CShells 0.0.21

CShells

A modular multi-tenancy framework for .NET that enables building feature-based applications with isolated services, configuration, and background workers.

Purpose

CShells is the core runtime package that provides blueprint-driven shell activation, cooperative drain-based reload, feature discovery, per-shell DI containers, and configuration-driven multi-tenancy.

Key Features

• Multi-shell architecture — each shell has its own isolated DI container
• Feature-based modularity — features are discovered automatically via attributes
• Dependency resolution — features can depend on other features with topological ordering
• Configuration-driven — shells and their features are configured via appsettings.json or code
• Generation lifecycle — Initializing → Active → Deactivating → Draining → Drained → Disposed
• Cooperative reload — IShellRegistry.ReloadAsync(name) builds the next generation while draining the previous one; in-flight request scopes finish against the old provider
• Observable events — IShellLifecycleSubscriber receives every state transition
• Configurable drain policies — fixed, extensible, and unbounded timeouts

Installation

dotnet add package CShells

Quick Start

1. Create a Feature

using CShells.Features;
using Microsoft.Extensions.DependencyInjection;

[ShellFeature("Core", DisplayName = "Core Services")]
public class CoreFeature : IShellFeature
{
    public void ConfigureServices(IServiceCollection services)
    {
        services.AddSingleton<ITimeService, TimeService>();
    }
}

2. Configure Shells

{
  "CShells": {
    "Shells": {
      "Default": {
        "Features": { "Core": {} }
      }
    }
  }
}

3. Register CShells

var builder = Host.CreateApplicationBuilder(args);
builder.Services.AddCShells(cshells =>
    cshells.WithConfigurationProvider(builder.Configuration));

var app = builder.Build();
app.Run();

Shell Scopes & Background Work

IShell.BeginScope() returns a tracked IShellScope that (a) exposes a scoped IServiceProvider built from the shell's container and (b) delays drain-handler invocation while the scope is outstanding:

public class ShellBackgroundWorker(IShellRegistry registry) : BackgroundService
{
    protected override async Task ExecuteAsync(CancellationToken stoppingToken)
    {
        while (!stoppingToken.IsCancellationRequested)
        {
            foreach (var name in registry.GetBlueprintNames())
            {
                var shell = registry.GetActive(name);
                if (shell is null) continue;

                await using var scope = shell.BeginScope();
                var service = scope.ServiceProvider.GetService<IMyService>();
                service?.Execute();
            }

            await Task.Delay(TimeSpan.FromSeconds(30), stoppingToken);
        }
    }
}

Code-First Shell Registration

builder.Services.AddCShells(cshells =>
{
    cshells.AddShell("Default", shell => shell
        .WithFeatures("Core", "Weather")
        .WithConfiguration("Theme", "Dark")
        .WithConfiguration("MaxItems", "100"));
});

Per-Shell Initialization & Drain

Register IShellInitializer services for per-shell startup work and IDrainHandler services for cooperative shutdown:

public class PaymentsFeature : IShellFeature
{
    public void ConfigureServices(IServiceCollection services)
    {
        services.AddSingleton<IPaymentProcessor, StripePaymentProcessor>();
        services.AddShellInitializer<RunPaymentMigrations>(
            LifecyclePhase.Prepare,
            order: 100);
        services.AddShellInitializer<StartPaymentProcessor>(
            LifecyclePhase.Start,
            order: 100);
        services.AddTransient<IDrainHandler, PaymentsDrainHandler>();
    }
}

Initializers run sequentially during Initializing -> Active. Existing direct IShellInitializer registrations still run in DI-registration order in LifecyclePhase.Default; AddShellInitializer<T>() adds explicit phase/order metadata and registers the initializer as transient. Drain handlers run in parallel during Draining, after all outstanding IShellScope handles have been released or the drain deadline elapses.

Reload

var result = await registry.ReloadAsync("payments");

// result.NewShell.Descriptor.Generation == previous + 1
// result.Drain (when non-null) is the cooperative drain on the previous generation.
if (result.Drain is not null)
    await result.Drain.WaitAsync();

Learn More

• Main Documentation
• ASP.NET Core Integration
• FluentStorage Provider
