XpressCache 1.0.1

XpressCache

A high-performance, thread-safe in-memory cache for .NET with built-in cache stampede (thundering herd) prevention using per-key single-flight locking.

Features

• 🚀 High Performance: Lock-free read operations with value-type keys for zero-allocation lookups
• 🧵 Thread-Safe: All operations are thread-safe with concurrent dictionary and atomic operations
• 🛡️ Cache Stampede Prevention: Per-key single-flight locking prevents thundering herd problems
• ⏳ Sliding Expiration: Automatic TTL renewal on access with configurable expiry policies
• ⚙️ Flexible Configuration: Control stampede prevention globally or per-call
• 🎯 Multi-Targeting: Supports .NET 6.0, .NET 7.0, .NET 8.0, .NET 9.0, and .NET 10.0
• 🧹 Automatic Cleanup: Probabilistic and manual cleanup of expired entries
• 🧪 Custom Validation: Support for custom validation functions on cached items
• 📚 Fully Documented: Comprehensive XML documentation for all public APIs

What is Cache Stampede?

Cache stampede (also known as thundering herd) occurs when:

1. A cached item expires
2. Multiple concurrent requests try to access it simultaneously
3. All requests miss the cache and trigger expensive recovery operations
4. Resources are wasted computing the same data multiple times

XpressCache solves this by ensuring only one caller executes the recovery function while others wait for and share the result.

Installation

Install via NuGet Package Manager:

dotnet add package XpressCache

Or via Package Manager Console:

Install-Package XpressCache

Quick Start

Basic Usage

using XpressCache;
using Microsoft.Extensions.Logger;
using Microsoft.Extensions.DependencyInjection;

// Setup with dependency injection
var services = new ServiceCollection();
services.AddLogging();
services.AddSingleton<ICacheStore, CacheStore>();

var provider = services.BuildServiceProvider();
var cache = provider.GetRequiredService<ICacheStore>();

// Load an item (with cache-miss recovery)
var userId = Guid.NewGuid();
var user = await cache.LoadItem<User>(
    entityId: userId,
    subject: "users",
    cacheMissRecovery: async (id) =>
    {
        // This expensive operation runs only once for concurrent requests
        return await database.GetUserAsync(id);
    }
);

Configuration Options

using Microsoft.Extensions.Options;

// Configure cache behavior
var options = Options.Create(new CacheStoreOptions
{
    PreventCacheStampedeByDefault = true,  // Enable single-flight (default: true)
    DefaultTtlMs = 10 * 60 * 1000,         // 10 minutes (default)
    InitialCapacity = 512,                  // Initial dictionary capacity
    ProbabilisticCleanupThreshold = 1000    // Trigger cleanup above this size
});

var cache = new CacheStore(logger, options);

Per-Call Behavior Control

// Force stampede prevention for expensive operations
var data = await cache.LoadItem<ExpensiveData>(
    entityId: id,
    subject: "reports",
    cacheMissRecovery: GenerateExpensiveReportAsync,
    behavior: CacheLoadBehavior.PreventStampede
);

// Allow parallel loads for cheap, idempotent operations
var config = await cache.LoadItem<Config>(
    entityId: id,
    subject: "config",
    cacheMissRecovery: LoadConfigAsync,
    behavior: CacheLoadBehavior.AllowParallelLoad
);

// Use default behavior from CacheStoreOptions
var item = await cache.LoadItem<Item>(
    entityId: id,
    subject: "items",
    cacheMissRecovery: LoadItemAsync,
    behavior: CacheLoadBehavior.Default  // This is also the default parameter
);

Advanced Usage

Custom Validation

Implement custom validation to invalidate cache entries based on business logic:

var product = await cache.LoadItem<Product>(
    entityId: productId,
    subject: "products",
    cacheMissRecovery: async (id) => await database.GetProductAsync(id),
    customValidate: async (cachedProduct) =>
    {
        // Invalidate if price changed in database
        var currentPrice = await database.GetProductPriceAsync(cachedProduct.Id);
        return cachedProduct.Price == currentPrice;
    }
);

Manual Cache Operations

// Explicitly set an item in cache
await cache.SetItem(userId, "users", userObject);

// Remove a specific item
bool removed = cache.RemoveItem<User>(userId, "users");

// Get all cached items of a type
List<User> allCachedUsers = cache.GetCachedItems<User>("users");

// Clear entire cache
cache.Clear();

// Manual cleanup of expired entries
cache.CleanupCache();

// Enable/disable caching at runtime
cache.EnableCache = false;  // All operations become no-ops
cache.EnableCache = true;   // Re-enable caching (clears existing cache)

Dependency Injection with ASP.NET Core

// In Program.cs or Startup.cs
builder.Services.Configure<CacheStoreOptions>(options =>
{
    options.PreventCacheStampedeByDefault = true;
    options.DefaultTtlMs = 15 * 60 * 1000;  // 15 minutes
    options.InitialCapacity = 1024;
});

builder.Services.AddSingleton<ICacheStore, CacheStore>();

// Usage in controllers or services
public class ProductService
{
    private readonly ICacheStore _cache;
    private readonly IProductRepository _repository;

    public ProductService(ICacheStore cache, IProductRepository repository)
    {
        _cache = cache;
        _repository = repository;
    }

    public async Task<Product> GetProductAsync(Guid productId)
    {
        return await _cache.LoadItem<Product>(
            entityId: productId,
            subject: "products",
            cacheMissRecovery: _repository.GetByIdAsync
        );
    }
}

How It Works

Cache Key Structure

XpressCache uses a composite key consisting of:

• Entity ID (Guid): Unique identifier for the entity
• Type (Type): The .NET type of the cached item
• Subject (string): Optional categorization (e.g., "users", "products")

This allows you to cache different types with the same ID without conflicts.

Single-Flight Pattern

When stampede prevention is enabled:

1. First Request (cache miss):

   • Acquires per-key lock
   • Executes cache-miss recovery function
   • Stores result in cache
   • Releases lock
   • Returns result

2. Concurrent Requests (for same key):

   • Wait for per-key lock
   • After lock released, check cache again (double-check pattern)
   • Find cached result from first request
   • Return cached result without executing recovery

3. Different Keys:

   • Execute in parallel (locks are per-key, not global)

Expiration and Renewal

• Entries have a sliding expiration window (TTL)
• Accessing an entry extends its expiration (best-effort)
• Expired entries are removed lazily during access
• Probabilistic cleanup prevents unbounded growth
• Manual cleanup available via CleanupCache()

Thread Safety Guarantees

All operations are thread-safe:

• 🧵 LoadItem - Multiple concurrent calls are safe
• ✍️ SetItem - Atomic updates
• ❌ RemoveItem - Safe concurrent removal
• 📋 GetCachedItems - Returns consistent snapshot
• 🧹 Clear - Safe to call anytime
• 🧹 CleanupCache - Can run concurrently with other operations
• 🔒 EnableCache setter - Thread-safe property

Performance Characteristics

Best Practices

✅ DO

• Use stampede prevention for expensive operations (database, API calls)
• Set appropriate TTL based on data volatility
• Use subject parameter to categorize related items
• Handle null returns from LoadItem when recovery returns null
• Consider custom validation for critical data freshness
• Use AllowParallelLoad for cheap, idempotent operations
• Monitor cache size and adjust ProbabilisticCleanupThreshold

🚫 DON'T

• Don't cache very large objects (hundreds of MB per entry)
• Don't use for persistent storage (in-memory only)
• Don't call GetCachedItems in hot paths (O(n) operation)
• Don't forget to handle exceptions in recovery functions
• Don't disable stampede prevention for expensive operations
• Don't use excessively short TTLs (defeats caching purpose)

Migration from Other Caches

From IMemoryCache

// Before (IMemoryCache)
var user = await cache.GetOrCreateAsync(userId, async entry =>
{
    entry.AbsoluteExpirationRelativeToNow = TimeSpan.FromMinutes(10);
    return await database.GetUserAsync(userId);
});

// After (XpressCache)
var user = await cache.LoadItem<User>(
    entityId: userId,
    subject: "users",
    cacheMissRecovery: database.GetUserAsync
);

From ConcurrentDictionary

// Before (manual ConcurrentDictionary)
var dict = new ConcurrentDictionary<Guid, User>();
var user = dict.GetOrAdd(userId, id => LoadUser(id)); // Synchronous only

// After (XpressCache)
var user = await cache.LoadItem<User>(
    entityId: userId,
    subject: "users",
    cacheMissRecovery: LoadUserAsync  // Async support
);

Troubleshooting

High Memory Usage

1. Check cache size: monitor entry count
2. Reduce DefaultTtlMs for faster expiration
3. Lower ProbabilisticCleanupThreshold
4. Call CleanupCache() periodically
5. Consider caching smaller objects

Cache Stampede Still Occurring

1. Verify PreventCacheStampedeByDefault = true
2. Check you're not using CacheLoadBehavior.AllowParallelLoad
3. Ensure same key (entityId + type + subject) for related requests

Performance Issues

1. Avoid GetCachedItems in hot paths
2. Use appropriate InitialCapacity to reduce rehashing
3. Consider if recovery function is the bottleneck
4. Check if TTL is too short causing frequent reloads

Examples

See the documentation folder for more examples:

• API Reference
• Architecture Guide
• Performance Optimization
• Getting Started Tutorial

Contributing

Contributions are welcome! Please feel free to submit a Pull Request.

License

This project is licensed under the MIT License - see the LICENSE file for details.

Author

Russlan Kafri
Company: Digixoil

Support

For issues, questions, or suggestions:

• Open an issue on GitHub
• Check existing documentation in the /doc folder
• Review XML documentation in source code

Made with ❤️ by Digixoil
