StormSocket 5.1.0

<p align="center"> <img src="assets/stormsocket-logo.png" alt="StormSocket" width="256" /> </p>

<h1 align="center">StormSocket</h1>

<p align="center"> <a href="https://github.com/suleymanbyzt/StormSocket/actions"><img src="https://img.shields.io/github/actions/workflow/status/suleymanbyzt/StormSocket/ci.yml?branch=master" alt="Build" /></a> <img src="https://img.shields.io/endpoint?url=https://gist.githubusercontent.com/suleymanbyzt/536cdf59b30363682a17ef0927ed7f45/raw/stormsocket-coverage.json" alt="Coverage" /> <a href="https://www.nuget.org/packages/StormSocket"><img src="https://img.shields.io/nuget/v/StormSocket.svg" alt="NuGet" /></a> <a href="https://www.nuget.org/packages/StormSocket"><img src="https://img.shields.io/nuget/dt/StormSocket.svg" alt="NuGet Downloads" /></a> <a href="https://github.com/suleymanbyzt/StormSocket/stargazers"><img src="https://img.shields.io/github/stars/suleymanbyzt/StormSocket" alt="Stars" /></a> <a href="https://github.com/suleymanbyzt/StormSocket/issues"><img src="https://img.shields.io/github/issues/suleymanbyzt/StormSocket" alt="Issues" /></a> <img src="https://img.shields.io/github/last-commit/suleymanbyzt/StormSocket" alt="Last Commit" /> <a href="LICENSE"><img src="https://img.shields.io/badge/License-MIT-green.svg" alt="License" /></a> <img src="https://img.shields.io/badge/.NET-6.0%20|%207.0%20|%208.0%20|%209.0%20|%2010.0-blue" alt=".NET" /> </p>

<p align="center">Modern, high-performance, event-based TCP/WebSocket/SSL library for .NET built on <b>System.IO.Pipelines</b>.</p>

<p align="center"> <a href="https://suleymanbyzt.github.io/StormSocket/docs/getting-started.html"><b>Getting Started</b></a> · <a href="https://suleymanbyzt.github.io/StormSocket/docs/features.html">Features</a> · <a href="https://suleymanbyzt.github.io/StormSocket/docs/configuration.html">Configuration</a> · <a href="https://suleymanbyzt.github.io/StormSocket/docs/examples.html">Examples</a> </p>

Zero subclassing required. Subscribe to events, configure options, and go. Server and client included.

Why StormSocket?

• Pooled I/O — System.IO.Pipelines buffer pool, ArrayPool for send encoding, and per-connection unmask buffers, so steady-state message traffic allocates almost nothing
• Backpressure that actually works — configurable pipe thresholds, OS TCP window propagates upstream
• Subscribe, don't subclass — server.OnDataReceived += handler, no inheritance chains
• SSL is a config flag — same server, add SslOptions, done
• Middleware pipeline — rate limiting, auth, logging as composable plugins
• Built-in pub/sub — named groups for chat rooms, game lobbies, ticker feeds

Features

• Event-based API - no subclassing, just server.OnDataReceived += handler
• TCP Server & Client with optional message framing (raw, length-prefix, delimiter)
• WebSocket Server & Client built to RFC 6455, 247/247 Autobahn Testsuite conformance cases passing — it validates the protocol rather than only speaking it: masking enforced in both directions, incremental UTF-8 validation across fragments (1007), close-code and close-reason validation (1002/1007), single close frame with a proper closing handshake, control-frame and frame-length rules, strict handshake validation
• SSL/TLS as a simple configuration option on any server or client
• Auto-reconnect - clients automatically reconnect on disconnect with configurable delay and max attempts
• System.IO.Pipelines — received payloads are handed to handlers without a copy where the protocol allows it, with backpressure that reaches the socket
• Automatic heartbeat with configurable ping interval and dead connection detection (missed pong counting)
• Session management - track, query, broadcast, and kick connections
• Groups/Rooms - named groups for targeted broadcast (chat rooms, game lobbies, etc.)
• WebSocket authentication - access path, query params, headers (cookies, tokens) before accepting connections via OnConnecting event
• Rate limiting middleware - opt-in per-session or per-IP limiting with a sliding window, configurable action (disconnect/drop) and exceeded event; meters control frames and fragments too, so a ping flood costs the sender budget
• Middleware pipeline - intercept connect, disconnect, data received, data sending, and errors (works on both server and client)
• Backpressure & buffer limits - configurable send/receive pipe limits prevent memory exhaustion
• Per-session user data - session.Items dictionary + strongly-typed session.Get<T> / session.Set<T> via SessionKey<T> — no external dictionary needed
• Slow consumer detection - SlowConsumerPolicy per session: Wait (block), Drop (skip), or Disconnect (close)
• Message fragmentation - automatic reassembly of fragmented WebSocket messages (RFC 6455 Section 5.4) with MaxMessageSize limit and send-side fragmentation helpers
• Connection idle timeout - automatically close connections that haven't sent any application-level data within a configurable period (ping/pong does NOT reset the timer)
• Disconnect reason tracking - OnDisconnected provides a DisconnectReason enum (ClosedByClient, ClosedByServer, Aborted, ProtocolError, TransportError, HeartbeatTimeout, HandshakeTimeout, SlowConsumer, GoingAway, RateLimited, IdleTimeout, MessageTooBig)
• Handshake timeout - configurable timeout for the WebSocket upgrade, plus a separate TlsHandshakeTimeout so a peer cannot park mid-TLS
• Connection limits that count half-open connections - MaxConnections and MaxConnectionsPerIp are claimed at accept time, before TLS and the upgrade, so slowloris-style connections cannot walk past them
• Bounded upgrade parsing - MaxRequestHeaderBytes / MaxRequestHeaderCount (16 KB / 100 by default), answered with 431
• Bounded decompression - permessage-deflate output is capped at MaxMessageSize, so a compression bomb fails the connection with 1009 instead of the process
• TCP Keep-Alive - fine-tuning options (idle time, probe interval, probe count)
• Unix domain socket transport — same API, just pass UnixDomainSocketEndPoint for fast local IPC (container-to-container, sidecar proxy)
• Multi-target: net6.0, net7.0, net8.0, net9.0, net10.0
• Server metrics - server.Metrics exposes active connections, total connections, messages sent/received, bytes, errors — built on System.Diagnostics.Metrics for native OpenTelemetry/Prometheus/dotnet-counters integration
• Structured logging via ILoggerFactory — zero overhead when disabled, structured output when enabled
• Zero dependencies beyond System.IO.Pipelines and Microsoft.Extensions.Logging.Abstractions

Quick Start

dotnet add package StormSocket

TCP Server

var server = new StormTcpServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 5000),
});

server.OnDataReceived += async (session, data) =>
{
    await session.SendAsync(data); // echo
};

await server.StartAsync();

WebSocket Server

var ws = new StormWebSocketServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 8080),
    WebSocket = new WebSocketOptions
    {
        Heartbeat = new() { PingInterval = TimeSpan.FromSeconds(15), MaxMissedPongs = 3 },
        Compression = new() { Enabled = true },
    },
});

ws.OnConnected += async session =>
{
    session.Set(UserId, "abc");       // type-safe session data
    ws.Groups.Add("lobby", session);  // join a room
};

ws.OnMessageReceived += async (session, msg) =>
{
    await ws.BroadcastTextAsync(msg.Text, excludeId: session.Id);
};

await ws.StartAsync();

msg.Data points into a buffer the connection reuses for the next frame, so it is valid for the duration of the handler. Copy it (msg.Data.ToArray()) if it outlives the call — a queue, a field, a captured closure. msg.Text already returns an independent string.

ASP.NET Core / Generic Host

dotnet add package StormSocket.Extensions.Hosting

builder.Services
    .AddStormWebSocketServer(options => options.MaxConnections = 10_000)
    .ListenOnAnyIP(8080)
    .AddHandler<ChatHandler>();

builder.Services.AddHealthChecks().AddStormWebSocketServer();

public sealed class ChatHandler(AppDbContext db) : IWebSocketHandler
{
    public async ValueTask OnMessageAsync(IWebSocketSession session, WsMessage message, CancellationToken ct)
        => await session.SendTextAsync(message.Text, ct);
}

Handlers are resolved per message from a DI scope, so scoped dependencies work the way they do in a web request. The server starts and stops with the host, drains in-flight work on shutdown, and logs through the application's logger factory. See the hosting guide.

WebSocket Client

var client = new StormWebSocketClient(new WsClientOptions
{
    Uri = new Uri("ws://localhost:8080"),
    Reconnect = new() { Enabled = true, Delay = TimeSpan.FromSeconds(2) },
    Subprotocols = ["graphql-ws"],
});

client.OnMessageReceived += async msg => Console.WriteLine(msg.Text);
await client.ConnectAsync();
await client.SendTextAsync("Hello!");

SSL — one line

var server = new StormWebSocketServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 443),
    Ssl = new() { Certificate = X509CertificateLoader.LoadPkcs12FromFile("cert.pfx", "pass") },
});

Authentication

ws.OnConnecting += async context =>
{
    string? token = context.Headers.GetValueOrDefault("Authorization");
    if (!IsValid(token))
        context.Reject(401, "Invalid token");
    else
        context.Accept();
};

Session Data — string keys or type-safe

// String keys
session.Items["role"] = "admin";

// Strongly-typed (no casts, compile-time safe)
static readonly SessionKey<string> UserId = new("userId");
session.Set(UserId, "abc123");
string id = session.Get(UserId);

Groups, Broadcast, Rate Limiting

ws.Groups.Add("room:vip", session);
await ws.Groups.BroadcastAsync("room:vip", data, excludeId: session.Id);

server.UseMiddleware(new RateLimitMiddleware(new RateLimitOptions
{
    Window = TimeSpan.FromSeconds(10), MaxMessages = 100,
}));

Slow Consumer Policy

var server = new StormWebSocketServer(new ServerOptions
{
    SlowConsumerPolicy = SlowConsumerPolicy.Drop, // Wait | Drop | Disconnect
    MaxConnections = 50_000,
});

Unix Domain Socket

// Server — fast local IPC, skips the TCP/IP stack entirely
var server = new StormTcpServer(new ServerOptions
{
    EndPoint = new UnixDomainSocketEndPoint("/tmp/myapp.sock"),
});

// Client
var client = new StormTcpClient(new ClientOptions
{
    EndPoint = new UnixDomainSocketEndPoint("/tmp/myapp.sock"),
});

Idle Timeout

var server = new StormWebSocketServer(new ServerOptions
{
    WebSocket = new WebSocketOptions
    {
        IdleTimeout = TimeSpan.FromMinutes(5), // close if no data for 5 min
    },
});
// ping/pong does NOT reset the timer — only real messages count

Server Metrics

// Direct property access
var m = server.Metrics;
Console.WriteLine($"Active: {m.ActiveConnections}, Total: {m.TotalConnections}");
Console.WriteLine($"Msgs in: {m.MessagesReceived}, Msgs out: {m.MessagesSent}");
Console.WriteLine($"Bytes in: {m.BytesReceivedTotal}, Bytes out: {m.BytesSentTotal}");
Console.WriteLine($"Errors: {m.ErrorCount}");

Built on System.Diagnostics.Metrics — works with OpenTelemetry, Prometheus, and dotnet-counters out of the box:

// OpenTelemetry integration (just add an exporter)
builder.Services.AddOpenTelemetry()
    .WithMetrics(m => m.AddMeter("StormSocket").AddPrometheusExporter());

// Or monitor from CLI — no code needed:
// $ dotnet-counters monitor --counters StormSocket

Disconnect Reasons

ws.OnDisconnected += async (session, reason) =>
{
    // ClosedByClient | ClosedByServer | HeartbeatTimeout | SlowConsumer
    // ProtocolError | TransportError | RateLimited | GoingAway | IdleTimeout | ...
    Console.WriteLine($"#{session.Id}: {reason}");
};

Full details: Features Guide | Examples | Configuration

Architecture

Benchmarks

Two different things get called "performance", and they are measured separately here because one cannot be derived from the other: a deeply pipelined run can push millions of messages per second while any single message waits milliseconds behind the ones queued ahead of it.

Numbers below are from an Apple M-series laptop, .NET 9, server GC, loopback, client and server on the same machine — treat them as a shape, not a spec sheet, and run them yourself.

Latency — measured round-trips, pipeline depth 1

Every message is timed individually with Stopwatch.GetTimestamp, and the next one is not sent until the echo comes back.

dotnet run -c Release --project benchmark/StormSocket.Benchmark.TcpEchoServer
dotnet run -c Release --project benchmark/StormSocket.Benchmark.TcpEchoClient -- -c 50 -s 32 -z 10 --mode latency

Throughput — saturation, deep pipeline

100 connections each keeping a 1000-message send window full (~100k messages in flight). This is a saturation figure: it says how much the server moves, not how long a message takes.

dotnet run -c Release --project benchmark/StormSocket.Benchmark.TcpEchoClient -- -c 100 -m 1000 -s 32 -z 10

Conformance

The Autobahn Testsuite is the reference suite for RFC 6455: it throws malformed frames, truncated UTF-8, reserved close codes and hostile handshakes at a server and judges both the reply and the close.

The UNIMPLEMENTED cases ask the server to compress with a smaller LZ77 window. DeflateStream exposes no window-size control, so those offers are declined rather than accepted and quietly ignored, which is what RFC 7692 Section 7.1.2.2 asks for. Both suites run in CI on every push (.github/workflows/autobahn.yml) and the full report is published as a build artifact.

dotnet run -c Release --project benchmark/autobahn/AutobahnEchoServer 9001
docker run --rm -v "$PWD/benchmark/autobahn:/config" -v "$PWD/benchmark/autobahn/reports:/reports" \
  crossbario/autobahn-testsuite wstest --mode fuzzingclient --spec /config/fuzzingclient.json

Frame decoding

Decode path in isolation, no sockets involved — this is where the WebSocket layer's own cost lives (best of five runs, per frame):

Unmasking is vectorized in 5.0, which is what moves the larger payloads. The 32-byte row goes the other way: that is the protocol validation added in 5.0 (masking, close codes, UTF-8, frame limits), and it is a trade this project is willing to make. Allocation per message on the server dropped from 156 to 109 bytes over a 25M-message run, and gen0 collections from 46 to 28.

No comparison against other libraries is published here. A fair one needs the competing harness committed next to ours, pinned versions and disclosed hardware; until that exists, numbers you cannot reproduce are not worth printing.

Documentation

Building

git clone https://github.com/suleymanbyzt/StormSocket.git
cd StormSocket
dotnet build
dotnet test

Samples

dotnet run --project samples/StormSocket.Samples.TcpEcho
dotnet run --project samples/StormSocket.Samples.WsChat
dotnet run --project samples/StormSocket.Samples.SslEcho
dotnet run --project samples/StormSocket.Samples.WsServer

License

MIT License - see LICENSE for details.
