StormSocket 1.0.0

<p align="center"> <img src="assets/stormsocket.png" alt="StormSocket" width="256" /> </p>

<h1 align="center">StormSocket</h1>

<p align="center"> <a href="LICENSE"><img src="https://img.shields.io/badge/License-MIT-green.svg" alt="License" /></a> <a href="https://www.nuget.org/packages/StormSocket"><img src="https://img.shields.io/nuget/v/StormSocket.svg" alt="NuGet" /></a> <img src="https://img.shields.io/badge/.NET-6.0%20|%207.0%20|%208.0%20|%209.0%20|%2010.0-blue" alt=".NET" /> </p>

<p align="center">Modern, high-performance, event-based TCP/WebSocket/SSL library for .NET built on <b>System.IO.Pipelines</b>.</p>

Zero subclassing required. Subscribe to events, configure options, and go. Server and client included.

Why StormSocket?

Most .NET networking libraries use raw byte arrays with manual buffer management, and force you to subclass a base session class. StormSocket takes a different approach:

• Pooled, allocation-free I/O — System.IO.Pipelines manages buffer pools internally. Socket writes directly into the pipe's memory, your handler reads from the same buffer — no intermediate copies, no new byte[] per read, minimal GC pressure under load
• Backpressure that actually works — each pipe has configurable size thresholds. When a consumer falls behind, writes pause automatically. The OS TCP window propagates this upstream to the sender. No unbounded memory growth, no OOM crashes
• Slow consumer isolation — every session gets its own dedicated pipe pair (receive + send). During broadcast, each session's send runs concurrently. If one client's send buffer is full, SlowConsumerPolicy handles it per-session (Drop the message, Disconnect the client, or Wait) — the other 99,999 sessions are completely unaffected. See Slow Consumer Detection for details
• Subscribe, don't subclass — server.OnDataReceived += handler, no inheritance chains
• SSL is a config flag — same server, add SslOptions, done. No separate SslServer class
• Middleware pipeline — rate limiting, auth, logging as composable plugins
• Built-in pub/sub — named groups for chat rooms, game lobbies, ticker feeds

Contents

• Why StormSocket?
• Features
• Architecture
• Benchmarks
• Requirements
• Quick Start
• Examples
  • TCP Echo Server
  • WebSocket Chat Server
  • WebSocket Authentication
  • SSL/TLS Server
  • TCP Client
  • WebSocket Client
  • Message Framing
  • Session Management
  • Groups & Rooms
  • Middleware Pipeline
  • WebSocket Heartbeat & Dead Connection Detection
  • Slow Consumer Detection
  • Rate Limiting
  • Closing Connections: CloseAsync vs Abort
  • Backpressure & Buffer Limits
  • Full WebSocket Server with Admin Console
• Configuration Reference
  • ServerOptions
  • ClientOptions
  • WsClientOptions
  • WebSocketOptions
  • SocketTuningOptions
  • HeartbeatOptions
  • ReconnectOptions
  • SslOptions
• API Reference
  • ISession
  • WebSocketSession
  • SessionManager
  • SessionGroup
  • StormTcpClient
  • StormWebSocketClient
  • IConnectionMiddleware
  • Message Framers
  • WsMessage
• How It Works
  • Connection Lifecycle
  • Write Serialization
  • Backpressure
• Building
• Samples
• License

Features

• Event-based API - no subclassing, just server.OnDataReceived += handler
• TCP Server & Client with optional message framing (raw, length-prefix, delimiter)
• WebSocket Server & Client with full RFC 6455 compliance (text, binary, ping/pong, close, client-side masking)
• SSL/TLS as a simple configuration option on any server or client
• Auto-reconnect - clients automatically reconnect on disconnect with configurable delay and max attempts
• System.IO.Pipelines for zero-copy I/O with built-in backpressure
• Automatic heartbeat with configurable ping interval and dead connection detection (missed pong counting)
• Session management - track, query, broadcast, and kick connections
• Groups/Rooms - named groups for targeted broadcast (chat rooms, game lobbies, etc.)
• WebSocket authentication - access path, query params, headers (cookies, tokens) before accepting connections via OnConnecting event
• Rate limiting middleware - opt-in per-session or per-IP rate limiting with configurable window, action (disconnect/drop), and exceeded event
• Middleware pipeline - intercept connect, disconnect, data received, data sending, and errors (works on both server and client)
• Backpressure & buffer limits - configurable send/receive pipe limits prevent memory exhaustion
• Slow consumer detection - SlowConsumerPolicy per session: Wait (block), Drop (skip), or Disconnect (close). Applied to both broadcast and individual sends
• Concurrent broadcast - sends to all sessions in parallel, one slow client never blocks others
• Max connections - configurable limit, excess connections are immediately rejected
• Thread-safe writes - all PipeWriter access serialized via SemaphoreSlim (no frame corruption)
• TCP Keep-Alive - enabled by default, prevents idle connections from being silently dropped by firewalls and NATs
• Connection timeout - configurable timeout for client connections
• Handshake timeout - configurable timeout for WebSocket upgrade, closes idle TCP connections that never send an upgrade request (DoS protection)
• Socket error handling - proper SocketError filtering (ConnectionReset, Abort, etc.)
• Multi-target: net6.0, net7.0, net8.0, net9.0, net10.0
• Zero dependencies beyond System.IO.Pipelines

Architecture

StormSocket is designed around a few core principles:

Principle	How
Composition over inheritance	Flat structure, no deep inheritance chains. WebSocket doesn't inherit from HTTP.
System.IO.Pipelines	Zero-copy I/O with kernel-level backpressure, not custom Buffer classes.
Event-based API	Subscribe to events, no need to subclass TcpSession or override methods.
SSL as decorator	Same server, just add SslOptions. No separate SslServer class.
Integer session IDs	Interlocked.Increment (fast, sortable) instead of Guid.
Write serialization	All writes go through a per-session SemaphoreSlim lock - heartbeat pings, auto-pong, user sends, close frames never corrupt each other.

Benchmarks

Echo round-trip benchmark: 100 concurrent clients, 32-byte messages, 10-second sustained load.

Benchmark methodology and client/server structure inspired by NetCoreServer — a mature, battle-tested networking library that has been in active development for years. We use it as our reference point and recommend checking it out if you need a proven, stable solution.

StormSocket is newer and still evolving, but is designed to be production-ready from day one.

TCP Echo

Metric	StormSocket	NetCoreServer
Throughput	342 MiB/s	73 MiB/s
Messages/sec	11,205,120	2,386,789
Latency	89 ns	418 ns

WebSocket Echo

Metric	StormSocket	NetCoreServer
Throughput	66 MiB/s	40 MiB/s
Messages/sec	2,163,373	1,309,842
Latency	462 ns	763 ns

Results will vary by hardware, OS, and .NET version. Benchmark projects are included under benchmark/ — run them yourself to verify on your own setup.

Reproduce

# Terminal 1: Start server
dotnet run -c Release --project benchmark/StormSocket.Benchmark.TcpEchoServer

# Terminal 2: Run client
dotnet run -c Release --project benchmark/StormSocket.Benchmark.TcpEchoClient -- -c 100 -m 1000 -s 32 -z 10

Replace TcpEcho with WsEcho for WebSocket benchmarks.

Requirements

• .NET 6.0 or later
• No native dependencies

Quick Start

dotnet add package StormSocket

using System.Net;
using StormSocket.Server;

var server = new StormTcpServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 5000),
});

server.OnDataReceived += async (session, data) =>
{
    await session.SendAsync(data); // echo
};

await server.StartAsync();
Console.ReadLine();
await server.DisposeAsync();

Examples

TCP Echo Server

The simplest possible server. Echoes back everything it receives.

using System.Net;
using StormSocket.Server;

var server = new StormTcpServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 5000),
    Socket = new SocketTuningOptions { NoDelay = true },
});

server.OnConnected += async session =>
{
    Console.WriteLine($"[{session.Id}] Connected ({server.Sessions.Count} online)");
};

server.OnDisconnected += async session =>
{
    Console.WriteLine($"[{session.Id}] Disconnected");
};

server.OnDataReceived += async (session, data) =>
{
    Console.WriteLine($"[{session.Id}] {data.Length} bytes received");
    await session.SendAsync(data);
};

server.OnError += async (session, ex) =>
{
    Console.WriteLine($"[{session?.Id}] Error: {ex.Message}");
};

await server.StartAsync();
Console.WriteLine("TCP Echo listening on :5000");
Console.ReadLine();
await server.DisposeAsync();

Test with: telnet localhost 5000

WebSocket Chat Server

Broadcasts every message to all connected WebSocket clients.

using System.Net;
using StormSocket.Server;

var ws = new StormWebSocketServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 8080),
    WebSocket = new WebSocketOptions
    {
        Heartbeat = new HeartbeatOptions
        {
            PingInterval = TimeSpan.FromSeconds(15),
            MaxMissedPongs = 3,
        },
    },
});

ws.OnConnected += async session =>
{
    Console.WriteLine($"[{session.Id}] WebSocket connected");
};

ws.OnMessageReceived += async (session, msg) =>
{
    if (msg.IsText)
    {
        Console.WriteLine($"[{session.Id}] {msg.Text}");
        // Broadcast to everyone except sender
        await ws.BroadcastTextAsync(msg.Text, excludeId: session.Id);
    }
};

await ws.StartAsync();
Console.WriteLine("WebSocket Chat listening on :8080");
Console.ReadLine();
await ws.DisposeAsync();

Test with: wscat -c ws://localhost:8080

WebSocket Authentication

Authenticate clients before accepting WebSocket connections using OnConnecting. Access headers, cookies, query params, and path from the HTTP upgrade request.

using System.Net;
using StormSocket.Server;

var ws = new StormWebSocketServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 8080),
});

ws.OnConnecting += async (context) =>
{
    // access request details
    Console.WriteLine($"Path: {context.Path}");                    // "/chat"
    Console.WriteLine($"Query: {context.Query["room"]}");          // "general"
    Console.WriteLine($"Remote: {context.RemoteEndPoint}");        // "192.168.1.5:54321"

    // check authorization header
    string? token = context.Headers.GetValueOrDefault("Authorization");
    if (string.IsNullOrEmpty(token) || !IsValidToken(token))
    {
        context.Reject(401, "Invalid or missing token");
        return;
    }

    // check origin for browser clients
    // or you can use allowedorigins in options
    string? origin = context.Headers.GetValueOrDefault("Origin");
    if (origin != "https://myapp.com")
    {
        context.Reject(403, "Origin not allowed");
        return;
    }

    context.Accept();
};

ws.OnConnected += async session =>
{
    Console.WriteLine($"Authenticated client connected: #{session.Id}");
};

await ws.StartAsync();

If no OnConnecting handler is registered, all connections are auto-accepted (backwards compatible).

SSL/TLS Server

Any server can be upgraded to SSL by adding SslOptions. No separate class needed.

using System.Net;
using System.Security.Cryptography.X509Certificates;
using StormSocket.Server;

var server = new StormTcpServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 5001),
    Ssl = new SslOptions
    {
        Certificate = X509CertificateLoader.LoadPkcs12FromFile("server.pfx", "password"),
    },
});

server.OnDataReceived += async (session, data) => await session.SendAsync(data);

await server.StartAsync();

Works the same with StormWebSocketServer for WSS (WebSocket Secure).

TCP Client

Connect to a TCP server with auto-reconnect, framing, and middleware support.

using System.Net;
using System.Text;
using StormSocket.Client;

var client = new StormTcpClient(new ClientOptions
{
    EndPoint = new IPEndPoint(IPAddress.Loopback, 5000),
    Socket = new SocketTuningOptions { NoDelay = true },
    Reconnect = new ReconnectOptions { Enabled = true, Delay = TimeSpan.FromSeconds(2) },
});

client.OnConnected += async () =>
{
    Console.WriteLine("Connected to server!");
};

client.OnDataReceived += async data =>
{
    Console.WriteLine($"Received: {Encoding.UTF8.GetString(data.Span)}");
};

client.OnDisconnected += async () =>
{
    Console.WriteLine("Disconnected from server");
};

client.OnReconnecting += async (attempt, delay) =>
{
    Console.WriteLine($"Reconnecting (attempt #{attempt})...");
};

await client.ConnectAsync();
await client.SendAsync(Encoding.UTF8.GetBytes("Hello Server!"));

Use the same IMessageFramer on both server and client for message boundaries:

var framer = new LengthPrefixFramer();

// Server
var server = new StormTcpServer(new ServerOptions { Framer = framer });

// Client
var client = new StormTcpClient(new ClientOptions { Framer = framer });

WebSocket Client

Connect to any WebSocket server with automatic masking, heartbeat, and reconnect.

using StormSocket.Client;

var ws = new StormWebSocketClient(new WsClientOptions
{
    Uri = new Uri("ws://localhost:8080/chat"),
    Reconnect = new ReconnectOptions { Enabled = true },
    Heartbeat = new HeartbeatOptions { PingInterval = TimeSpan.FromSeconds(15) },
});

ws.OnConnected += async () =>
{
    Console.WriteLine("WebSocket connected!");
    await ws.SendTextAsync("Hello from StormSocket!");
};

ws.OnMessageReceived += async msg =>
{
    if (msg.IsText)
        Console.WriteLine($"Server says: {msg.Text}");
    else
        Console.WriteLine($"Binary data: {msg.Data.Length} bytes");
};

ws.OnDisconnected += async () =>
{
    Console.WriteLine("WebSocket disconnected");
};

await ws.ConnectAsync();

For WSS (WebSocket Secure), use the wss:// scheme:

var ws = new StormWebSocketClient(new WsClientOptions
{
    Uri = new Uri("wss://echo.websocket.org"),
});

Send custom HTTP headers during the upgrade handshake:

var ws = new StormWebSocketClient(new WsClientOptions
{
    Uri = new Uri("ws://localhost:8080"),
    Headers = new Dictionary<string, string>
    {
        { "Authorization", "Bearer my-token" },
    },
});

Message Framing

TCP is a stream protocol - it doesn't preserve message boundaries. StormSocket provides pluggable framers to solve this.

Length-Prefix Framer

Prepends a 4-byte big-endian length header to each message. Best for binary protocols.

var server = new StormTcpServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 5000),
    Framer = new LengthPrefixFramer(), // [4-byte length][payload]
});

server.OnDataReceived += async (session, data) =>
{
    // data is a complete message - no partial reads
    Console.WriteLine($"Complete message: {data.Length} bytes");
};

Delimiter Framer

Splits messages on a delimiter byte. Default is \n. Good for text protocols.

var server = new StormTcpServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 5000),
    Framer = new DelimiterFramer(), // splits on \n
});

Custom Framer

Implement IMessageFramer for your own protocol:

public interface IMessageFramer
{
    bool TryReadMessage(ref ReadOnlySequence<byte> buffer, out ReadOnlyMemory<byte> message);
    void WriteFrame(IBufferWriter<byte> writer, ReadOnlySpan<byte> payload);
}

Session Management

Every connection gets an ISession with a unique auto-incrementing ID.

// Get session count
int online = server.Sessions.Count;

// Find a session by ID
if (server.Sessions.TryGet(42, out ISession? session))
{
    Console.WriteLine($"Session #{session.Id}, uptime: {session.Metrics.Uptime}");
    Console.WriteLine($"Bytes sent: {session.Metrics.BytesSent}");
    Console.WriteLine($"Bytes received: {session.Metrics.BytesReceived}");
    Console.WriteLine($"Groups: {string.Join(", ", session.Groups)}");
}

// Broadcast to all
await server.BroadcastAsync(data);

// Broadcast excluding one
await server.BroadcastAsync(data, excludeId: senderId);

// Kick a session
await session.CloseAsync();

// Iterate all sessions
foreach (ISession s in server.Sessions.All)
{
    Console.WriteLine($"#{s.Id} - {s.State} - up {s.Metrics.Uptime:hh\\:mm\\:ss}");
}

WebSocket-specific methods

Cast to WebSocketSession for text frame support:

ws.OnMessageReceived += async (session, msg) =>
{
    if (session is WebSocketSession wss)
    {
        // Send text frame (UTF-8)
        await wss.SendTextAsync("Hello!");

        // Send pre-encoded UTF-8 bytes (zero-copy)
        byte[] utf8 = Encoding.UTF8.GetBytes("Hello!");
        await wss.SendTextAsync(utf8);

        // Send binary frame
        await wss.SendAsync(binaryData);
    }
};

Groups & Rooms

Built-in named groups for chat rooms, game lobbies, pub/sub channels, etc.

// Add session to a group
server.Groups.Add("room:general", session);
server.Groups.Add("room:vip", session);

// Broadcast to a group
await server.Groups.BroadcastAsync("room:general", data);

// Broadcast excluding sender
await server.Groups.BroadcastAsync("room:general", data, excludeId: session.Id);

// Remove from group
server.Groups.Remove("room:vip", session);

// Check member count
int count = server.Groups.MemberCount("room:general");

// List all groups
foreach (string name in server.Groups.GroupNames)
{
    Console.WriteLine($"{name}: {server.Groups.MemberCount(name)} members");
}

// Auto-cleanup on disconnect (call in OnDisconnected)
server.Groups.RemoveFromAll(session);

Middleware Pipeline

Intercept and modify data flow, log connections, implement rate limiting, authentication, etc.

public class AuthMiddleware : IConnectionMiddleware
{
    public ValueTask OnConnectedAsync(ISession session)
    {
        Console.WriteLine($"#{session.Id} connected");
        return ValueTask.CompletedTask;
    }

    public ValueTask<ReadOnlyMemory<byte>> OnDataReceivedAsync(ISession session, ReadOnlyMemory<byte> data)
    {
        // Return data to pass downstream, or ReadOnlyMemory<byte>.Empty to suppress
        if (!IsAuthenticated(session))
            return ValueTask.FromResult(ReadOnlyMemory<byte>.Empty); // drop message

        return ValueTask.FromResult(data);
    }

    public ValueTask OnDisconnectedAsync(ISession session)
    {
        // Called in reverse order (like middleware unwinding)
        return ValueTask.CompletedTask;
    }

    public ValueTask OnErrorAsync(ISession session, Exception exception)
    {
        Console.WriteLine($"#{session.Id} error: {exception.Message}");
        return ValueTask.CompletedTask;
    }
}

server.UseMiddleware(new AuthMiddleware());

All methods have default no-op implementations - override only what you need.

WebSocket Heartbeat & Dead Connection Detection

StormSocket automatically sends WebSocket Ping frames at a configurable interval and tracks Pong responses. If a client misses too many consecutive pongs, the connection is considered dead and automatically closed.

var ws = new StormWebSocketServer(new ServerOptions
{
    WebSocket = new WebSocketOptions
    {
        Heartbeat = new HeartbeatOptions
        {
            PingInterval = TimeSpan.FromSeconds(15),  // Send Ping every 15s
            MaxMissedPongs = 3,                        // Allow 3 missed Pongs
            AutoPong = true,                           // Auto-reply to client Pings
        },
    },
});

How it works:

t=0s   : Connection established
t=15s  : Server sends Ping → missedPongs=1
t=17s  : Client sends Pong → missedPongs=0 (reset)
t=30s  : Server sends Ping → missedPongs=1
t=45s  : Server sends Ping → missedPongs=2 (client not responding)
t=60s  : Server sends Ping → missedPongs=3
t=75s  : missedPongs=4 > 3 → OnTimeout → connection closed

Slow Consumer Detection

When broadcasting to thousands of clients, one slow client can stall delivery to everyone else. SlowConsumerPolicy solves this at the session level - it applies to both broadcast and individual sends.

using StormSocket.Core;

var server = new StormWebSocketServer(new ServerOptions
{
    EndPoint = new IPEndPoint(IPAddress.Any, 8080),
    MaxConnections = 50_000,
    SlowConsumerPolicy = SlowConsumerPolicy.Drop,
});

Policy	Behavior	Use Case
Wait	Awaits until pipe drains (default)	Reliable delivery, low client count
Drop	Silently skips backpressured sessions	Real-time data where stale data is useless (chat, game state, stock tickers)
Disconnect	Closes backpressured sessions	Critical feeds where all clients must keep up (financial data, command streams)

The policy is enforced inside SendAsync / SendTextAsync, so it works everywhere:

// Individual send - policy applies
await session.SendAsync(data);

// Broadcast - policy applies per session, sends are concurrent
await server.BroadcastAsync(data);
await ws.BroadcastTextAsync("update");

// Check if a session is under pressure
if (session.IsBackpressured)
{
    Console.WriteLine($"Session #{session.Id} is slow");
}

How it works with 1M clients:

Broadcast("data") called
    │
    ├─ Session #1: not backpressured → send (concurrent)
    ├─ Session #2: backpressured + Drop → skip
    ├─ Session #3: not backpressured → send (concurrent)
    ├─ Session #4: backpressured + Disconnect → close + skip
    └─ ... all sessions checked in parallel

All broadcast sends are dispatched concurrently. Each session has its own pipe, so one slow flush never blocks others.

Max Connections

Limit concurrent connections. Excess connections are rejected at the TCP level (socket closed immediately before any handshake).

var server = new StormTcpServer(new ServerOptions
{
    MaxConnections = 10_000, // 0 = unlimited (default)
});

Rate Limiting

Built-in opt-in middleware that limits incoming messages per client within a configurable time window. Protects the server from misbehaving or malicious clients.

using StormSocket.Middleware.RateLimiting;

var rateLimiter = new RateLimitMiddleware(new RateLimitOptions
{
    Window = TimeSpan.FromSeconds(10),   // Time window
    MaxMessages = 500,                   // Max messages per window
    Scope = RateLimitScope.Session,      // Per session (default) or per IP
    ExceededAction = RateLimitAction.Disconnect, // Disconnect (default) or Drop
});

rateLimiter.OnExceeded += async (session) =>
{
    Console.WriteLine($"Rate limit exceeded: #{session.Id} ({session.RemoteEndPoint})");
};

server.UseMiddleware(rateLimiter);

Option	Values	Description
Window	TimeSpan	Time window for counting messages (default: 1 second)
MaxMessages	int	Max messages allowed within the window (default: 100)
Scope	Session, IpAddress	Per-session counters (default) or shared per IP
ExceededAction	Disconnect, Drop	Abort the connection (default) or silently drop the message

Scope options:

• Session (default): Each session has its own independent counter. Safe and predictable.
• IpAddress: All sessions from the same IP share a single counter. Useful against distributed abuse from a single source. Note: clients behind NAT share an IP, so set limits accordingly.

Action options:

• Disconnect (default): Calls session.Abort() to immediately terminate the connection. Best for untrusted clients.
• Drop: Silently discards the message but keeps the connection open. Useful for trusted clients that occasionally burst.

The OnExceeded event fires on every rate limit hit (regardless of action), so you can log, monitor, or send a warning before the action is taken.

Note: Disconnect uses Abort() (immediate TCP close) rather than CloseAsync() (graceful WebSocket Close frame). This is intentional — a client flooding the server may not process a Close frame, causing the same blocking issue that Abort() was designed to solve. If you need a more nuanced approach, use Drop action with the OnExceeded event to handle it yourself.

Using .NET's built-in rate limiting? The IConnectionMiddleware interface is your extension point — you can create your own middleware wrapping System.Threading.RateLimiting (TokenBucketRateLimiter, SlidingWindowRateLimiter, etc.) without any extra dependencies from StormSocket.

Closing Connections: CloseAsync vs Abort

StormSocket provides two ways to close a connection:

Method	Behavior
CloseAsync()	Graceful: Sends a WebSocket Close frame (if WS), waits for flush, then closes the socket. Safe and clean, but can block if the client is slow.
Abort()	Immediate: Closes the socket directly without sending anything. All pending reads and writes are cancelled. The client sees a connection reset.

When to use Abort:

If a client is so slow that it can't even process a Close frame, CloseAsync() will block waiting for the flush to complete. This is the exact scenario you encounter with slow consumers in production — the client's receive buffer is full, your Close frame sits in the send pipe, and the connection stays open indefinitely.

Abort() skips the Close frame entirely and terminates the socket immediately. The server's read loop breaks, OnDisconnected fires, and the session is cleaned up.

// Graceful close - sends Close frame, waits for flush
await session.CloseAsync();

// Immediate termination - no Close frame, no waiting
session.Abort();

// Common pattern: try graceful, fall back to abort
using var cts = new CancellationTokenSource(TimeSpan.FromSeconds(5));
try
{
    await session.CloseAsync(cts.Token);
}
catch (OperationCanceledException)
{
    session.Abort(); // client didn't close in time
}

SlowConsumerPolicy.Disconnect uses Abort() internally — when backpressure is detected, the socket is killed immediately without attempting a graceful close.

Backpressure & Buffer Limits

Pipe-level backpressure prevents memory exhaustion from slow consumers or fast producers.

var server = new StormTcpServer(new ServerOptions
{
    Socket = new SocketTuningOptions
    {
        MaxPendingSendBytes = 1024 * 1024,     // 1 MB send buffer limit
        MaxPendingReceiveBytes = 1024 * 1024,  // 1 MB receive buffer limit
    },
});

What happens when limits are reached:

• Send buffer full: Behavior depends on SlowConsumerPolicy:
  • Wait (default): SendAsync awaits until the socket drains pending data
  • Drop: SendAsync returns immediately, message is silently discarded
  • Disconnect: Session is closed automatically
• Receive buffer full: Socket reads pause until the application processes buffered messages. The OS TCP window handles flow control upstream.

Set to 0 for unlimited (not recommended for production).

Full WebSocket Server with Admin Console

See samples/StormSocket.Samples.WsServer for a complete example featuring:

• JSON command protocol (setName, chat, whisper, join/leave rooms, list users, etc.)
• Per-second heartbeat tick with timestamp broadcast to all clients
• Admin console with /sessions, /kick, /broadcast, /rooms, /info commands
• Middleware-based connection logging
• Session management with user names and room membership

dotnet run --project samples/StormSocket.Samples.WsServer

StormSocket WsServer running on ws://0.0.0.0:8080
/sessions  /kick <id>  /broadcast <msg>
/rooms     /info <id>  /stop

Configuration Reference

ServerOptions

Property	Type	Default	Description
EndPoint	IPEndPoint	0.0.0.0:5000	IP and port to listen on
Backlog	int	128	Maximum pending connection queue
DualMode	bool	false	Accept both IPv4 and IPv6 on a single port
ReceiveBufferSize	int	65536	OS socket receive buffer (bytes)
SendBufferSize	int	65536	OS socket send buffer (bytes)
MaxConnections	int	0	Max concurrent connections (0 = unlimited). Excess are rejected at TCP level
SlowConsumerPolicy	SlowConsumerPolicy	Wait	Behavior when a session is backpressured: Wait, Drop, or Disconnect
Ssl	SslOptions?	null	SSL/TLS configuration (null = plain TCP)
WebSocket	WebSocketOptions?	null	WebSocket settings (only for StormWebSocketServer)
Framer	IMessageFramer?	null	Message framing strategy (null = raw bytes)
Socket	SocketTuningOptions	new()	Low-level TCP socket tuning (NoDelay, KeepAlive, backpressure limits)

WebSocketOptions

Property	Type	Default	Description
MaxFrameSize	int	1048576	Maximum frame payload (bytes). Oversized frames trigger close with MessageTooBig
AllowedOrigins	IReadOnlyList<string>?	null	Allowed origins for CSWSH protection (RFC 6455 #10.2). null = allow all
HandshakeTimeout	TimeSpan	5s	Max time for client to complete WebSocket upgrade after TCP connect. Prevents DoS via idle connections
Heartbeat	HeartbeatOptions	new()	Ping/pong heartbeat and dead connection detection settings

ClientOptions

Property	Type	Default	Description
EndPoint	IPEndPoint	127.0.0.1:5000	Server endpoint to connect to
Ssl	ClientSslOptions?	null	SSL/TLS configuration
Framer	IMessageFramer?	null	Message framing strategy
ConnectTimeout	TimeSpan	10s	Connection timeout
Socket	SocketTuningOptions	new()	Low-level TCP socket tuning (NoDelay, KeepAlive, backpressure limits)
Reconnect	ReconnectOptions	new()	Auto-reconnect settings

WsClientOptions

Property	Type	Default	Description
Uri	Uri	ws://localhost:8080	WebSocket URI (ws:// or wss://)
ConnectTimeout	TimeSpan	10s	Connection timeout
MaxFrameSize	int	1048576	Maximum frame payload (bytes)
Headers	Dictionary<string, string>?	null	Extra HTTP headers for upgrade
Ssl	ClientSslOptions?	null	SSL/TLS configuration
Socket	SocketTuningOptions	new()	Low-level TCP socket tuning (NoDelay, KeepAlive, backpressure limits)
Heartbeat	HeartbeatOptions	new()	Ping/pong heartbeat and dead connection detection settings
Reconnect	ReconnectOptions	new()	Auto-reconnect settings

SocketTuningOptions

Shared by ServerOptions, ClientOptions, and WsClientOptions.

Property	Type	Default	Description
NoDelay	bool	false	Disable Nagle's algorithm for lower latency
KeepAlive	bool	true	Enable TCP Keep-Alive to prevent idle connections from being dropped by firewalls/NATs
MaxPendingSendBytes	long	1048576	Max bytes buffered before send backpressure (0 = unlimited)
MaxPendingReceiveBytes	long	1048576	Max bytes buffered before receive backpressure (0 = unlimited)

HeartbeatOptions

Shared by WebSocketOptions (server) and WsClientOptions (client).

Property	Type	Default	Description
PingInterval	TimeSpan	30s	Interval between Ping frames (TimeSpan.Zero = disabled)
MaxMissedPongs	int	3	Consecutive missed Pongs before closing
AutoPong	bool	true	Automatically reply to incoming Ping frames with a Pong

ReconnectOptions

Shared by ClientOptions and WsClientOptions.

Property	Type	Default	Description
Enabled	bool	false	Enable automatic reconnection on disconnect
Delay	TimeSpan	2s	Delay between reconnect attempts
MaxAttempts	int	0	Max reconnection attempts (0 = unlimited)

SslOptions

Property	Type	Default	Description
Certificate	X509Certificate2	(required)	Server certificate
Protocols	SslProtocols	Tls12 \| Tls13	Allowed TLS protocol versions
ClientCertificateRequired	bool	false	Require client certificate

API Reference

ISession

public interface ISession : IAsyncDisposable
{
    long Id { get; }                      // Unique auto-incrementing ID
    ConnectionState State { get; }        // Connected, Closing, Closed
    ConnectionMetrics Metrics { get; }    // BytesSent, BytesReceived, Uptime
    bool IsBackpressured { get; }         // True when send buffer is full
    IReadOnlySet<string> Groups { get; }  // Group memberships

    ValueTask SendAsync(ReadOnlyMemory<byte> data, CancellationToken ct = default);
    ValueTask CloseAsync(CancellationToken ct = default);
    void Abort();
    void JoinGroup(string group);
    void LeaveGroup(string group);
}

WebSocketSession

Extends ISession with WebSocket-specific methods:

// Text frame from string
await session.SendTextAsync("Hello!");

// Text frame from pre-encoded UTF-8 (zero-copy)
await session.SendTextAsync(utf8Bytes);

// Binary frame
await session.SendAsync(binaryData);

// Close with status
await session.CloseAsync();

SessionManager

server.Sessions.Count;                              // Current count
server.Sessions.All;                                 // IEnumerable<ISession>
server.Sessions.TryGet(id, out ISession? session);   // Lookup by ID
server.Sessions.BroadcastAsync(data);                // Send to all
server.Sessions.CloseAllAsync();                     // Graceful shutdown

SessionGroup

server.Groups.Add("room", session);                  // Join
server.Groups.Remove("room", session);               // Leave
server.Groups.RemoveFromAll(session);                // Leave all (on disconnect)
server.Groups.BroadcastAsync("room", data);          // Send to room
server.Groups.MemberCount("room");                   // Count
server.Groups.GroupNames;                             // All room names

StormTcpClient

var client = new StormTcpClient(options);

// Events
client.OnConnected += async () => { };
client.OnDisconnected += async () => { };
client.OnDataReceived += async (ReadOnlyMemory<byte> data) => { };
client.OnError += async (Exception ex) => { };
client.OnReconnecting += async (int attempt, TimeSpan delay) => { };

// Lifecycle
await client.ConnectAsync(ct);             // Connect (with optional CancellationToken)
await client.SendAsync(data, ct);          // Send data
await client.DisconnectAsync(ct);          // Graceful disconnect
await client.DisposeAsync();               // Disconnect + cleanup

// Properties
client.State;                              // ConnectionState (Connecting, Connected, Closing, Closed)
client.Metrics.BytesSent;                  // Total bytes sent
client.Metrics.BytesReceived;              // Total bytes received
client.Metrics.Uptime;                     // Connection uptime
client.UseMiddleware(middleware);           // Add middleware

StormWebSocketClient

var ws = new StormWebSocketClient(options);

// Events
ws.OnConnected += async () => { };
ws.OnDisconnected += async () => { };
ws.OnMessageReceived += async (WsMessage msg) => { };
ws.OnError += async (Exception ex) => { };
ws.OnReconnecting += async (int attempt, TimeSpan delay) => { };

// Lifecycle
await ws.ConnectAsync(ct);                 // Connect + WebSocket upgrade
await ws.SendTextAsync("hello", ct);       // Send text frame (masked)
await ws.SendTextAsync(utf8Bytes, ct);     // Send pre-encoded text frame
await ws.SendAsync(binaryData, ct);        // Send binary frame (masked)
await ws.DisconnectAsync(ct);              // Send Close frame + disconnect
await ws.DisposeAsync();                   // Disconnect + cleanup

// Properties
ws.State;                                  // ConnectionState
ws.Metrics;                                // ConnectionMetrics
ws.RemoteEndPoint;                         // Server endpoint
ws.UseMiddleware(middleware);               // Add middleware

IConnectionMiddleware

public interface IConnectionMiddleware
{
    ValueTask OnConnectedAsync(ISession session);
    ValueTask<ReadOnlyMemory<byte>> OnDataReceivedAsync(ISession session, ReadOnlyMemory<byte> data);
    ValueTask<ReadOnlyMemory<byte>> OnDataSendingAsync(ISession session, ReadOnlyMemory<byte> data);
    ValueTask OnDisconnectedAsync(ISession session);  // Called in reverse order
    ValueTask OnErrorAsync(ISession session, Exception exception);
}

All methods have default no-op implementations.

Message Framers

Framer	Format	Use Case
RawFramer	No framing, pass-through	Raw TCP streams
LengthPrefixFramer	[4-byte BE length][payload]	Binary protocols
DelimiterFramer	[payload][delimiter] (default: \n)	Text protocols, line-based
Custom IMessageFramer	Your format	Custom protocols

WsMessage

public readonly struct WsMessage
{
    ReadOnlyMemory<byte> Data { get; }  // Raw payload
    bool IsText { get; }                // True = Text frame, False = Binary
    string Text { get; }                // UTF-8 decode (throws if !IsText)
}

How It Works

Connection Lifecycle

Server-side:

Client connects
    │
    ├─ Socket.AcceptAsync
    ├─ TcpTransport created (Pipe pair with backpressure limits)
    ├─ SSL handshake (if SslOptions configured)
    ├─ WebSocket HTTP upgrade (if StormWebSocketServer)
    ├─ Session created, added to SessionManager
    ├─ Middleware.OnConnectedAsync
    ├─ OnConnected event
    │
    ├─ Read loop (receives frames/data, dispatches events)
    ├─ Heartbeat loop (sends Pings, tracks Pongs) [concurrent]
    │
    ├─ Connection closes (client disconnect / timeout / kick)
    ├─ Middleware.OnDisconnectedAsync (reverse order)
    ├─ OnDisconnected event
    ├─ Session removed from SessionManager
    └─ Transport disposed

Client-side:

ConnectAsync called
    │
    ├─ Socket.ConnectAsync (with timeout)
    ├─ TcpTransport or SslTransport created
    ├─ SSL handshake (if configured or wss://)
    ├─ WebSocket HTTP upgrade (if StormWebSocketClient)
    ├─ Middleware.OnConnectedAsync
    ├─ OnConnected event
    │
    ├─ Read/frame loop (dispatches OnDataReceived / OnMessageReceived)
    ├─ Heartbeat loop (WebSocket: sends masked Pings) [concurrent]
    │
    ├─ Connection closes (server disconnect / timeout / DisconnectAsync)
    ├─ Middleware.OnDisconnectedAsync (reverse order)
    ├─ OnDisconnected event
    │
    ├─ [Reconnect.Enabled = true]: wait Reconnect.Delay → OnReconnecting → retry
    └─ Transport disposed

Write Serialization

All writes to a WebSocket connection are serialized through a per-session SemaphoreSlim:

session.SendTextAsync("hello")  ─┐
heartbeat ping                   ├─→ _writeLock → PipeWriter → Socket
auto-pong                       ─┘

This prevents frame interleaving when multiple sources write concurrently (user code, heartbeat timer, auto-pong handler).

Backpressure

StormSocket uses System.IO.Pipelines with configurable pauseWriterThreshold and resumeWriterThreshold:

[Socket] → ReceivePipe (1MB limit) → [Frame Decoder] → [Event Handler]
[Event Handler] → [Frame Encoder] → SendPipe (1MB limit) → [Socket]

When a pipe fills up:

• Receive pipe full: ReceiveAsync pauses → OS TCP window closes → sender slows down
• Send pipe full: session.IsBackpressured = true → SlowConsumerPolicy kicks in:
  • Wait: FlushAsync awaits → caller waits → no memory growth
  • Drop: SendAsync returns immediately → message discarded → no blocking
  • Disconnect: CloseAsync fired → session removed → no slow consumer

Resume happens at 50% of the threshold to avoid oscillation.

Broadcast is concurrent: Each session's send runs in parallel. One slow session never blocks delivery to others, regardless of policy.

Building

git clone https://github.com/suleymanbyzt/StormSocket.git
cd StormSocket
dotnet build
dotnet test

Samples

Sample	Port	Description
StormSocket.Samples.TcpEcho	5000	TCP echo server, test with telnet
StormSocket.Samples.WsChat	8080	WebSocket broadcast chat
StormSocket.Samples.SslEcho	5001	SSL/TLS echo with self-signed cert
StormSocket.Samples.WsServer	8080	Full-featured WS server with admin console, rooms, heartbeat

dotnet run --project samples/StormSocket.Samples.TcpEcho
dotnet run --project samples/StormSocket.Samples.WsChat
dotnet run --project samples/StormSocket.Samples.SslEcho
dotnet run --project samples/StormSocket.Samples.WsServer

License

MIT License - see LICENSE for details.
