ByteAether.Ulid.Dapper 1.3.9-preview.0

ULID Dapper Integration

from ByteAether

An official extension package for ByteAether.Ulid, providing seamless integration with Dapper. It enables effortless mapping of Ulid and Ulid? properties to database columns using customizable global persistence strategies.

For the core library and full details, visit our GitHub repository.

Features

• Version Support: Fully compatible with Dapper versions 2.0.0 and newer.
• Automated Configuration: Register mappings globally across your entire application runtime using a single configuration call.
• Flexible Storage Strategies: Choose how your identifiers are mapped based on your database engine constraints:
  • String: 26-character Crockford's Base32 string (e.g., CHAR(26)). (Default)
  • Binary: 16-byte binary payload (e.g., BINARY(16)).
  • Guid: Native UUID format (ideal for PostgreSQL uuid).
  • SqlServerGuid: Shuffled SQL Server sequential uniqueidentifier to maintain native index sorting properties.

Installation

Install the stable package via NuGet:

dotnet add package ByteAether.Ulid.Dapper

Usage

Call DapperUlid.RegisterUlid() during your application's startup lifecycle (e.g., inside Program.cs or a global initialization block) before executing any queries:

using ByteAether.Ulid.Dapper;

// Configures the mapping globally using your chosen database storage format.
// Supports: UlidStorageFormat.String (Default), Binary, Guid, and SqlServerGuid
DapperUlid.RegisterUlid(UlidStorageFormat.Binary);

Once registered, queries executing via Dapper parameters or multi-mapping configurations handle the translation transparently:

public class User
{
    public int Id { get; set; }
    public Ulid AccountId { get; set; }
    public Ulid? ManagedById { get; set; }
}

// Queries execute seamlessly
var user = connection.QueryFirstOrDefault<User>(
    "SELECT * FROM Users WHERE AccountId = @Id",
    new { Id = myUlid }
);

⚠️ Important Architectural Limitations & Warnings

1. No Per-Property / Mixed Mappings

Unlike full object-relational mappers (like Entity Framework Core) which preserve structural metadata per table column, Dapper maps .NET types globally via a 1:1 scheme (Type → TypeHandler).

• The Rule: You can choose exactly one global strategy for your application lifecycle.
• The Constraint: If you call RegisterUlid(UlidStorageFormat.String), you cannot have some tables storing Ulid as BINARY(16) and others as VARCHAR(26) within the same execution path. The last configuration registered will override any previous configuration globally. If a mixed scheme is explicitly required, wrapper primitive types or custom parameter objects must be introduced manually.

2. Range Queries & Sorting Compatibility (>=, <=, ORDER BY)

All storage formats are technically supported, but their ability to maintain chronological sorting and support range queries depends entirely on how the underlying database provider handles GUID byte layouts. Because ULIDs rely on a big-endian timestamp for sorting, your choice of database provider determines which formats remain index-friendly:

• Globally Safe (String and Binary): These formats preserve the raw left-to-right chronological order of ULIDs natively across all database engines (SQLite, PostgreSQL, SQL Server, etc.).
• Provider Dependent (Guid): Standard .NET Guid structures use a mixed-endian layout.
  • PostgreSQL: Supported. The connection driver automatically corrects the endianness when mapping to native uuid columns, preserving chronological sorting.
  • SQLite / Others: Incompatible for range queries. These engines store GUIDs as raw byte streams, meaning the mixed-endian layout will scramble chronological comparison (though equality operations remain fully functional).
• SQL Server Specific (SqlServerGuid): This format explicitly optimizes byte shuffling for Microsoft SQL Server's unique sequential indexing rules.
  • Constraint: This format only works as intended if the underlying column is typed as uniqueidentifier. Storing it as BINARY(16) or VARCHAR will break sorting.
  • Trade-off: This internal byte reordering sacrifices cross-database compatibility (e.g., migrating data to PostgreSQL or SQLite) in exchange for raw SQL Server index performance.

CRITICAL: Before using Guid or SqlServerGuid formats for range queries (>=, <=) or OrderBy clauses, verify your database provider's native UUID comparison behavior. Misaligning the format with the engine's sorting behavior will result in broken data retrieval and missed records.

Native AOT & Trimming Compatibility

ByteAether.Ulid.Dapper introduces no runtime reflection, dynamic IL injection, or dynamic code compilation patterns inside its mapping block. The explicit SqlMapper.TypeHandler<T> strategy is fully safe for Native AOT compilation and trimming.

Ensure your version of the underlying Dapper framework itself is explicitly configured to support AOT workloads

License

This project is licensed under the MIT License. See the LICENSE file for details.
