits.

The editing guide covers document/view ownership, commands, clipboard completion, caret intent, resource limits, and application-loop integration.

Platforms and Targets

The library, samples, and tests target net8.0, net9.0, and net10.0 with C# 13 and AnyCPU library output. Build tooling supports CMD, shell, and PowerShell 5.1. Interactive applications require a usable terminal and a DCurses profile supporting cursor motion.

Windows, macOS, and Linux are build/CI targets. Live terminal results are environment-specific: W1310 records the 1.3 qualification scope and explicitly unavailable live environments. Automated tests are not a claim of live-terminal qualification.

Design Boundaries and Guarantees

• Applications own terminal sessions, the input reader, monotonic time, command execution, validation, asynchronous work, and cleanup. Widgets starts no hidden event loop or competing input reader.
• Provider jobs return results for application-loop application. Stale, foreign, canceled, and closed-picker results cannot complete a selection.
• Pickers return paths or target observations; they do not create, delete, or write files. The editor sample performs bounded file reads in application code; both editor and workspace samples edit only in memory.
• Modal scopes isolate background commands and restore eligible focus. Compact viewports clip rendering while retaining keyboard cancellation.
• Resource limits are explicit. The 1.0 host supports 1,024 widgets, 4,096 pending actions, and 16 modal/submenu levels; lists and directory snapshots allow 100,000 items. Invalid ownership and capacity violations fail before attachment.
• DCurses immediate-raster presentation cannot compose overlapping retained panels; raster applications select text presentation while an overlay is visible.

Samples and Documentation

The sample guide covers the gallery, editor, roguelike UI, and document workspace. All four support -- --smoke for deterministic checks without a live terminal.

Recommended entry points:

• Controls and interaction — behavior, keys, examples, errors, and limits.
• Changelog — versions and release history.
• Main roadmap — broader direction and library/application boundaries.
• 1.3 public API baseline, 1.2 baseline, 1.1 baseline, and 1.0 baseline — compatibility references.
• Build and packaging guide — local builds and validation/publication workflows.

Release audits, versioned plans, API snapshots, and qualification worksheets remain in the repository. They are intentionally not repeated in this README.

Compatibility and Versioning

The stable 1.0 public API is the compatibility floor for the 1.x line. Additive updates preserve existing control contracts and retain assembly identity 1.0.0.0; package versions advance separately.

The README is a product and contributor entry point. Release chronology belongs in the changelog; implementation and qualification status belongs in versioned roadmaps and evidence records. Planned features are not installation promises.

Authors

While this is all original work by Timothy Bruce, it is inspired by original work from Bill Joy, author of the original termcap; Ken Arnold, for his work on termcap and curses; Mary Ann (born Mark) Horton, author of terminfo; Pavel Curtis, author of pcurses; and Zeyd Ben-Halim, Eric S. Raymond, and Thomas Dickey, whose work developed and maintained libtinfo and ncurses.

Managed .NET implementation by Timothy J. Bruce uniblab@hotmail.com.

Copyright

Copyright (c) 2026 Timothy J. Bruce

License

The library is LGPL-3.0-or-later. Samples and tests are GPL-3.0-or-later, following the established Icod convention. See licensing assignments, LGPL terms, and GPL terms.
