SqlOM 1.0.2

SqlOM

Generate dynamic SQL queries using C# code only

💡 For AI Tools (Cursor AI, GitHub Copilot, etc.): This README contains comprehensive examples and documentation for using SqlOM. When coding with SqlOM, refer to this README file for complete API usage, examples, and best practices. All examples progress from simple to complex queries.

SqlOM is a software component which allows you to programmatically create SQL queries at runtime using a convenient .NET object model, thus creating an abstraction layer over SQL. Dynamic SQL generation is useful in several scenarios:

• Generate SQL dynamically when query structure is not known at development time (i.e. user defined reports or filters)
• Generate SQL dynamically when database structure is not known at development time (i.e. user defined tables or fields)
• Create a database independent data layer

SqlOM automates the process of SQL generation in a dynamic, convenient, time saving, database independent way.

Installation

Package Manager

Install-Package SqlOM

.NET CLI

dotnet add package SqlOM

PackageReference

<PackageReference Include="SqlOM" Version="1.0.2" />

Supported Databases

Currently the following databases are supported. We continuously add support for additional databases. If your database is not on the list, contact us or tweak the source code on your own to add the desired functionality.

• SQL Server
• Oracle
• MySQL
• MariaDB
• SQLite

Features

• ✅ Dynamic SQL query generation
• ✅ Database-agnostic query building
• ✅ Support for complex WHERE conditions
• ✅ Multiple JOIN types (INNER, LEFT, RIGHT, FULL, CROSS)
• ✅ CASE expressions
• ✅ UNION queries
• ✅ Paging support
• ✅ Parameterized queries
• ✅ Cross-Tabs (Pivot Tables)
• ✅ Modern C# 12 syntax support
• ✅ Multi-targets .NET 8.0 and .NET 9.0

Examples (Simple to Complex)

All examples use the following namespaces:

using Reeb.SqlOM;
using Reeb.SqlOM.Render;

1. Simple SELECT Query (Single Table)

The most basic query - selecting columns from a single table:

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("name"));
query.Columns.Add(new SelectColumn("email"));
query.FromClause.BaseTable = FromTerm.Table("customers");

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);
// Result: SELECT [name], [email] FROM [customers]

2. SELECT with WHERE Clause

Adding a simple WHERE condition:

FromTerm tCustomers = FromTerm.Table("customers", "c");

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("name", tCustomers));
query.Columns.Add(new SelectColumn("email", tCustomers));
query.FromClause.BaseTable = tCustomers;

query.WherePhrase.Terms.Add(WhereTerm.CreateCompare(
    SqlExpression.Field("name", tCustomers),
    SqlExpression.String("John"),
    CompareOperator.Equal));

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);
// Result: SELECT [c].[name], [c].[email] FROM [customers] [c] WHERE [c].[name] = 'John'

3. SELECT with ORDER BY

Adding sorting to your query:

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("name"));
query.Columns.Add(new SelectColumn("createdDate"));
query.FromClause.BaseTable = FromTerm.Table("customers");

query.OrderByTerms.Add(new OrderByTerm("name", OrderByDirection.Ascending));
query.OrderByTerms.Add(new OrderByTerm("createdDate", OrderByDirection.Descending));

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);
// Result: SELECT [name], [createdDate] FROM [customers] ORDER BY [name] asc, [createdDate] desc

4. SELECT with Multiple WHERE Conditions

Using AND/OR logic in WHERE clauses:

FromTerm tProducts = FromTerm.Table("products", "p");

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("name", tProducts));
query.Columns.Add(new SelectColumn("price", tProducts));
query.FromClause.BaseTable = tProducts;

// AND condition (default)
query.WherePhrase.Terms.Add(WhereTerm.CreateCompare(
    SqlExpression.Field("price", tProducts),
    SqlExpression.Number(10),
    CompareOperator.Greater));

query.WherePhrase.Terms.Add(WhereTerm.CreateCompare(
    SqlExpression.Field("price", tProducts),
    SqlExpression.Number(100),
    CompareOperator.Less));

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);
// Result: SELECT [p].[name], [p].[price] FROM [products] [p] WHERE ([p].[price] > 10 AND [p].[price] < 100)

5. Rendering Queries

After building your query, render it to SQL for your specific database:

SelectQuery query = new SelectQuery();
// ... configure query ...

// For SQL Server
string sql = new SqlServerRenderer().RenderSelect(query);

// For MySQL
string sql = new MySqlRenderer().RenderSelect(query);

// For Oracle
string sql = new OracleRenderer().RenderSelect(query);

// For SQLite
string sql = new SQLiteRenderer().RenderSelect(query);

6. Simple JOIN (Two Tables)

Joining two tables with a simple key relationship:

FromTerm tCustomers = FromTerm.Table("customers", "c");
FromTerm tOrders = FromTerm.Table("orders", "o");

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("name", tCustomers));
query.Columns.Add(new SelectColumn("orderDate", tOrders));
query.Columns.Add(new SelectColumn("total", tOrders));

query.FromClause.BaseTable = tCustomers;
query.FromClause.Join(JoinType.Inner, tCustomers, tOrders, "customerId", "customerId");

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);
// Result: SELECT [c].[name], [o].[orderDate], [o].[total] FROM [customers] [c] INNER JOIN [orders] [o] ON [c].[customerId] = [o].[customerId]

7. Multiple JOINs (Three or More Tables)

Joining multiple tables:

FromTerm tCustomers = FromTerm.Table("customers", "c");
FromTerm tOrders = FromTerm.Table("orders", "o");
FromTerm tOrderItems = FromTerm.Table("orderItems", "oi");
FromTerm tProducts = FromTerm.Table("products", "p");

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("name", tCustomers));
query.Columns.Add(new SelectColumn("orderDate", tOrders));
query.Columns.Add(new SelectColumn("productName", tProducts));
query.Columns.Add(new SelectColumn("quantity", tOrderItems));

query.FromClause.BaseTable = tCustomers;
query.FromClause.Join(JoinType.Left, tCustomers, tOrders, "customerId", "customerId");
query.FromClause.Join(JoinType.Inner, tOrders, tOrderItems, "orderId", "orderId");
query.FromClause.Join(JoinType.Inner, tOrderItems, tProducts, "productId", "productId");

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);

8. Complex WHERE Conditions

Using various comparison operators and logical groupings:

FromTerm tProducts = FromTerm.Table("products", "p");

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("name", tProducts));
query.Columns.Add(new SelectColumn("price", tProducts));
query.FromClause.BaseTable = tProducts;

// Simple comparison
query.WherePhrase.Terms.Add(WhereTerm.CreateCompare(
    SqlExpression.Field("name", tProducts),
    SqlExpression.String("John"),
    CompareOperator.Equal));

// BETWEEN clause
query.WherePhrase.Terms.Add(WhereTerm.CreateBetween(
    SqlExpression.Field("price", tProducts),
    SqlExpression.Number(1),
    SqlExpression.Number(100)));

// IN clause
query.WherePhrase.Terms.Add(WhereTerm.CreateIn(
    SqlExpression.Field("category", tProducts),
    SqlConstantCollection.FromList(new string[] {"Electronics", "Books", "Clothing"})));

// IS NULL
query.WherePhrase.Terms.Add(WhereTerm.CreateIsNull(SqlExpression.Field("deletedDate", tProducts)));

// OR group
WhereClause orGroup = new WhereClause(WhereClauseRelationship.Or);
orGroup.Terms.Add(WhereTerm.CreateCompare(
    SqlExpression.Field("status", tProducts),
    SqlExpression.String("Active"),
    CompareOperator.Equal));
orGroup.Terms.Add(WhereTerm.CreateCompare(
    SqlExpression.Field("status", tProducts),
    SqlExpression.String("Pending"),
    CompareOperator.Equal));
query.WherePhrase.SubClauses.Add(orGroup);

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);

9. Complex JOINs with Multiple Conditions

Joining tables with multiple join conditions:

FromTerm tOrders = FromTerm.Table("orders", "o");
FromTerm tOrderItems = FromTerm.Table("orderItems", "oi");

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("orderId", tOrders));
query.Columns.Add(new SelectColumn("itemId", tOrderItems));

query.FromClause.BaseTable = tOrders;

// Join with multiple conditions
query.FromClause.Join(JoinType.Left, tOrders, tOrderItems,
    new JoinCondition("orderId", "orderId"),
    new JoinCondition("customerId", "customerId"));

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);

10. JOINs with Custom WHERE Conditions

Using WHERE clauses for complex join conditions:

FromTerm tOrders = FromTerm.Table("orders", "o");
FromTerm tProducts = FromTerm.Table("products", "p");

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("orderId", tOrders));
query.Columns.Add(new SelectColumn("productName", tProducts));

query.FromClause.BaseTable = tOrders;

// Complex join condition using WHERE clause
WhereClause joinCondition = new WhereClause(WhereClauseRelationship.Or);
joinCondition.Terms.Add(WhereTerm.CreateCompare(
    SqlExpression.Field("productId", tOrders),
    SqlExpression.Field("productId", tProducts),
    CompareOperator.Equal));
joinCondition.Terms.Add(WhereTerm.CreateCompare(
    SqlExpression.Field("productName", tOrders),
    SqlExpression.Field("name", tProducts),
    CompareOperator.Equal));

query.FromClause.Join(JoinType.Left, tOrders, tProducts, joinCondition);

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);

11. Aggregations and GROUP BY

Using aggregate functions and grouping:

FromTerm tOrders = FromTerm.Table("orders", "o");

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("customerId", tOrders));
query.Columns.Add(new SelectColumn(
    SqlExpression.Function(SqlAggregationFunction.Sum, SqlExpression.Field("total", tOrders)),
    "totalAmount"));
query.Columns.Add(new SelectColumn(
    SqlExpression.Function(SqlAggregationFunction.Count, SqlExpression.Field("orderId", tOrders)),
    "orderCount"));

query.FromClause.BaseTable = tOrders;

query.GroupByTerms.Add(new GroupByTerm("customerId", tOrders));

query.OrderByTerms.Add(new OrderByTerm("totalAmount", OrderByDirection.Descending));

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);
// Result: SELECT [o].[customerId], SUM([o].[total]) [totalAmount], COUNT([o].[orderId]) [orderCount]
//         FROM [orders] [o] GROUP BY [o].[customerId] ORDER BY [totalAmount] desc

12. CASE Expressions

Using CASE statements in SELECT columns:

FromTerm tProducts = FromTerm.Table("products", "p");

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("name", tProducts));
query.Columns.Add(new SelectColumn("price", tProducts));

// Create CASE expression
CaseClause caseClause = new CaseClause();
caseClause.Terms.Add(new CaseTerm(
    WhereTerm.CreateCompare(SqlExpression.Field("price", tProducts), SqlExpression.Number(100), CompareOperator.Less),
    SqlExpression.String("Budget")));
caseClause.Terms.Add(new CaseTerm(
    WhereTerm.CreateCompare(SqlExpression.Field("price", tProducts), SqlExpression.Number(500), CompareOperator.Less),
    SqlExpression.String("Mid-Range")));
caseClause.ElseValue = SqlExpression.String("Premium");

query.Columns.Add(new SelectColumn(SqlExpression.Case(caseClause), "priceCategory"));

query.FromClause.BaseTable = tProducts;

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);

13. UNION Queries

Combining multiple SELECT queries:

SqlUnion union = new SqlUnion();

// First query
SelectQuery query1 = new SelectQuery();
query1.Columns.Add(new SelectColumn(SqlExpression.Raw("price * 10"), "priceX10"));
query1.FromClause.BaseTable = FromTerm.Table("products");
union.Add(query1);

// Second query
SelectQuery query2 = new SelectQuery();
query2.Columns.Add(new SelectColumn(SqlExpression.Field("price"), "priceX10"));
query2.FromClause.BaseTable = FromTerm.Table("products");
union.Add(query2, DistinctModifier.All);

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderUnion(union);
// Result: SELECT price * 10 [priceX10] FROM [products] UNION ALL SELECT [price] [priceX10] FROM [products]

14. Parameterized Queries

Using parameters for better performance and security:

FromTerm tCustomers = FromTerm.Table("customers");

SelectQuery query = new SelectQuery();
query.TableSpace = "MyDatabase.dbo"; // For execution plan caching
query.Columns.Add(new SelectColumn("name", tCustomers));
query.Columns.Add(new SelectColumn("email", tCustomers));
query.FromClause.BaseTable = tCustomers;

// Use parameters instead of literal values
query.WherePhrase.Terms.Add(WhereTerm.CreateCompare(
    SqlExpression.Parameter("@customerName"),
    SqlExpression.Field("name", tCustomers),
    CompareOperator.Equal));

query.WherePhrase.Terms.Add(WhereTerm.CreateCompare(
    SqlExpression.Field("age", tCustomers),
    SqlExpression.Parameter("@minAge"),
    CompareOperator.GreaterOrEqual));

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);

// Use with SqlCommand
SqlCommand command = new SqlCommand(sql, connection);
command.Parameters.Add("@customerName", SqlDbType.NVarChar).Value = "John";
command.Parameters.Add("@minAge", SqlDbType.Int).Value = 18;

15. Paging

Implementing pagination for large result sets:

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("name"));
query.Columns.Add(new SelectColumn("email"));
query.FromClause.BaseTable = FromTerm.Table("customers");

// ORDER BY is required for paging
query.OrderByTerms.Add(new OrderByTerm("name", OrderByDirection.Ascending));

SqlServerRenderer renderer = new SqlServerRenderer();

// First, get total row count
string rowCountSql = renderer.RenderRowCount(query);
int totalRows = (int)ExecuteScalar(rowCountSql);

// Then get paged results
int pageIndex = 0; // Zero-based
int pageSize = 10;
string sql = renderer.RenderPage(pageIndex, pageSize, totalRows, query);

16. Subqueries

Using subqueries in WHERE clauses:

FromTerm tCustomers = FromTerm.Table("customers", "c");

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("name", tCustomers));
query.Columns.Add(new SelectColumn("email", tCustomers));
query.FromClause.BaseTable = tCustomers;

// IN subquery
SelectQuery subQuery = new SelectQuery();
subQuery.Columns.Add(new SelectColumn("customerId"));
subQuery.FromClause.BaseTable = FromTerm.Table("orders");
subQuery.WherePhrase.Terms.Add(WhereTerm.CreateCompare(
    SqlExpression.Field("orderDate"),
    SqlExpression.Date(DateTime.Now.AddDays(-30)),
    CompareOperator.GreaterOrEqual));

query.WherePhrase.Terms.Add(WhereTerm.CreateIn(
    SqlExpression.Field("customerId", tCustomers),
    subQuery));

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);

17. EXISTS and NOT EXISTS

Using EXISTS clauses:

FromTerm tCustomers = FromTerm.Table("customers", "c");
FromTerm tOrders = FromTerm.Table("orders", "o");

SelectQuery query = new SelectQuery();
query.Columns.Add(new SelectColumn("name", tCustomers));
query.Columns.Add(new SelectColumn("email", tCustomers));
query.FromClause.BaseTable = tCustomers;

// EXISTS subquery
SelectQuery existsQuery = new SelectQuery();
existsQuery.Columns.Add(new SelectColumn("*"));
existsQuery.FromClause.BaseTable = tOrders;
existsQuery.WherePhrase.Terms.Add(WhereTerm.CreateCompare(
    SqlExpression.Field("customerId", tOrders),
    SqlExpression.Field("customerId", tCustomers),
    CompareOperator.Equal));

query.WherePhrase.Terms.Add(WhereTerm.CreateExists(existsQuery));

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(query);
// Result: SELECT [c].[name], [c].[email] FROM [customers] [c]
//         WHERE EXISTS (SELECT * FROM [orders] [o] WHERE [o].[customerId] = [c].[customerId])

18. Cross-Tabs (Pivot Tables) - Advanced

Creating dynamic pivot tables for reporting:

PivotTable pivot = new PivotTable();
pivot.BaseSql = "select * from orders";
pivot.Function = SqlAggregationFunction.Sum;
pivot.ValueField = "quantity";
pivot.RowField = "customerId";

// Date-based pivot column
PivotColumn pivotCol = new PivotColumn("date", SqlDataType.Date);
TimePeriod currentYear = TimePeriod.FromToday(TimePeriodType.Year);
pivotCol.Values.Add(PivotColumnValue.CreateRange("before2023",
    new Range(null, currentYear.Add(-1).PeriodStartDate)));
pivotCol.Values.Add(PivotColumnValue.CreateRange("y2023",
    new Range(currentYear.Add(-1).PeriodStartDate, currentYear.PeriodStartDate)));
pivotCol.Values.Add(PivotColumnValue.CreateRange("after2023",
    new Range(currentYear.PeriodStartDate, null)));
pivot.Columns.Add(pivotCol);

// Product-based pivot column
pivotCol = new PivotColumn("productId", SqlDataType.Number);
pivotCol.Values.Add(PivotColumnValue.CreateScalar("product1", 1));
pivotCol.Values.Add(PivotColumnValue.CreateScalar("product2", 2));
pivot.Columns.Add(pivotCol);

SelectQuery pivotQuery = pivot.BuildPivotSql();

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(pivotQuery);

19. Cross-Tab Drill-Down - Advanced

Drilling down into pivot table cells:

// Using the same pivot instance from example 18
SelectQuery drillDownQuery = pivot.BuildDrillDownSql(
    SqlConstant.Number(1), // customerId = 1
    "y2023"                // column name
);

SqlServerRenderer renderer = new SqlServerRenderer();
string sql = renderer.RenderSelect(drillDownQuery);

Requirements

• .NET 8.0 or later (.NET 8.0 and .NET 9.0 are supported)

License

See License.txt for license information.

Contributing

Contributions are welcome! If you find a bug or have a feature request, please open an issue on the project repository.

Version History

1.0.2

• Enhanced documentation with comprehensive examples
• Examples organized from simple to complex
• Added AI tool instruction note
• Improved README structure and clarity

1.0.1

• Initial release, originated from a former SourceForge project
• Modernized codebase with C# 12 features
• Multi-targets .NET 8.0 and .NET 9.0
• Improved nullable reference type support
• Enhanced code quality and performance
• File-scoped namespaces throughout
• Modern switch expressions
• Improved string handling and StringBuilder usage
• Better immutability with readonly modifiers
