TedToolkit.CppBindings.Generator 2026.9.15

TedToolkit.CppBindings.Generator

Provider-neutral generation stages for C++ bindings. This .NET 10 tool package owns source-path validation, publication, and the existing Windows x64 native function-table/loading mechanics. It contains no Clang declarations, OCCT rules, native package dependencies, or ownership classification.

Use

The package is unreleased; pack it locally before adding a direct package reference:

<PackageReference Include="TedToolkit.CppBindings.Generator" Version="1.0.0" />

Implement IGenerationProvider directly, or derive from SemanticGenerationProvider when the provider uses the shared semantic extension boundary. Register its preparation module types on a PipelineBuilder, then call AddCppGenerators(options, provider). The complete executable example is the independent packed consumer. It references only this package and needs neither a provider assembly nor friend access.

GenerationOptions supplies dedicated, non-overlapping CSharpFolder and CppFolder directories, CSharpNamespace, and a portable NativeLibraryBaseName. The built-in target is win-x64, with Cdecl function pointers and the MSVC native ABI. Other runtime identifiers are rejected before preparation. CppVersion defaults to 17 and is available to the provider's native build description; IsInternal is available to its managed emitters. Set NativeLibraryVersion to a System.Version when the provider's primary native package must match exactly. Leaving it unset preserves the provider's existing unversioned resolver behavior; it does not promise that every resolver chooses the globally newest release.

Provider contract

CreatePlanAsync runs once after every declared preparation module succeeds. A direct IGenerationProvider returns a GenerationPlan containing copied, read-only C# and C++ source inventories and one exact native export order. Both sides must derive their slot indexes from that same order. Preparation and renderer failures or cancellation propagate instead of becoming an empty successful plan.

AddCppGenerators calls the options-aware CreatePlanAsync(options, cancellationToken) overload. Existing providers that only implement the cancellation-only overload remain source compatible. Their default options-aware implementation delegates when NativeLibraryVersion is unset and throws NotSupportedException when an exact version is requested, so a provider cannot silently ignore the selection.

Each GeneratedSource has an output-relative path and an asynchronous streaming renderer. Write to the supplied TextWriter, observe cancellation, and neither retain nor dispose the writer. A provider can preserve its own renderer concurrency limits; the core owns file creation and disposal. Rendering starts only after the entire plan passes path, collision and export checks.

The core reserves NativeApi.g.cs and NativeFunctionTable.cpp; the native project automatically receives the latter in its complete compiled-source inventory. BindingCMakeProjectDefinition lets providers submit dependency targets, compile facts, target properties, and optional bounded family/depth unity grouping while Shared owns deterministic CMake rendering. Providers still own their native headers, local error support, dependency choices, and declaration-specific semantics. Do not return either reserved path yourself.

Semantic extension boundary

BindingSemanticEngine composes provider-owned IBindingTypeRule, IBindingLayoutPolicy, IBindingTemplatePolicy, and named IBindingEmitterPrimitive implementations. A SemanticGenerationProvider overrides CreateProviderModelAsync and returns a BindingProviderModel: normalized declarations and enums, explicit roots and dependency identities, a finite emission profile, supplemental sources and exports, and native build metadata.

Shared owns the normalized record, member, type, transport, lifetime, layout, and template model. It closes roots over dependencies, rejects incomplete semantics, assigns the single export-slot order, and emits both declaration bodies before creating the final GenerationPlan. Providers supply compiler-derived facts and finite syntax/runtime policy; they do not submit declaration-renderer delegates or reconstruct a second model for either language. Supplemental provider renderers are limited to genuinely library-specific support such as adapter types or polymorphic result projection; generic native-project boilerplate belongs to Shared.

Finite handwritten native profiles use BindingFiniteProfileApi when their ABI is not a direct set of C++ member declarations. The API contains collections of named status, value, owner, and result types plus an ordered set of composable operations; it does not prescribe one provider's operation topology. Explicit buffer definitions drive span validation and pointer/length transport. Operations select conditional or direct owner construction, scalar or composite projection, and counted two-phase buffer copying. Public managed types, managed ABI transports, and native transports remain distinct inputs. The explicit export order drives both managed slots and NativeFunctionTable.cpp. Providers retain only their native algorithm bodies and dependency-specific build policy. Shared contains no provider-name branch or provider assembly dependency, and validates the complete graph before publishing a plan.

Type rules are evaluated in registration order and the first match wins. Layout and template policies must return BindingAdmission.Admitted or a rejected result with a stable reason. Emitter primitive names are unique and case-sensitive. Keep these policies in the provider package; Shared must never reference a provider assembly.

Output directories are exclusively for generated artifacts: successful preparation clears stale contents while preserving the roots. Invalid plans do not clear existing output. Rendering failure can leave partial files and must never be treated as successful publication. Filesystem roots, overlapping roots, traversal paths, collisions, and filesystem links are rejected. Callers must not concurrently replace output paths while a run is active.

Native lifetime

Generated loading uses NativeLibrary.Load, one exported NativeApi_GetFunctionTable entry, and a native pointer table retained for process lifetime. It introduces no fingerprint, runtime manifest, table replacement, or unloading. Package-owned native artifacts must match the generated managed binding; this package does not authorize substituting a different native build.

Verify

From the repository root:

pwsh -NoProfile -File Build/VerifyProviderBoundaries.ps1
dotnet run --project tests/TedToolkit.CppBindings.Generator.Tests/TedToolkit.CppBindings.Generator.Tests.csproj -c Release
pwsh -NoProfile -File Build/VerifyGeneratorPackage.ps1

This PowerShell 7.5 verification packs Shared, builds an isolated consumer with a fresh package cache, checks the restored package hash and dependency graph, and exercises real Shared-produced managed/native declaration bodies, preparation ordering, detached semantic graph snapshots, exact export ordering, deterministic output, narrow semantic rejection, path rejection, failure, and cancellation. It retains logs and results under out/verification. NuGet access is required to restore ordinary tool dependencies. This proves the generic boundary, not a complete OCCT build.
