BrainforceControls 1.4.1

BrainforceControls

Modern UI controls for Avalonia®

A small, focused library of high-quality, render-based controls for Avalonia®.

Table of contents

• Installation
• Activate library styles
• ProgressRingControl
  • Features
  • Properties
  • XAML example
  • C# animation example
• Speedometer
  • Features
  • Properties
  • XAML example
  • C# animation example
• LEDDisplay
  • Features
  • Properties
  • XAML example
• DialControl
  • Features
  • Properties
  • XAML example
• AvatarImage
  • Features
  • Properties
  • XAML example
• Layout example
• Custom fonts
• Designer vs runtime note
• Troubleshooting
• License

Installation

Install from NuGet:

dotnet add package BrainforceControls

Or via Package Manager:

Install-Package BrainforceControls

The assembly name is BrainForceOne.BrainforceControls.

Activate library styles

To ensure the controls render with their default styles (including bundled fonts and templates), include the library Generic.axaml in your application App.axaml:

<Application xmlns="https://github.com/avaloniaui"
             xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml">
  <Application.Styles>
    <FluentTheme Mode="Dark"/>

    <StyleInclude Source="avares://BrainForceOne.BrainforceControls/Themes/Generic.axaml"/>
  </Application.Styles>
</Application>

If you do not include the library styles, the controls will still work but defaults (for example the bundled font or default visual settings) may not be applied.

ProgressRingControl

A modern, animated ring indicator with optional glow, titles and configurable stroke.

<img src="https://raw.githubusercontent.com/Brainforce1/AvaloniaControls/refs/heads/master/BrainforceControls/docs/images/ProgressRing.gif" width="300" />

ProgressRingControl — Features

• Smooth, configurable progress animation
• Supertitle and Subtitle text areas
• Glow effect (color, blur radius, opacity)
• Configurable stroke thickness and size
• Template-based control — fully stylable
• Custom font support via FontFamily
• Designer preview friendly

ProgressRingControl — Properties

ProgressRingControl — XAML example

<controls:ProgressRingControl
    x:Name="Ring"
    Progress="0"
    Supertitle="STREAMING FROM"
    Subtitle="Server@Home"
    HorizontalAlignment="Center"
    StrokeThickness="20"
    VerticalAlignment="Center"
    Width="240"
    Height="240"/>

ProgressRingControl — C# animation example

private async void StartProgress()
{
    while (true)
    {
        for (int i = 0; i <= 100; i++)
        {
            Ring.Progress = i;
            await Task.Delay(30);
        }

        Ring.Progress = 0;
        await Task.Delay(200);
    }
}

Recommendation: Task.Delay or DispatcherTimer are fine for demos. For smooth, jitter-free animations use render-based updates (update in Render() using elapsed time and call InvalidateVisual()), or Avalonia® composition animations.

Speedometer

A fully drawn gauge control with a needle, configurable sweep, glass effect and unit display.

<img src="https://raw.githubusercontent.com/Brainforce1/AvaloniaControls/refs/heads/master/BrainforceControls/docs/images/Speedometer.gif" width="300" />

Speedometer — Features

• Render-based visuals for crisp drawing
• Smooth needle animation with easing (when animated via render/composition)
• Configurable sweep angle (for example 180 or 270 degrees)
• Minimum / Maximum value range
• Unit text and value text with custom font support
• Optional glass effect and styling via template
• Designer preview friendly

Speedometer — Properties

Speedometer — XAML example

<controls:Speedometer
    x:Name="Speedometer"
    Width="240"
    Height="240"
    Position="Top"
    GlassEffect="True"
    SweepAngle="270"
    Minimum="30.0"
    Maximum="200.0"
    TextSize="30"
    UnitText="cm/h"
    UnitTextSize="12"
    Value="65"/>

Speedometer — C# animation example

private async void AnimateSpeed()
{
    while (true)
    {
        for (int i = 30; i <= 200; i++)
        {
            Speedometer.Value = i;
            await Task.Delay(20);
        }

        for (int i = 200; i >= 30; i--)
        {
            Speedometer.Value = i;
            await Task.Delay(20);
        }
    }
}

Recommendation: Avoid relying on Task.Delay for frame-perfect motion. Prefer updating the control from a render loop (use InvalidateVisual() and compute delta time with Stopwatch) or use Avalonia composition animations where possible.

LEDDisplay

A render-based seven-segment display control for showing numeric values with configurable digits, color, glow and segment thickness.

<img src="https://raw.githubusercontent.com/Brainforce1/AvaloniaControls/refs/heads/master/BrainforceControls/docs/images/LedDisplay.gif" width="300" />

LEDDisplay — Features

• Render-based seven-segment digits for crisp visuals
• Configurable number of digits
• Optional leading-zero display
• Configurable segment color and thickness
• Optional glow effect for active segments
• Designer preview friendly

LEDDisplay — Properties

LEDDisplay — XAML example

<controls:LedDisplay
    x:Name="LedDisplay"
    Width="240"
    Height="80"
    Digits="4"
    Value="1234"
    LeadingZeros="True"
    Glow="True"
    SegmentOnColor="Red"
    SegmentThickness="1.0"/>

DialControl

A circular, interactive dial that displays a value on a 270-degree progress ring. The value can be changed by dragging vertically, scrolling the mouse wheel, or binding the Value property.

<img src="https://raw.githubusercontent.com/Brainforce1/AvaloniaControls/refs/heads/master/BrainforceControls/docs/images/DialControl.gif" width="300" />

DialControl — Features

• Interactive mouse drag and mouse-wheel value adjustment
• Fine adjustment while dragging with the Control key
• Configurable minimum and maximum value range
• Customizable track, progress, disabled-progress, title, and value brushes
• Optional progress-ring gradient with a configurable end brush
• Configurable title, value format, text sizes, ring thickness, and font family
• ValueChanged event for reacting to user changes
• Designer preview friendly

DialControl — Properties

DialControl — XAML example

<controls:DialControl
    x:Name="Dial"
    Width="240"
    Height="240"
    Title="Volume"
    Minimum="0"
    Maximum="100"
    Value="65"
    ValueFormat="%"
    RingThickness="14"
    TrackBrush="#334455"
    ProgressBrush="DeepPink"
    UseGradient="True"
    GradientBrush="Orange"
    ValueTextBrush="White"
    TitleTextBrush="LightGray"
    ValueTextSize="44"
    TitleTextSize="16"
    FontFamily="Segoe UI"/>

AvatarImage

A circular avatar control that loads an image from an HTTP(S) URL or a local file path. While an image is loading, it displays an animated ring; if no image is available, it displays the configured placeholder brush.

<img src="https://raw.githubusercontent.com/Brainforce1/AvaloniaControls/refs/heads/master/BrainforceControls/docs/images/AvatarImage.gif" width="300" />

AvatarImage — Features

• Circular image rendering with automatic center cropping
• Supports HTTP(S) URLs and local file paths
• In-memory image caching by URL or path
• Animated loading ring with optional visibility
• Optional glass reflection effect over the loaded image
• Configurable ring, placeholder, and glass overlay brushes
• Designer preview friendly

AvatarImage — Properties

AvatarImage — XAML example

<controls:AvatarImage
    Width="128"
    Height="128"
    ImageUrl="https://example.com/images/avatar.png"
    RingBrush="DeepSkyBlue"
    RingThickness="5"
    PlaceholderBrush="#263238"
    GlassEffect="True"
    HideLoadingRing="False"/>

For a local image, set ImageUrl to a local file path instead of an HTTP(S) URL. DelayForLoadTest is honored only in DEBUG builds and is intended for testing loading states.

Layout example

Below is the exact XAML sample used in the test app:

<Window
    xmlns="https://github.com/avaloniaui"
    xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
    xmlns:local="clr-namespace:AvaloniaControlTesterApp"
    xmlns:controls="clr-namespace:BrainForceOne.BrainforceControls;assembly=BrainForceOne.BrainforceControls"
    x:Class="AvaloniaControlTesterApp.MainWindow"
    Width="500" Height="500"
    Background="#0B1A2A">

    <Grid ColumnDefinitions="*,*">

        <controls:ProgressRingControl
            x:Name="Ring"
            Progress="0"
            Supertitle="STREAMING FROM"
            Subtitle="Server@Home"
            HorizontalAlignment="Center"
            StrokeThickness="20"
            VerticalAlignment="Center"
            Width="240"
            Height="240"
            Grid.Column="0"/>

        <controls:Speedometer
            x:Name="Speedometer"
            Width="240"
            Height="240"
            Position="Top"
            GlassEffect="True"
            SweepAngle="270"
            Minimum="30.0"
            Maximum="200.0"
            TextSize="30"
            UnitText="cm/h"
            UnitTextSize="12"
            Value="65"
            Grid.Column="1"/>
    </Grid>

</Window>

Thermometer Control

The Thermometer is an Avalonia® control that displays a vertical temperature indicator with a gradient between StartColor and EndColor. The control supports ticks, glass effect, unit text, and a configurable bulb size.

<img src="https://raw.githubusercontent.com/Brainforce1/AvaloniaControls/refs/heads/master/BrainforceControls/docs/images/Thermometer.gif" width="300" />

Properties

XAML Example

<thermo:Thermometer
    Width="150"
    Height="400"
    Minimum="0"
    Maximum="120"
    Value="90"
    BulbSize="40"
    StartColor="LimeGreen"
    EndColor="Red"
    ShowTicks="True"
    Unit="°C"
    TickInterval="10"
    TickColor="Red"
    TickPlacement="Left"
    GlassEffect="True"/>

Custom fonts

The controls support FontFamily (same pattern as Avalonia® controls). You can set a font from your app or use the library default.

Example: use an embedded font from your app:

1. Add font file to your app project (for example Assets/Fonts/MyFont.ttf) and include it as an Avalonia® resource in the app project file:

   <ItemGroup>
     <AvaloniaResource Include="Assets/Fonts/MyFont.ttf" />
   </ItemGroup>


2. Register a FontFamily resource in your app App.axaml or a resource dictionary:

   <FontFamily x:Key="MyAppFont">
     avares://MyApp/Assets/Fonts/MyFont.ttf#My Font
   </FontFamily>


3. Use it on the control:

   <controls:Speedometer FontFamily="{StaticResource MyAppFont}" />


Library default font: The library ships a default font and sets it in Generic.axaml. To ensure the default is applied, include the library styles in your App.axaml (see “Activate library styles”).

Designer vs runtime note

• Designer preview often loads library styles and simulates a stable render loop.
• Runtime requires you to include avares://BrainForceOne.BrainforceControls/Themes/Generic.axaml in your Application.Styles to apply the library defaults (fonts, templates, resources).
• If fonts or styles appear in preview but not at runtime, check that your app includes the StyleInclude and that the assembly name in avares:// URIs matches exactly.

Troubleshooting

Fonts not showing in runtime

• Ensure Generic.axaml is included in your app App.axaml.
• Verify the avares:// URI uses the correct assembly name and internal font family name (the font's internal name, not the file name).
• Confirm the font file is included as AvaloniaResource in the project that hosts the font.

Preview shows font but runtime does not

• Designer may load library resources automatically. Your app must explicitly include the library styles to get the same defaults at runtime.

Jittery or jumpy animations

• Avoid DispatcherTimer or Task.Delay for frame-sensitive animations.
• Use render-based updates (update animation state in Render() using elapsed time and call InvalidateVisual()), or use Avalonia® composition animations.
• If you must use timers, compute motion based on elapsed time (delta) rather than fixed increments.

Needle or ring renders under text

• Drawing order matters: draw background elements first, then text, then needle (or draw needle last) so it appears above text.

License

MIT License — see LICENSE file in the package for full text.
