KBUBComm.Database 1.4.2

KBUBComm.Database

Typed protected object-backed configuration and local database storage layer for .NET applications and services.

This is not a general ORM. It is a POCO-first model store:

• define normal C# classes
• mark the root with [DBModel]
• open DatabaseConnection<TModel>
• mutate databaseConnection.Model
• call SyncAsync() for commit-style persistence
• call WriteAsync() / MutateAsync() for immediate persistence

Package contents

The NuGet package includes:

• package icon metadata
• package README metadata
• embedded MIT license file
• neutral sample defaults with no organization-specific wording

Compatibility policy

Version 1.4.2 is a backward-compatible hardening release.

Existing public APIs from 1.4.1 are preserved. The release adds optional helper APIs for diagnostics, backup/export, and secret-reference validation. Existing callers using OpenAsync, WriteAsync, MutateAsync, SyncAsync, list helpers, Secrets.SetAsync, Secrets.GetAsync, and Secrets.RotateAsync do not need call-site changes.

SQLite provider

The package uses:

• Microsoft.Data.Sqlite.Core
• SQLitePCLRaw.bundle_e_sqlite3

The SQLite bundle is initialized explicitly by the SQLite provider before opening connections. This keeps the package self-contained for normal .NET applications without requiring app callers to remember SQLite provider initialization.

Basic use

DatabaseConnection<DemoBridgeDbModel> databaseConnection =
    await DatabaseConnection<DemoBridgeDbModel>.OpenAsync(
        new DatabaseConnectionOptions
        {
            DatabaseName = "DemoStatusBridge",
            StoragePath = databasePath,
            EncryptionMode = DatabaseEncryptionMode.LocalUserProtected,
            ChangedBy = Environment.UserName,
            ChangeReason = "Initial setup"
        });

await databaseConnection.WriteAsync(
    model => model.ConnectionSettings.OpcUaPort,
    4840);

await databaseConnection.AddDistinctToListAsync(
    model => model.ConnectionSettings.ClientIpWhitelist,
    "10.10.20.15");

await databaseConnection.MutateAsync(
    model => model.OpcAndPathSettings.CustomTagsToMonitor,
    tags =>
    {
        if (!tags.Contains("DEMO.CONTROLLER.HEARTBEAT", StringComparer.OrdinalIgnoreCase))
        {
            tags.Add("DEMO.CONTROLLER.HEARTBEAT");
        }
    });

Commit-style changes

databaseConnection.SetAuditContext(Environment.UserName, "Updated bridge settings");

databaseConnection.Model.ConnectionSettings.OpcUaPort = 4840;
databaseConnection.Model.ConnectionSettings.EndpointIp = "127.0.0.1";

IReadOnlyList<DatabaseChange> pendingChanges = databaseConnection.GetPendingChanges();
DatabaseSyncResult syncResult = await databaseConnection.SyncAsync();

Immediate scalar write

DatabaseSyncResult writeResult = await databaseConnection.WriteAsync(
    model => model.ConnectionSettings.ReaderPort,
    55231);

Immediate list mutation

DatabaseSyncResult addResult = await databaseConnection.AddDistinctToListAsync(
    model => model.ConnectionSettings.ClientIpWhitelist,
    "10.10.20.15");

DatabaseSyncResult removeResult = await databaseConnection.RemoveFromListAsync(
    model => model.ConnectionSettings.ClientIpWhitelist,
    "10.10.20.15");

Secrets

Use [DBSecret] only for recoverable outbound secrets, not user login passwords.

SecretRef secretRef = await databaseConnection.Secrets.SetAsync(
    "Demo.Reader.Password",
    passwordValue,
    Environment.UserName);

databaseConnection.Model.Credentials.ReaderPassword = secretRef;
await databaseConnection.SyncAsync();

string password = await databaseConnection.Secrets.GetAsync(
    databaseConnection.Model.Credentials.ReaderPassword);

Diagnostics-safe status

Use GetStatusAsync() to show database state in app diagnostics without exposing protected values, secret values, password hashes, or raw config payloads.

DatabaseStatusSnapshot status = await databaseConnection.GetStatusAsync();

Console.WriteLine(status.DatabasePath);
Console.WriteLine(status.SchemaVersion);
Console.WriteLine(status.ModelValueCount);
Console.WriteLine(status.SecretCount);

DatabaseStatusSnapshot.IsDiagnosticsSafe is always true for the built-in SQLite provider because it reports only paths, counts, provider/version labels, schema metadata, and file metadata.

Backup/export

Use BackupAsync() to create a consistent SQLite backup with VACUUM INTO.

DatabaseBackupResult backup = await databaseConnection.BackupAsync(
    Path.Combine(backupFolder, "settings-backup.db"),
    overwriteExisting: true);

The source database remains open/usable. The backup file is a standalone SQLite database copy.

Secret-reference validation

Use ValidateSecretReferencesAsync() to check [DBSecret] properties currently present on the model.

SecretReferenceValidationResult result = await databaseConnection.ValidateSecretReferencesAsync();

foreach (SecretReferenceValidationIssue issue in result.Issues)
{
    Console.WriteLine($"{issue.Severity}: {issue.ValuePath} - {issue.Message}");
}

Empty secret references are warnings because optional secrets may intentionally be blank. References to missing stored secrets are errors.

Attributes

• [DBModel("Name")] marks the root model.
• [DBName("Name")] overrides the inferred path segment.
• [DBIgnore] skips a property.
• [DBProtected] protects a persisted field value.
• [DBSecret] stores a SecretRef as a protected secret reference.

Current limitations

• SQLite provider only.
• No SQLCipher full-file encryption yet.
• [DBProtected] and [DBSecret] use DPAPI on Windows.
• DatabaseEncryptionMode.None requires AllowPlainTextProtectionForDevelopment = true.
• Automatic property change tracking is intentionally not implemented. Use SyncAsync() or WriteAsync() / MutateAsync().
• User login passwords need a separate password-hashing user manager. Do not store login passwords with [DBSecret].
