UnityMCP.Server 3.2.0

Unity MCP Server (.NET) v3.0.0

A pure .NET Model Context Protocol (MCP) server for Unity Editor automation. Enables AI assistants and LLMs to scaffold projects, create scenes, scripts, prefabs, and manage assets with proper .meta sidecars — no Unity or UPM dependencies at build or runtime.

Features

• Extended MCP tool set: Project scaffolding, scene authoring, typed asset saving (with .meta sidecars), C# validation, UPM packages, UI/navigation/input/animation/VFX/physics tools, and orchestration recipes.
• Complete .meta generation: MonoImporter, TextureImporter, AudioImporter, DefaultImporter, and folder .meta — Unity recognises all assets on import.
• Extensible tool/skill architecture: Tools organised in partial classes by concern; add new automation easily.
• JSON-RPC 2.0 over stdio: MCP over stdio for compatibility with Claude Desktop, Cursor, and other MCP hosts.
• Pure .NET: No Unity/UPM dependencies. Runs on Windows, Linux, and macOS where .NET 10.0+ is supported.
• CI/CD: GitHub Actions for build, test (multi-OS), CodeQL, Dependabot, and NuGet release packaging.
• Comprehensive test suite: 117 tests (unit + integration), split by fixture and concern.

Quick Start

Get up and running in minutes!

Prerequisites

• .NET 10.0 SDK or later
• Python 3.7+ or Node.js 14+ (for client examples)

Installation

You can either run from source, or install the published NuGet tool.

Option A – Run from source

1. Clone this repo and build:

   dotnet build Unity-MCP-Server.sln


2. Run the server:

   dotnet run --project UnityMCP.Server/UnityMCP.Server.csproj


Option B – Install via NuGet (global tool)

Install the tool globally from NuGet.org:

dotnet tool install --global UnityMCP.Server

After installation you can run:

unity-mcp

To upgrade to the latest version:

dotnet tool update --global UnityMCP.Server

For local development builds instead of NuGet, use install-tool.ps1 (see Skills/SKILL.md).

Test Connection

• Python:

  import socket, json
  sock = socket.socket(); sock.connect(('localhost', 8765))
  req = {"jsonrpc": "2.0", "id": "1", "method": "ping", "params": {}}
  sock.send((json.dumps(req) + "\n").encode()); print(sock.recv(1024).decode()); sock.close()


• Command Line:

  echo '{"jsonrpc":"2.0","id":"1","method":"ping","params":{}}' | ncat localhost 8765


VS Code Dev Container & Docker

You can develop and run the MCP Server in a fully containerized environment using VS Code Dev Containers and Docker.

Dev Container (VS Code)

• Open the project in VS Code and run “Reopen in Container” (requires Docker)
• The .devcontainer/devcontainer.json uses the .NET 10 dev container image and runs dotnet restore Unity-MCP-Server.sln after create
• MCP uses stdio (no port). Use the integrated terminal or your MCP host’s config to run dotnet run --project UnityMCP.Server/UnityMCP.Server.csproj or unity-mcp if installed

Docker (Standalone)

• Build the image:

  docker build -t unity-mcp-server .


• Run the server (stdio; MCP hosts start this with stdin/stdout connected):

  docker run -i --rm unity-mcp-server


• Configure as MCP server: See Docs/docker-mcp-setup.md for Claude Desktop, Cursor, and integration examples. Optional: mount a Unity folder and set UNITY_PATH (see DOCKER.md).

Project Structure

• UnityMcp.Server/: .NET server entry point (stdio MCP transport); packable as unity-mcp global tool (v3.0.0).
• UnityMcp.Application/: MCP tool definitions in partial classes (UnityTools.cs + UnityTools.*.cs by concern).
• UnityMcp.Core/: Interfaces and abstractions.
• UnityMcp.Infrastructure/: File-based Unity service, YAML writer, MetaFileWriter.
• UnityMcp.Tests/: 117 tests in fixture-split files (unit + integration).
• Docs/: Validation pipeline, tool contracts, UI/nav/recipes, and Docker MCP setup (install/run/configure + integration example).
• Skills/SKILL.md: AI agent skill reference.

Protocol & API Reference

See Docs/ for tool contracts, validation pipeline, and scenario docs. Tool list and usage are in Skills/SKILL.md.

Troubleshooting

• Port already in use: Change port in config or close other app.
• No tools registered: Check file locations and namespaces.
• Connection timeout: Check firewall and allow port 8765.

Version History

• 3.0.0 (2026-03)
  • Version set to 3.0.0; NuGet package metadata and multi-platform (Windows, Linux, macOS).
  • Refactor: UnityTools split into partial classes by concern (ScenesAndAssets, Project, PackagesAndValidation, Ui, Navigation, InputAndAnimation, VfxAndPhysics, Recipes).
  • Tests refactored into separate files by fixture (UnityToolsTests, UnityYamlWriterTests, UnityToolsNewToolsTests, UnityToolsRecipeTests, MetaFileWriterTests, FileUnityServiceNewToolsTests, AdvancedSystemsGoldenFixtureTests).
  • GitHub Actions: CI (multi-OS build + test), Release (NuGet pack on tag), CodeQL, Dependabot.
  • 117 tests (unit + integration). 2.0.0 (2026-03-12)
• 1.5.0 / 1.4.0 (2026-03-01)
  • Extended MCP tools (scaffold, folder, save script/text/texture/audio, validate C#, add packages, project info, UI, nav, input, animation, VFX, physics, recipes).
  • Full .meta sidecar generation; 55+ tests.
• 1.2.0 (2026-02-15)
  • Pure .NET structure, Unity/UPM code archived; Docs and Docker support.
• 1.0.0 (2025-02-14)
  • Initial release with core MCP protocol and tools.

Legacy Unity/UPM Support

All Unity/UPM-specific code and documentation has been archived in the archive/ folder. This repo is now a pure .NET MCP server. For Unity integration, see the archived files.
