WebScene.JavaScript.Interop.Generator 1.0.34

WebScene JavaScript interop source generator

This analyzer generates strongly typed .NET models, outbound proxies, and inbound adapters from an WebScene interop API manifest and reviewed policy.

Reference both packages:

<ItemGroup>
  <PackageReference Include="WebScene.JavaScript.Interop" Version="..." />
  <PackageReference Include="WebScene.JavaScript.Interop.Generator"
                    Version="..."
                    PrivateAssets="all" />
</ItemGroup>

Then configure the two generator inputs. The package's build-transitive target adds them as Roslyn AdditionalFiles and validates that both exist:

<PropertyGroup>
  <WebSceneInteropApiManifest>Interop/TradingView.webscene-interop-api.json</WebSceneInteropApiManifest>
  <WebSceneInteropPolicy>Interop/TradingView.webscene-interop-policy.json</WebSceneInteropPolicy>
</PropertyGroup>

Generate and compile a complete declaration-package validation with webscene-interop-validate. Licensed declarations remain local to the application and are never embedded in either WebScene package.

External contracts and ABI 3 codecs

Object typeMappings automatically receive ABI 3 readers and writers when their TypeScript schema and CLR contract are compatible. The codec is emitted into the integration assembly and directly consumes the external contract. The contracts assembly needs no WebScene, Avalonia, or backend reference.

For interface Sample { time: number; value: number | null; }, a referenced public sealed record Sample(double Time, double? Value); works with:

{
  "typeMappings": { "Sample": "global::Application.Contracts.Sample" },
  "models": [{ "source": "Sample", "include": false }]
}

Property names default to PascalCase. To use Timestamp and Price instead, add "propertyMappings": { "time": "Timestamp", "value": "Price" } to the Sample model policy. These names select CLR properties; the binary property names and ordering still come from the TypeScript manifest. JSON attributes do not change the native wire schema.

Both directions support direct objects, arrays, nullable values, and nested supported external contracts. Writers reuse the generated DTO wire format and read the supplied objects/lists directly without intermediate DTOs or projected arrays. Readers construct the final external objects and result arrays. Struct writes use typed access without boxing each value, including nullable structs and struct array elements. Struct readers prefer a matching constructor.

Contracts must be accessible, non-abstract, non-generic classes or structs (including records) with public readable properties of the mapped CLR types. Reading requires either an accessible parameterless constructor and writable/init properties, or one accessible constructor matching all mapped properties by name (ignoring case) and type. Constructor parameter order may differ from wire property order. Required members must be initialized or satisfied by a SetsRequiredMembers constructor. Array properties accept IReadOnlyList<T> and, for non-nullable required arrays, T[]. By default, optional TypeScript properties require the existing JavaScriptOptional<T> representation to preserve absent versus null semantics. External models can explicitly choose ordinary CLR properties using optionalProperties as described below.

Unsupported contracts (including recursive graphs, ref structs, generics, index signatures, incompatible properties, and unavailable constructors) emit warning WEBSCENEJS004 with the reason. Remove the mapping and enable the generated model, adjust the contract/policy, or supply a custom binary invocation. Native object and function handle mappings remain supported. Projects requiring native transport can promote the warning with <WarningsAsErrors>$(WarningsAsErrors);WEBSCENEJS004</WarningsAsErrors>.

Integer timestamp properties

External long properties can map to TypeScript number, and long? properties can map to number | null. The generated codec converts them to and from the ABI's double-precision number representation. This applies to required properties and optional properties explicitly mapped to ordinary CLR values with optionalProperties. Wrappers using JavaScriptOptional<long> are not currently converted.

JavaScript numbers cannot represent every 64-bit integer. To prevent silent precision loss, both directions enforce the safe-integer interval [-9007199254740991, 9007199254740991] (±(2^53 − 1)). Writes outside that interval throw OverflowException, even if a particular larger integer is representable. Reads also reject fractional values, NaN, and infinities with OverflowException; they never truncate, round, or clamp. Nullable properties preserve null. Unix millisecond timestamps in this interval round-trip exactly; full-range 64-bit identifiers require another wire representation.

For example, a neutral readonly record struct TradingViewBar(long TimeMilliseconds, double Open, double High, double Low, double Close, double Volume) can use "propertyMappings": { "time": "TimeMilliseconds" } to match a candle schema with numeric time, open, high, low, close, and volume properties.

Optional fields in neutral contracts

External model policies can explicitly map optional TypeScript fields to ordinary CLR properties. For example, spreadBidPriceInBps?: number | null can use double? SpreadBidPriceInBps, and volume?: number can use double Volume:

{
  "typeMappings": { "Point": "global::Application.Contracts.Point" },
  "models": [{
    "source": "Point",
    "include": false,
    "optionalProperties": {
      "spreadBidPriceInBps": { "write": "always", "read": "null" },
      "volume": { "write": "always", "read": "default", "default": 0 }
    }
  }]
}

Keys are TypeScript property names, even when propertyMappings renames their CLR properties. Each entry must explicitly specify write and read:

• write: "always" emits the property on every write, including a null value when the declared type permits null. Values are never omitted based on their default value. This is the only ordinary-property write mode currently supported.
• read: "reject" throws InvalidOperationException when the property is absent.
• read: "null" maps absence to null and requires a nullable CLR property compatible with the TypeScript value type.
• read: "default" maps absence to the explicit JSON default value. Defaults support compatible strings, booleans, finite numbers, or null for nullable properties (including external objects). Int64 defaults must be safe integers. Object and array defaults are not supported.

Explicit JavaScript undefined follows the same rule as absence. Explicit null is handled according to the declared value type: it remains null for nullable fields and is rejected for non-nullable fields. A configured default is never substituted for an explicit null or an invalid supplied value. In particular, volume?: number with default 0 rejects explicit null; it does not become a nullable property. Long conversions retain the range and precision checks above.

Only fields listed in optionalProperties use these semantics. Other optional fields still require JavaScriptOptional<T> and preserve absent versus present null/value. Ordinary properties need no WebScene reference in the contracts assembly. The policy changes codec behavior explicitly without changing the TypeScript declarations, and writes still avoid intermediate DTOs, projected arrays, and per-element boxing for struct arrays. Invalid or incompatible policy entries produce WEBSCENEJS004.

Adapter-valued properties

Instance and global properties whose declared value is a generated callback adapter use ABI 3 retained handles. Their getters return JavaScriptObjectReference (or JavaScriptObjectReference? for optional/nullable properties), rather than attempting to deserialize an abstract adapter class. Promise-valued properties await the promise before returning the handle. Writable adapter-valued instance properties likewise accept a handle; an existing adapter exposes its registered handle through JavaScriptReference.

For example, GetDotnetBridgeAsync() now returns the JavaScript bridge object's handle. It does not recover the original registered .NET adapter instance or create a typed proxy for its methods. Keep the adapter instance separately when that is needed. Callback registration APIs and adapter classes are unchanged.

Each non-null getter result owns a retained native handle. Release it through the same invoker when finished, independently of the adapter's registration lifetime:

var bridgeReference = await host.GetDotnetBridgeAsync();
try
{
    // Use bridgeReference in supported native interop operations.
}
finally
{
    await invoker.ReleaseAsync(bridgeReference);
}

This changes the return type of previously unsupported adapter-valued getters. Ordinary generated-model and binding-valued properties retain their existing mapping. Mixed unions and collections of adapters are not projected to handles by this property-specific behavior.
