<p align="center">Modern, high-performance, event-based TCP/WebSocket/SSL server library for .NET built on <b>System.IO.Pipelines</b>.</p>

Zero subclassing required. Subscribe to events, configure options, and go.

Contents

• Features
• Architecture
• Requirements
• Quick Start
• Examples
  • TCP Echo Server
  • WebSocket Chat Server
  • SSL/TLS Server
  • Message Framing
  • Session Management
  • Groups & Rooms
  • Middleware Pipeline
  • WebSocket Heartbeat & Dead Connection Detection
  • Backpressure & Buffer Limits
  • Full WebSocket Server with Admin Console
• Configuration Reference
  • ServerOptions
  • WebSocketOptions
  • SslOptions
• API Reference
  • ISession
  • WebSocketSession
  • SessionManager
  • SessionGroup
  • IConnectionMiddleware
  • Message Framers
  • WsMessage
• How It Works
  • Connection Lifecycle
  • Write Serialization
  • Backpressure
• Building
• Samples
• License

Features

• Event-based API - no subclassing, just server.OnDataReceived += handler
• TCP Server with optional message framing (raw, length-prefix, delimiter)
• WebSocket Server with full RFC 6455 compliance (text, binary, ping/pong, close status codes)
• SSL/TLS as a simple configuration option on any server
• System.IO.Pipelines for zero-copy I/O with built-in backpressure
• Automatic heartbeat with configurable ping interval and dead connection detection (missed pong counting)
• Session management - track, query, broadcast, and kick connections
• Groups/Rooms - named groups for targeted broadcast (chat rooms, game lobbies, etc.)
• Middleware pipeline - intercept connect, disconnect, data received, data sending, and errors
• Backpressure & buffer limits - configurable send/receive pipe limits prevent memory exhaustion
• Thread-safe writes - all PipeWriter access serialized via SemaphoreSlim (no frame corruption)
• Socket error handling - proper SocketError filtering (ConnectionReset, Abort, etc.)
• Multi-target: net6.0, net7.0, net8.0, net9.0, net10.0
• Zero dependencies beyond System.IO.Pipelines

Architecture

StormSocket is designed around a few core principles:

Requirements

• .NET 6.0 or later
• No native dependencies

Quick Start

dotnet add package StormSocket

using System.Net;
using StormSocket.Server;

var server = new StormTcpServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 5000),
});

server.OnDataReceived += async (session, data) =>
{
    await session.SendAsync(data); // echo
};

await server.StartAsync();
Console.ReadLine();
await server.DisposeAsync();

Examples

TCP Echo Server

The simplest possible server. Echoes back everything it receives.

using System.Net;
using StormSocket.Server;

var server = new StormTcpServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 5000),
    NoDelay = true,
});

server.OnConnected += async session =>
{
    Console.WriteLine($"[{session.Id}] Connected ({server.Sessions.Count} online)");
};

server.OnDisconnected += async session =>
{
    Console.WriteLine($"[{session.Id}] Disconnected");
};

server.OnDataReceived += async (session, data) =>
{
    Console.WriteLine($"[{session.Id}] {data.Length} bytes received");
    await session.SendAsync(data);
};

server.OnError += async (session, ex) =>
{
    Console.WriteLine($"[{session?.Id}] Error: {ex.Message}");
};

await server.StartAsync();
Console.WriteLine("TCP Echo listening on :5000");
Console.ReadLine();
await server.DisposeAsync();

Test with: telnet localhost 5000

WebSocket Chat Server

Broadcasts every message to all connected WebSocket clients.

using System.Net;
using StormSocket.Server;

var ws = new StormWebSocketServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 8080),
    WebSocket = new WebSocketOptions
    {
        PingInterval = TimeSpan.FromSeconds(15),
        MaxMissedPongs = 3,
    },
});

ws.OnConnected += async session =>
{
    Console.WriteLine($"[{session.Id}] WebSocket connected");
};

ws.OnMessageReceived += async (session, msg) =>
{
    if (msg.IsText)
    {
        Console.WriteLine($"[{session.Id}] {msg.Text}");
        // Broadcast to everyone except sender
        await ws.BroadcastTextAsync(msg.Text, excludeId: session.Id);
    }
};

await ws.StartAsync();
Console.WriteLine("WebSocket Chat listening on :8080");
Console.ReadLine();
await ws.DisposeAsync();

Test with: wscat -c ws://localhost:8080

SSL/TLS Server

Any server can be upgraded to SSL by adding SslOptions. No separate class needed.

using System.Net;
using System.Security.Cryptography.X509Certificates;
using StormSocket.Server;

var server = new StormTcpServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 5001),
    Ssl = new SslOptions
    {
        Certificate = X509CertificateLoader.LoadPkcs12FromFile("server.pfx", "password"),
    },
});

server.OnDataReceived += async (session, data) => await session.SendAsync(data);

await server.StartAsync();

Works the same with StormWebSocketServer for WSS (WebSocket Secure).

Message Framing

TCP is a stream protocol - it doesn't preserve message boundaries. StormSocket provides pluggable framers to solve this.

Length-Prefix Framer

Prepends a 4-byte big-endian length header to each message. Best for binary protocols.

var server = new StormTcpServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 5000),
    Framer = new LengthPrefixFramer(), // [4-byte length][payload]
});

server.OnDataReceived += async (session, data) =>
{
    // data is a complete message - no partial reads
    Console.WriteLine($"Complete message: {data.Length} bytes");
};

Delimiter Framer

Splits messages on a delimiter byte. Default is \n. Good for text protocols.

var server = new StormTcpServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 5000),
    Framer = new DelimiterFramer(), // splits on \n
});

Custom Framer

Implement IMessageFramer for your own protocol:

public interface IMessageFramer
{
    bool TryReadMessage(ref ReadOnlySequence<byte> buffer, out ReadOnlyMemory<byte> message);
    void WriteFrame(IBufferWriter<byte> writer, ReadOnlySpan<byte> payload);
}

Session Management

Every connection gets an ISession with a unique auto-incrementing ID.

// Get session count
int online = server.Sessions.Count;

// Find a session by ID
if (server.Sessions.TryGet(42, out ISession? session))
{
    Console.WriteLine($"Session #{session.Id}, uptime: {session.Metrics.Uptime}");
    Console.WriteLine($"Bytes sent: {session.Metrics.BytesSent}");
    Console.WriteLine($"Bytes received: {session.Metrics.BytesReceived}");
    Console.WriteLine($"Groups: {string.Join(", ", session.Groups)}");
}

// Broadcast to all
await server.BroadcastAsync(data);

// Broadcast excluding one
await server.BroadcastAsync(data, excludeId: senderId);

// Kick a session
await session.CloseAsync();

// Iterate all sessions
foreach (ISession s in server.Sessions.All)
{
    Console.WriteLine($"#{s.Id} - {s.State} - up {s.Metrics.Uptime:hh\\:mm\\:ss}");
}

WebSocket-specific methods

Cast to WebSocketSession for text frame support:

ws.OnMessageReceived += async (session, msg) =>
{
    if (session is WebSocketSession wss)
    {
        // Send text frame (UTF-8)
        await wss.SendTextAsync("Hello!");

        // Send pre-encoded UTF-8 bytes (zero-copy)
        byte[] utf8 = Encoding.UTF8.GetBytes("Hello!");
        await wss.SendTextAsync(utf8);

        // Send binary frame
        await wss.SendAsync(binaryData);
    }
};

Groups & Rooms

Built-in named groups for chat rooms, game lobbies, pub/sub channels, etc.

// Add session to a group
server.Groups.Add("room:general", session);
server.Groups.Add("room:vip", session);

// Broadcast to a group
await server.Groups.BroadcastAsync("room:general", data);

// Broadcast excluding sender
await server.Groups.BroadcastAsync("room:general", data, excludeId: session.Id);

// Remove from group
server.Groups.Remove("room:vip", session);

// Check member count
int count = server.Groups.MemberCount("room:general");

// List all groups
foreach (string name in server.Groups.GroupNames)
{
    Console.WriteLine($"{name}: {server.Groups.MemberCount(name)} members");
}

// Auto-cleanup on disconnect (call in OnDisconnected)
server.Groups.RemoveFromAll(session);

Middleware Pipeline

Intercept and modify data flow, log connections, implement rate limiting, authentication, etc.

public class AuthMiddleware : IConnectionMiddleware
{
    public ValueTask OnConnectedAsync(ISession session)
    {
        Console.WriteLine($"#{session.Id} connected");
        return ValueTask.CompletedTask;
    }

    public ValueTask<ReadOnlyMemory<byte>> OnDataReceivedAsync(ISession session, ReadOnlyMemory<byte> data)
    {
        // Return data to pass downstream, or ReadOnlyMemory<byte>.Empty to suppress
        if (!IsAuthenticated(session))
            return ValueTask.FromResult(ReadOnlyMemory<byte>.Empty); // drop message

        return ValueTask.FromResult(data);
    }

    public ValueTask OnDisconnectedAsync(ISession session)
    {
        // Called in reverse order (like middleware unwinding)
        return ValueTask.CompletedTask;
    }

    public ValueTask OnErrorAsync(ISession session, Exception exception)
    {
        Console.WriteLine($"#{session.Id} error: {exception.Message}");
        return ValueTask.CompletedTask;
    }
}

server.UseMiddleware(new AuthMiddleware());

All methods have default no-op implementations - override only what you need.

WebSocket Heartbeat & Dead Connection Detection

StormSocket automatically sends WebSocket Ping frames at a configurable interval and tracks Pong responses. If a client misses too many consecutive pongs, the connection is considered dead and automatically closed.

var ws = new StormWebSocketServer(new ServerOptions
{
    WebSocket = new WebSocketOptions
    {
        PingInterval = TimeSpan.FromSeconds(15),  // Send Ping every 15s
        MaxMissedPongs = 3,                        // Allow 3 missed Pongs
        AutoPong = true,                           // Auto-reply to client Pings
    },
});

How it works:

t=0s   : Connection established
t=15s  : Server sends Ping → missedPongs=1
t=17s  : Client sends Pong → missedPongs=0 (reset)
t=30s  : Server sends Ping → missedPongs=1
t=45s  : Server sends Ping → missedPongs=2 (client not responding)
t=60s  : Server sends Ping → missedPongs=3
t=75s  : missedPongs=4 > 3 → OnTimeout → connection closed

Backpressure & Buffer Limits

Pipe-level backpressure prevents memory exhaustion from slow consumers or fast producers.

var server = new StormTcpServer(new ServerOptions
{
    MaxPendingSendBytes = 1024 * 1024,     // 1 MB send buffer limit
    MaxPendingReceiveBytes = 1024 * 1024,  // 1 MB receive buffer limit
});

What happens when limits are reached:

• Send buffer full: SendAsync awaits until the socket drains pending data. No data loss, no crash - just backpressure.
• Receive buffer full: Socket reads pause until the application processes buffered messages. The OS TCP window handles flow control upstream.

Set to 0 for unlimited (not recommended for production).

Full WebSocket Server with Admin Console

See samples/StormSocket.Samples.WsServer for a complete example featuring:

• JSON command protocol (setName, chat, whisper, join/leave rooms, list users, etc.)
• Per-second heartbeat tick with timestamp broadcast to all clients
• Admin console with /sessions, /kick, /broadcast, /rooms, /info commands
• Middleware-based connection logging
• Session management with user names and room membership

dotnet run --project samples/StormSocket.Samples.WsServer

StormSocket WsServer running on ws://0.0.0.0:8080
/sessions  /kick <id>  /broadcast <msg>
/rooms     /info <id>  /stop

Configuration Reference

ServerOptions

WebSocketOptions

SslOptions

API Reference

ISession

public interface ISession : IAsyncDisposable
{
    long Id { get; }                      // Unique auto-incrementing ID
    ConnectionState State { get; }        // Connected, Closing, Closed
    ConnectionMetrics Metrics { get; }    // BytesSent, BytesReceived, Uptime
    IReadOnlySet<string> Groups { get; }  // Group memberships

    ValueTask SendAsync(ReadOnlyMemory<byte> data, CancellationToken ct = default);
    ValueTask CloseAsync(CancellationToken ct = default);
    void JoinGroup(string group);
    void LeaveGroup(string group);
}

WebSocketSession

Extends ISession with WebSocket-specific methods:

// Text frame from string
await session.SendTextAsync("Hello!");

// Text frame from pre-encoded UTF-8 (zero-copy)
await session.SendTextAsync(utf8Bytes);

// Binary frame
await session.SendAsync(binaryData);

// Close with status
await session.CloseAsync();

SessionManager

server.Sessions.Count;                              // Current count
server.Sessions.All;                                 // IEnumerable<ISession>
server.Sessions.TryGet(id, out ISession? session);   // Lookup by ID
server.Sessions.BroadcastAsync(data);                // Send to all
server.Sessions.CloseAllAsync();                     // Graceful shutdown

SessionGroup

server.Groups.Add("room", session);                  // Join
server.Groups.Remove("room", session);               // Leave
server.Groups.RemoveFromAll(session);                // Leave all (on disconnect)
server.Groups.BroadcastAsync("room", data);          // Send to room
server.Groups.MemberCount("room");                   // Count
server.Groups.GroupNames;                             // All room names

IConnectionMiddleware

public interface IConnectionMiddleware
{
    ValueTask OnConnectedAsync(ISession session);
    ValueTask<ReadOnlyMemory<byte>> OnDataReceivedAsync(ISession session, ReadOnlyMemory<byte> data);
    ValueTask<ReadOnlyMemory<byte>> OnDataSendingAsync(ISession session, ReadOnlyMemory<byte> data);
    ValueTask OnDisconnectedAsync(ISession session);  // Called in reverse order
    ValueTask OnErrorAsync(ISession session, Exception exception);
}

All methods have default no-op implementations.

Message Framers

WsMessage

public readonly struct WsMessage
{
    ReadOnlyMemory<byte> Data { get; }  // Raw payload
    bool IsText { get; }                // True = Text frame, False = Binary
    string Text { get; }                // UTF-8 decode (throws if !IsText)
}

How It Works

Connection Lifecycle

Client connects
    │
    ├─ Socket.AcceptAsync
    ├─ TcpTransport created (Pipe pair with backpressure limits)
    ├─ SSL handshake (if SslOptions configured)
    ├─ WebSocket HTTP upgrade (if StormWebSocketServer)
    ├─ Session created, added to SessionManager
    ├─ Middleware.OnConnectedAsync
    ├─ OnConnected event
    │
    ├─ Read loop (receives frames/data, dispatches events)
    ├─ Heartbeat loop (sends Pings, tracks Pongs) [concurrent]
    │
    ├─ Connection closes (client disconnect / timeout / kick)
    ├─ Middleware.OnDisconnectedAsync (reverse order)
    ├─ OnDisconnected event
    ├─ Session removed from SessionManager
    └─ Transport disposed

Write Serialization

All writes to a WebSocket connection are serialized through a per-session SemaphoreSlim:

session.SendTextAsync("hello")  ─┐
heartbeat ping                   ├─→ _writeLock → PipeWriter → Socket
auto-pong                        ─┘

This prevents frame interleaving when multiple sources write concurrently (user code, heartbeat timer, auto-pong handler).

Backpressure

StormSocket uses System.IO.Pipelines with configurable pauseWriterThreshold and resumeWriterThreshold:

[Socket] → ReceivePipe (1MB limit) → [Frame Decoder] → [Event Handler]
[Event Handler] → [Frame Encoder] → SendPipe (1MB limit) → [Socket]

When a pipe fills up:

• Receive pipe full: ReceiveAsync pauses → OS TCP window closes → sender slows down
• Send pipe full: FlushAsync awaits → caller waits → no memory growth

Resume happens at 50% of the threshold to avoid oscillation.

Building

git clone https://github.com/suleymanbyzt/StormSocket.git
cd StormSocket
dotnet build
dotnet test

Samples

dotnet run --project samples/StormSocket.Samples.TcpEcho
dotnet run --project samples/StormSocket.Samples.WsChat
dotnet run --project samples/StormSocket.Samples.SslEcho
dotnet run --project samples/StormSocket.Samples.WsServer

License

MIT License - see LICENSE for details.
