Bluetooth.Core 1.0.3

Bluetooth.Core & Bluetooth.Maui

<div style="max-width: 256px; margin-left: auto; margin-right: auto;">

</div>

A cross-platform .NET MAUI Bluetooth Low Energy (BLE) library providing a unified API for Android, iOS, and Windows platforms.

Features

• 🔍 Bluetooth Scanning - Discover nearby BLE devices with filtering
• 🔗 Device Connection - Connect and manage multiple devices
• 📡 GATT Operations - Read, write, and subscribe to characteristics
• 📢 Broadcasting - Act as a BLE peripheral (Android only)
• 🎯 Cross-Platform - Consistent API across Android, iOS, and Windows
• 🔄 Async/Await - Modern async patterns with cancellation support
• 💉 Dependency Injection - Built-in MAUI DI support

Installation

dotnet add package Bluetooth.Maui

Quick Start

Option 1: MAUI Dependency Injection (Recommended)

Register Bluetooth services in your MauiProgram.cs:

public static class MauiProgram
{
    public static MauiApp CreateMauiApp()
    {
        var builder = MauiApp.CreateBuilder();

        builder
            .UseMauiApp<App>()
            .UseBluetooth(
                configureScanner: scanner =>
                {
                    // Optional: Configure scanner
                    scanner.AdvertisementFilter = ad => ad.IsConnectable;
                }
            );

        return builder.Build();
    }
}

Then inject IBluetoothScanner in your pages or view models:

public partial class MainPage : ContentPage
{
    private readonly IBluetoothScanner _scanner;

    public MainPage(IBluetoothScanner scanner)
    {
        InitializeComponent();
        _scanner = scanner;
    }

    protected override async void OnAppearing()
    {
        base.OnAppearing();

        // Explicitly initialize when ready (handles permissions)
        await _scanner.InitializeAsync();

        // Start scanning
        await _scanner.StartAsync();
    }
}

Option 2: Direct Instantiation

If you prefer full control over initialization timing:

// Create and initialize scanner
var scanner = await BluetoothScanner.GetOrCreateDefaultScannerAsync();

// Configure scanner
scanner.AdvertisementFilter = ad => ad.IsConnectable;

// Start scanning
await scanner.StartAsync();

Usage Examples

Scanning for Devices

var scanner = await BluetoothScanner.GetOrCreateDefaultScannerAsync();

// Subscribe to device discovery
scanner.DevicesAdded += (sender, args) =>
{
    foreach (var device in args.Devices)
    {
        Console.WriteLine($"Found: {device.Name} ({device.Id})");
    }
};

// Start scanning
await scanner.StartAsync();

// Stop scanning
await scanner.StopAsync();

Connecting to a Device

// Get a specific device
var device = await scanner.GetDeviceAsync(deviceId);

// Or wait for a device matching criteria
var device = await scanner.GetDeviceOrWaitForDeviceToAppearAsync(
    filter: d => d.Name.Contains("MyDevice"),
    timeout: TimeSpan.FromSeconds(10)
);

// Connect
await device.ConnectAsync();

// Check connection status
if (device.IsConnected)
{
    Console.WriteLine("Connected!");
}

Exploring Services and Characteristics

// Discover services
await device.ExploreServicesAsync(exploreCharacteristicsToo: true);

// Get a specific service
var service = device.GetService(serviceGuid);

// Get a specific characteristic
var characteristic = service.GetCharacteristic(characteristicGuid);

Reading and Writing Characteristics

// Read value
var value = await characteristic.ReadAsync();
Console.WriteLine($"Value: {BitConverter.ToString(value.ToArray())}");

// Write value
byte[] data = { 0x01, 0x02, 0x03 };
await characteristic.WriteAsync(data);

// Write without response (faster)
await characteristic.WriteAsync(data, withoutResponse: true);

Subscribing to Notifications

// Subscribe to characteristic changes
characteristic.ValueUpdated += (sender, args) =>
{
    Console.WriteLine($"New value: {BitConverter.ToString(args.Value.ToArray())}");
};

await characteristic.SubscribeAsync();

// Unsubscribe when done
await characteristic.UnsubscribeAsync();

Using Characteristic Access Services

For strongly-typed characteristic access:

// Define a characteristic access service
var batteryService = CharacteristicAccessServiceFactory.CreateForByte(
    characteristicId: Guid.Parse("00002A19-0000-1000-8000-00805F9B34FB"),
    name: "Battery Level"
);

// Read the battery level
var batteryLevel = await batteryService.ReadAsync(device);
Console.WriteLine($"Battery: {batteryLevel}%");

// Subscribe to battery level changes
await batteryService.SubscribeAsync(device, (value) =>
{
    Console.WriteLine($"Battery changed: {value}%");
});

Broadcasting (Android Only)

var broadcaster = await BluetoothBroadcaster.GetOrCreateDefaultBroadcasterAsync();

// Start broadcasting
await broadcaster.StartAsync();

// Stop broadcasting
await broadcaster.StopAsync();

Advanced Configuration

Filtering Advertisements

scanner.AdvertisementFilter = advertisement =>
{
    // Only process connectable devices
    if (!advertisement.IsConnectable) return false;

    // Only devices with specific service
    if (!advertisement.ServicesGuids.Contains(myServiceGuid)) return false;

    // Only devices with good signal strength
    if (advertisement.RawSignalStrengthInDBm < -80) return false;

    return true;
};

Handling Timeouts and Cancellation

using var cts = new CancellationTokenSource(TimeSpan.FromSeconds(30));

try
{
    await device.ConnectAsync(
        timeout: TimeSpan.FromSeconds(10),
        cancellationToken: cts.Token
    );
}
catch (OperationCanceledException)
{
    Console.WriteLine("Connection timed out or was cancelled");
}

Device Cleanup

// Clean up specific device
await scanner.CleanAsync(device);

// Clean up all devices
await scanner.CleanAsync();

// Dispose device (disconnects and cleans up)
await device.DisposeAsync();

Platform-Specific Considerations

Android

• Requires BLUETOOTH_SCAN and BLUETOOTH_CONNECT permissions (Android 12+)
• Requires ACCESS_FINE_LOCATION permission for scanning
• Broadcasting fully supported via BluetoothGattServer

iOS

• Requires NSBluetoothAlwaysUsageDescription in Info.plist
• Limited background scanning capabilities
• Broadcasting not currently implemented (throws NotImplementedException)

Windows

• Requires Bluetooth capability in package manifest
• Use GattSession.MaintainConnection for persistent connections
• Broadcasting not currently implemented (throws NotImplementedException)

Architecture

Plugin.Bluetooth
├── Bluetooth.Core          # Platform-agnostic abstractions
│   ├── Abstractions/       # Interfaces
│   ├── BaseClasses/        # Base implementations
│   ├── CharacteristicAccess/
│   └── Exceptions/
└── Bluetooth.Maui         # Platform-specific implementations
    ├── Core/              # Fallback implementations
    └── Platforms/
        ├── Android/       # Android BLE
        ├── iOS/           # CoreBluetooth
        └── Windows/       # Windows.Devices.Bluetooth

API Overview

Core Interfaces

• IBluetoothScanner - Device discovery and scanning
• IBluetoothDevice - Device representation and connection management
• IBluetoothService - GATT service wrapper
• IBluetoothCharacteristic - GATT characteristic operations
• IBluetoothBroadcaster - Peripheral/advertising mode
• IBluetoothAdvertisement - Advertisement data

Exception Handling

The library provides a comprehensive exception hierarchy:

try
{
    await device.ConnectAsync();
}
catch (DeviceNotFoundException ex)
{
    // Device not found during scan
}
catch (DeviceConnectionFailedException ex)
{
    // Connection attempt failed
}
catch (DeviceNotConnectedException ex)
{
    // Attempted operation on disconnected device
}
catch (BluetoothException ex)
{
    // Generic Bluetooth error
}

Requirements

• .NET 10.0 or higher
• MAUI application

License

MIT License - Copyright (c) 2025 Laerdal Medical

See LICENSE.md for details.

Contributing

Contributions are welcome! Please ensure all public APIs are documented with XML comments.

Support

For issues and feature requests, please use the GitHub issue tracker.
