CSharpEssentials.LoggerHelper 5.2.2.6

CSharpEssentials — LoggerHelper

Stop writing Serilog boilerplate. Route any log level to any sink — in one JSON file.

⭐ If you find this project useful, please consider giving it a star on GitHub!
💡 Explore the source code, check open issues, or contribute.

LoggerHelper is a modular logging infrastructure for .NET. Install the core + only the sink packages you need, drop in a JSON config, and your entire app's ILogger<T> routes to Console, File, Email, Telegram, SQL Server, PostgreSQL, Elasticsearch, Seq, and Hangfire Console — each receiving only the log levels you configure.

Zero code changes required if you already use ILogger<T>. LoggerHelper registers as a standard ILoggerProvider.

dotnet add package CSharpEssentials.LoggerHelper
dotnet add package CSharpEssentials.LoggerHelper.Sink.Console
dotnet add package CSharpEssentials.LoggerHelper.Sink.File

Table of Contents

• Quick Start
• Run the Demo in 60 Seconds
• Why choose LoggerHelper?
• Packages
• Feature Highlights
• Built-in UI — Dashboard
• AI Integration — MCP Server
• Sink Overview & JSON Examples
• Comparison
• Architecture
• Coming Soon
• View Source & Contribute
• Documentation & Links

🚀 Quick Start

Option A — JSON config (recommended)

1. Install packages

dotnet add package CSharpEssentials.LoggerHelper
dotnet add package CSharpEssentials.LoggerHelper.Sink.Console
dotnet add package CSharpEssentials.LoggerHelper.Sink.File

2. Wire up in Program.cs

builder.Services.AddLoggerHelper(builder.Configuration);
app.UseLoggerHelper();

3. Create appsettings.LoggerHelper.json in your project root

{
  "LoggerHelper": {
    "ApplicationName": "MyApp",
    "Routes": [
      { "Sink": "Console", "Levels": ["Information", "Warning"] },
      { "Sink": "File", "Levels": ["Information", "Warning", "Error", "Fatal"] },
      { "Sink": "Email", "Levels": ["Error", "Fatal"] },
      { "Sink": "MSSqlServer", "Levels": ["Information", "Warning", "Error", "Fatal"] }
    ],
    "Sinks": {
      "File": {
        "Path": "Logs",
        "RollingInterval": "Day",
        "RetainedFileCountLimit": 7,
        "FileNameProperty": "TenantId"
      },
      "Email": {
        "From": "alerts@myapp.com",
        "To": "team@myapp.com",
        "Host": "smtp.myapp.com",
        "Port": 587
      },
      "MSSqlServer": {
        "ConnectionString": "Server=localhost;Database=LogsDb;Trusted_Connection=true;",
        "TableName": "Logs",
        "AutoCreateSqlTable": true
      }
    },
    "General": { "EnableRequestResponseLogging": true }
  }
}

Done. Every ILogger<T> in your app now routes through LoggerHelper.

💡 PRO TIP: Environment-Specific Configs
LoggerHelper automatically detects your environment! Create an appsettings.LoggerHelper.debug.json file alongside the main config, and LoggerHelper will automatically load it when running in Development mode. This is perfect for enabling verbose Console logging locally while keeping appsettings.LoggerHelper.json strictly for Production settings (like Databases and Email).

Option B — Fluent API

builder.Services.AddLoggerHelper(b => b
    .WithApplicationName("MyApp")
    .AddRoute("Console", LogEventLevel.Information, LogEventLevel.Warning)
    .AddRoute("File",    LogEventLevel.Information, LogEventLevel.Warning, LogEventLevel.Error, LogEventLevel.Fatal)
    .AddRoute("Email",   LogEventLevel.Error, LogEventLevel.Fatal)
    .ConfigureFile(f => { f.Path = "Logs"; f.RollingInterval = "Day"; })
    .ConfigureEmail(e => { e.To = "ops@example.com"; e.Host = "smtp.example.com"; })
    .EnableRequestResponseLogging()
);

Option C — JSON + Fluent merge

// JSON defines shared config across environments.
// Fluent adds development-only extras without touching JSON.
builder.Services.AddLoggerHelper(builder.Configuration, b => b
    .AddRoute("Console", LogEventLevel.Debug)
);

⚡ Run the Demo in 60 Seconds

Clone the repo and start the interactive demo app. The demo comes pre-configured with Console, File, MSSqlServer, and PostgreSQL sinks.

git clone https://github.com/alexbypa/CSharp.Essentials.git
cd CSharp.Essentials/src/CSharpEssentials.LoggerHelper.Demo
dotnet run

Open the URL shown in your terminal (usually http://localhost:<port>/swagger/index.html) — the Swagger UI lists all available demo scenarios. Each endpoint produces structured logs visible immediately in the terminal and in the Logs/ folder.

💡 No database required to run it: Even if you don't have SQL Server or PostgreSQL running locally, LoggerHelper gracefully ignores the connection errors. Your app won't crash, and logs will still appear perfectly in the Console and File sinks!

🎯 Why choose LoggerHelper?

• 🔌 Native ILogger<T>: Zero vendor lock-in. Uses standard Microsoft abstractions.
• 🧩 Zero Unnecessary Dependencies: Highly modular. Install the core package and only the specific sinks you need.
• 🛠️ JSON-First Configuration: Route any log level to any sink without writing a single line of C# conditional logic.
• 🛡️ PII Data Masking: Automatically redact passwords, JWTs, and sensitive fields across all sinks globally.
• 🤖 AI-Ready: Includes a native MCP Server to let AI assistants query log health and configuration out-of-the-box.

📦 Packages

Package	Description	Version
CSharpEssentials.LoggerHelper	Core routing engine, ILogger<T> bridge, JSON/fluent config
...Sink.Console	Colored console output, per-level themes — guide →
...Sink.File	Rolling JSON files, per-property subdirectories, configurable retention — guide →
...Sink.Email	SMTP alerts, HTML templates, throttling — guide →
...Sink.Telegram	Bot notifications, MarkdownV2, throttling — guide →
...Sink.Elasticsearch	Elasticsearch/OpenSearch indexing, Kibana-ready — guide →
...Sink.MSSqlServer	SQL Server structured logs, auto table creation — guide →
...Sink.Postgresql	PostgreSQL, JSONB columns, custom schema — guide →
...Sink.Seq	Seq centralized log server — guide →
...Sink.HangfireConsole	Structured logs in Hangfire Dashboard with color output — guide →
...Sink.Dashboard	Dashboard LoggerHelper — guide →
CSharpEssentials.LoggerHelper.MCP	MCP server: AI assistants can query sink health, errors & config — guide →
CSharpEssentials.HttpHelper	HttpClient + Polly resilience, rate limiting, auto logging

✨ Feature Highlights

Per-Level Sink Routing — Declarative

Send different log levels to different destinations without writing conditional predicates:

"Routes": [
  { "Sink": "Console",       "Levels": ["Debug", "Information", "Warning"] },
  { "Sink": "File",          "Levels": ["Information", "Warning", "Error", "Fatal"] },
  { "Sink": "Telegram",      "Levels": ["Error", "Fatal"] },
  { "Sink": "Email",         "Levels": ["Fatal"] },
  { "Sink": "Elasticsearch", "Levels": ["Information", "Warning", "Error", "Fatal"] }
]

Native ILogger<T> — Zero Code Changes

If your app already uses ILogger<T>, you change nothing. LoggerHelper registers as a standard ILoggerProvider:

public class OrderService(ILogger<OrderService> logger) {
    public void Process(int orderId) {
        logger.LogInformation("Processing order {OrderId}", orderId);  // → Console + File
        logger.LogError("Payment failed for {OrderId}", orderId);      // → File + Email
    }
}

Named parameters like {OrderId} are preserved as structured Serilog properties — not flattened into strings.

BeginScope — Context That Travels

using (_logger.BeginScope(new Dictionary<string, object?> {
    ["OrderId"] = orderId,
    ["UserId"]  = userId
}))
{
    _logger.LogInformation("Validation started");   // OrderId + UserId attached
    await ValidateStock();                           // inner logs also carry them
    _logger.LogInformation("Order confirmed");       // OrderId + UserId attached
}

Automatic Enrichment

Every log event automatically carries:

Internal Diagnostics

If a sink fails (wrong connection string, unreachable SMTP), your app keeps running. Errors are captured silently and inspectable at runtime:

app.MapGet("/health/logging", (ILogErrorStore errors) =>
    errors.Count == 0
        ? Results.Ok("All sinks healthy")
        : Results.Problem(string.Join("\n", errors.GetAll().Select(e => $"{e.SinkName}: {e.ErrorMessage}")))
);

Request/Response Logging Middleware

"General": { "EnableRequestResponseLogging": true }

app.UseLoggerHelper();

One setting, one line — full HTTP request/response logging with correlation IDs and timing.

Dynamic File Routing (Multi-Tenant)

Route logs to subdirectories based on any log property:

"Sinks": {
  "File": { "Path": "Logs", "RollingInterval": "Day", "FileNameProperty": "TenantId" }
}

Logs with TenantId = "acme" → Logs/acme/log-20250101.txt.
Logs without the property → Logs/log-20250101.txt.

Sensitive Data Masking — One JSON Block Protects Every Sink

Stop writing Regex.Replace calls before every logger.LogInformation. Declare what's sensitive once, and LoggerHelper redacts it everywhere — Console, File, SQL, Elasticsearch, Seq, Telegram — before any sink ever sees it:

"SensitiveDataMasking": {
  "Enabled": true,
  "MaskText": "***MASKED***",
  "Presets": [ "Email", "CreditCard", "JwtToken", "BearerToken", "ConnectionStringSecret" ],
  "SensitiveProperties": [ "Password", "ApiKey" ],
  "Rules": [
    { "Name": "OrderId", "Pattern": "ORD-\\d+" }
  ]
}

logger.LogInformation("Login for {Email} with {Password}", "alice@example.com", "Sup3rSecret!");
// → every sink receives: Login for ***MASKED*** with ***MASKED***

• Built-in presets for the secrets that leak most often: emails, credit card numbers, JWTs, Bearer ... tokens, and Password=... / Pwd=... in connection strings.
• SensitiveProperties redacts named structured fields outright (e.g. Password, ApiKey), regardless of content.
• Custom regex rules with an optional secret capture group mask only part of a match — Bearer ***MASKED*** keeps the scheme visible while hiding the token.
• Zero overhead when disabled (the default) — the enricher isn't added to the pipeline at all.

Serilog has no first-class equivalent: redaction usually means a hand-rolled IDestructuringPolicy or a third-party enricher wired up per project. Here it's one JSON block, applied globally.

📊 Built-in UI — Dashboard

dotnet add package CSharpEssentials.LoggerHelper.Dashboard

Embedded real-time diagnostics dashboard for ASP.NET Core — no Seq, no Kibana, no extra infrastructure required. Navigate to /loggerhelper to see the health of your logging pipeline at a glance:

• 📡 Live Log Stream: Browser-based tail -f via Server-Sent Events. Filter by level or text in real time.
• 🩺 Sink Health Cards: At-a-glance status for every configured sink (ACTIVE / FAILED) and their assigned log levels.
• ⚠️ Error History: Click-to-expand table of recent sink errors (SMTP failures, DB write errors) with full stack traces.
• ⏪ Context Before Error: The killer feature. A zero-allocation ring buffer automatically flushes all preceding Debug/Info/Warning entries only when an Error or Fatal event fires. You see exactly what happened before the crash without keeping verbose logging on permanently!

// Program.cs
builder.Services.AddLoggerHelperDashboard();
// ...
app.MapLoggerHelperDashboard(); // Exposes the UI at /loggerhelper

🤖 AI Integration — MCP Server

dotnet add package CSharpEssentials.LoggerHelper.MCP

Give your AI assistant live visibility into your running app's logging state. Two lines of setup expose a Model Context Protocol (MCP) server that Claude, Cursor, GitHub Copilot, and any MCP-compatible client can query.

// Program.cs — add after AddLoggerHelper()
builder.Services.AddLoggerHelperMcp();
// ...
app.MapLoggerHelperMcp("/mcp");        // Streamable HTTP  — Claude Code, Cursor, Copilot
app.MapLoggerHelperMcpSse();           // HTTP+SSE         — Claude Desktop, MCP Inspector

AI can now ask your app:

• "Are all sinks healthy?" → loggerhelper_get_health (OK / WARNING / CRITICAL)
• "Show me the last 10 logging errors" → loggerhelper_get_errors
• "What levels does the Email sink receive?" → loggerhelper_get_sinks
• "Is PII masking enabled?" → loggerhelper_get_config

Predefined prompt — run a full diagnostic with one command:

curl -X POST http://localhost:5000/mcp \
  -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","id":1,"method":"prompts/get","params":{"name":"diagnose-logging","arguments":{"focus":"all"}}}'

The diagnose-logging prompt instructs the AI to call all four tools and return a structured report with Overall Status, Failed Sinks, Configuration Issues, and Recommended Actions.

Why this matters: Every other .NET logging library requires a separate dashboard (Seq, Kibana, Grafana) before an AI assistant can see log state. LoggerHelper MCP ships that built in — zero extra infrastructure, zero extra dependencies, one NuGet package.

📋 Sink Overview

Each sink is a separate NuGet package — install only what you need. Click guide → for the full configuration reference, sample output, and troubleshooting for each sink.

Every sink uses the same routing pattern — just add the sink name to Routes:

"Routes": [
  { "Sink": "Console",       "Levels": ["Debug", "Information", "Warning"] },
  { "Sink": "File",          "Levels": ["Information", "Warning", "Error", "Fatal"] },
  { "Sink": "Elasticsearch", "Levels": ["Warning", "Error", "Fatal"] }
]

For per-sink configuration options (connection strings, paths, retention, custom columns), see the guide → linked in the table above.

📊 Comparison

🏗️ Architecture

LoggerHelper uses a zero-dependency plugin architecture. The core package has no knowledge of any specific sink — they self-register at startup via [ModuleInitializer].

Your App
  └── CSharpEssentials.LoggerHelper (core)
        ├── Bridges ILogger<T> → Serilog (zero allocations on hot path)
        ├── Routes events by level via pre-computed HashSet<LogEventLevel>
        ├── Exposes ILogErrorStore for sink failure diagnostics
        └── Discovers sink plugins automatically at startup
              ├── Sink.Console    (auto-registers via [ModuleInitializer])
              ├── Sink.File       (auto-registers)
              ├── Sink.Email      (auto-registers)
              └── ... any ISinkPlugin

Performance Focus

Every version ships a targeted performance audit. Key hot-path optimizations to date:

Building a Custom Sink

[LoggerHelperSink]
public sealed class MyTargetSinkPlugin : ISinkPlugin {
    public bool CanHandle(string sinkName) =>
        sinkName.Equals("MyTarget", StringComparison.OrdinalIgnoreCase);

    public void Configure(LoggerConfiguration loggerConfig, SinkRouting routing, LoggerHelperOptions options) {
        var opts = options.GetSinkConfig<MyTargetOptions>("MyTarget")
                   ?? options.BindSinkSection<MyTargetOptions>("MyTarget");

        loggerConfig.WriteTo.Conditional(
            evt => routing.Matches(evt.Level),
            wt => wt.MySink(opts?.ConnectionString)
        );
    }
}

public static class PluginInitializer {
    [ModuleInitializer]
    public static void Init() => SinkPluginRegistry.Register(new MyTargetSinkPlugin());
}

Reference CSharpEssentials.LoggerHelper as a NuGet package. The sink auto-registers with no changes to the core.

🤝 View Source & Contribute

If you're reading this on NuGet, we highly recommend visiting our GitHub Repository!

By visiting the repository you can:

• 👀 Explore the source code and evaluate the code quality.
• 🐛 Check open issues or report new ones.
• 🛠️ Contribute to the project via Pull Requests.
• ⭐ Drop a star to support the project's growth!

📚 Documentation & Links

• Documentation Site — full reference, guides, and playground
• Interactive Playground
• Changelog
• Benchmark Results
• Migration Guide v2/v4 → v5
• NuGet — LoggerHelper
• NuGet — HttpHelper
• GitHub Issues

License

MIT — Alessandro Chiodo

GitHub · NuGet · loggerhelper.com
