MessageValidation.MqttNet 1.0.0

MessageValidation.MqttNet

MQTTnet transport adapter for the MessageValidation pipeline — automatically feed incoming MQTT messages into the validation pipeline with a single line of code.

Installation

dotnet add package MessageValidation.MqttNet

Quick Start

Option A — Extension method on IMqttClient

Wire the pipeline directly onto an existing MQTTnet client:

using MessageValidation.MqttNet;
using MQTTnet;
using MQTTnet.Client;

var factory = new MqttFactory();
var client = factory.CreateMqttClient();

var pipeline = serviceProvider.GetRequiredService<MessageValidationPipeline>();

// One line — all incoming messages now go through the validation pipeline
client.UseMessageValidation(pipeline);

// Connect and subscribe as usual
await client.ConnectAsync(new MqttClientOptionsBuilder()
    .WithTcpServer("broker.example.com")
    .Build());

await client.SubscribeAsync("sensors/+/temperature");

Option B — DI registration

Let the DI container create and configure the client automatically:

using MessageValidation;
using MessageValidation.MqttNet;

builder.Services.AddMessageValidation(options =>
{
    options.MapSource<TemperatureReading>("sensors/+/temperature");
    options.DefaultFailureBehavior = FailureBehavior.Log;
});

builder.Services.AddMessageDeserializer<JsonMessageDeserializer>();
builder.Services.AddMessageHandler<TemperatureReading, TemperatureHandler>();

// Register an IMqttClient with the validation pipeline pre-wired
builder.Services.AddMqttNetMessageValidation();

Then inject IMqttClient wherever you need it:

public class MqttWorker(IMqttClient mqttClient) : BackgroundService
{
    protected override async Task ExecuteAsync(CancellationToken ct)
    {
        await mqttClient.ConnectAsync(new MqttClientOptionsBuilder()
            .WithTcpServer("broker.example.com")
            .Build(), ct);

        await mqttClient.SubscribeAsync("sensors/+/temperature", cancellationToken: ct);

        // Messages are automatically deserialized, validated, and dispatched
        await Task.Delay(Timeout.Infinite, ct);
    }
}

Server-side validation

You can also hook the pipeline on an MQTTnet server to validate messages as they are published:

using MessageValidation.MqttNet;
using MQTTnet.Server;

var serverOptions = new MqttServerOptionsBuilder()
    .WithDefaultEndpoint()
    .Build();

var server = new MqttFactory().CreateMqttServer(serverOptions);

var pipeline = serviceProvider.GetRequiredService<MessageValidationPipeline>();
server.UseMessageValidation(pipeline);

await server.StartAsync();

MQTT Metadata

When the adapter creates a MessageContext, it populates the Metadata dictionary with MQTT-specific properties:

Access them in your handler:

public class TemperatureHandler : IMessageHandler<TemperatureReading>
{
    public Task HandleAsync(
        TemperatureReading message, MessageContext context, CancellationToken ct = default)
    {
        var qos = context.Metadata["mqtt.qos"];
        Console.WriteLine($"[{context.Source}] QoS={qos} — Sensor {message.SensorId}: {message.Value}°C");
        return Task.CompletedTask;
    }
}

API Reference

IMqttClient.UseMessageValidation(MessageValidationPipeline pipeline)

Hooks the pipeline into the client's ApplicationMessageReceivedAsync event. Returns the same IMqttClient for chaining.

MqttServer.UseMessageValidation(MessageValidationPipeline pipeline)

Hooks the pipeline into the server's InterceptingPublishAsync event. Returns the same MqttServer for chaining.

AddMqttNetMessageValidation(Action<IMqttClient>? configureMqttClient = null)

Registers a singleton IMqttClient in the DI container with the validation pipeline pre-wired. Optional callback for additional client configuration.

Requirements

• .NET 10+
• MessageValidation core package
• MQTTnet 4+

License

MIT
