EasyOcrSharp 1.0.2

<div align="center"> <img src="src/EasyOcrSharp/Assets/icon.gif" alt="EasyOcrSharp Logo" width="128" height="128"> <h1>EasyOcrSharp</h1>

</div>

High-accuracy OCR for .NET 9 powered by the EasyOCR Python library. EasyOcrSharp uses a two-package architecture with a pre-bundled Python runtime, so you can ship a single .NET package without requiring users to install Python or download dependencies at runtime.

First run tip: The very first launch copies the optimized Python runtime, bootstraps pip, and (optionally) downloads GPU components. Please keep the app open and connected to the internet until this finishes—subsequent runs start instantly and work offline.

Architecture

EasyOcrSharp uses a two-package architecture for optimal performance and reliability:

📦 EasyOcrSharp (Main Package)

• Contains only C# logic and API
• Lightweight and fast
• Automatically references EasyOcrSharp.Runtime as a dependency
• Downloads only language models on-demand (first run)

🐍 EasyOcrSharp.Runtime (Runtime Package)

• Contains pre-bundled Python 3.11 embedded runtime
• Includes all required site-packages:
  • easyocr
  • torch, torchvision
  • pillow, numpy
  • opencv-python-headless
  • All EasyOCR dependencies
• NO models (models download separately on-demand)
• Automatically installed when you install EasyOcrSharp

⚡ Runtime Behavior

When your app references EasyOcrSharp:

1. NuGet automatically installs EasyOcrSharp.Runtime
2. On first call, the library uses the Python runtime directly from the NuGet cache (no copying needed)
3. Only models are downloaded on-demand and cached permanently in LocalAppData
4. No pip, no Python downloads, no dependency installations
5. After models download once → full offline operation

Features

• ✅ Zero Python installation required – Python 3.11 is pre-bundled in the runtime package
• ✅ Zero runtime downloads – Python and dependencies are pre-bundled, only models download on-demand
• ✅ Fast first run – Only model downloads happen on first use (no Python/dependency downloads)
• ✅ Async C# API with automatic GPU detection and multilingual support
• ✅ Image OCR – Extract text from image files (PNG, JPEG, GIF, BMP, TIFF)
• ✅ Multilingual OCR – Process multiple languages in parallel for better accuracy
• ✅ Automatic Language Grouping – Intelligently groups languages for optimal OCR performance
• ✅ Language Compatibility Handling – Automatically handles language dependencies (e.g., Arabic, Thai, Chinese)
• ✅ Bounding box coordinates and polygon points for each recognized line
• ✅ Automatic English inclusion for non-Latin scripts (Hindi, Arabic, etc.)
• ✅ UTF-8 console encoding support for proper Unicode character display
• ✅ Lightweight logging via Microsoft.Extensions.Logging
• ✅ Example console app demonstrating end-to-end usage

Installation

Install EasyOcrSharp via NuGet Package Manager:

dotnet add package EasyOcrSharp

Or via Package Manager Console:

Install-Package EasyOcrSharp

Or add it directly to your .csproj file:

<PackageReference Include="EasyOcrSharp" Version="1.0.0" />

The EasyOcrSharp.Runtime package is automatically installed as a dependency. You don't need to reference it directly.

Prerequisites

• .NET SDK 9.0 or later - Required to build and run applications using EasyOcrSharp
• Internet access on first run (models only) - Required only to download language models on first use
• NO Python installation needed - Python 3.11 is pre-bundled in EasyOcrSharp.Runtime
• NO pip, NO wheel downloads - All Python dependencies are pre-bundled

Important:

• Python 3.11 and all dependencies (easyocr, torch, pillow, numpy, etc.) are pre-bundled in EasyOcrSharp.Runtime
• Only language models are downloaded on-demand on first use
• Models are cached permanently after first download
• After models are cached, full offline operation is possible
• First run is fast - only model downloads occur (typically 10-50 MB per language)

Supported Languages

EasyOcrSharp supports 80+ languages through EasyOCR. Here's the complete list:

Note: Language codes are case-insensitive. Use lowercase codes (e.g., "en", "hi", "ar") for consistency.

For the most up-to-date list and language code details, see the EasyOCR documentation.

Quick Start

Basic Usage

using EasyOcrSharp.Services;
using Microsoft.Extensions.Logging;

var loggerFactory = LoggerFactory.Create(builder =>
{
    builder.AddSimpleConsole();
    builder.SetMinimumLevel(LogLevel.Information);
});

// Use default embedded Python runtime (from EasyOcrSharp.Runtime package)
// Models will be cached in LocalAppData\EasyOcrSharp\models by default
await using var ocr = new EasyOcrService(logger: loggerFactory.CreateLogger<EasyOcrService>());

// Or specify a custom path for model downloads
await using var ocr = new EasyOcrService(
    modelCachePath: @"D:\MyApp\Models",
    logger: loggerFactory.CreateLogger<EasyOcrService>());

// Extract text from an image with specified languages
// GPU is automatically detected and used if available
// Models are downloaded on-demand on first use
var result = await ocr.ExtractTextFromImage("sample.png", new[] { "en", "hi", "ar" });

Console.WriteLine(result.FullText);

foreach (var line in result.Lines)
{
    if (!line.BoundingBox.IsEmpty)
    {
        var bbox = line.BoundingBox;
        Console.WriteLine(
            $"{line.Text} (confidence {line.Confidence:P1}) " +
            $"bbox=([{bbox.MinX:F1}, {bbox.MinY:F1}] → [{bbox.MaxX:F1}, {bbox.MaxY:F1}])");
    }
    else
    {
        Console.WriteLine($"{line.Text} (confidence {line.Confidence:P1})");
    }
}

Advanced Features

Multilingual OCR

EasyOcrSharp automatically handles multilingual images by:

• Grouping languages for optimal compatibility (e.g., Arabic requires specific companions)
• Processing language groups in parallel for better performance
• Merging and deduplicating results from multiple language groups
• Automatically including English when using non-Latin scripts (Hindi, Arabic, Bengali, etc.)

// Process image with multiple languages
// The library will automatically:
// 1. Group languages: ["ar", "fa", "ur", "ug", "en"] and ["hi", "en"]
// 2. Run OCR in parallel for each group
// 3. Merge and deduplicate results
// 4. Download models on-demand if not cached
var result = await ocr.ExtractTextFromImage("multilingual.png", new[] { "en", "hi", "ar" });

Language Compatibility

Some languages have specific compatibility requirements:

• Arabic (ar): Can only work with ["ar", "fa", "ur", "ug", "en"]. Other languages will be processed in separate groups.
• Thai (th): Requires English to be included.
• Chinese/Japanese/Korean: Require English (ch_sim, ch_tra, zh_sim, zh_tra, ja, ko).
• Non-Latin scripts: English is automatically added for better multilingual support (Hindi, Bengali, Telugu, etc.).

The library handles these automatically - you just specify the languages you want, and it groups them appropriately.

Processing Image Streams

You can also process images from streams without saving to disk:

await using var ocr = new EasyOcrService(logger: loggerFactory.CreateLogger<EasyOcrService>());

using var imageStream = File.OpenRead("sample.png");
var result = await ocr.ExtractTextFromImage(imageStream, new[] { "en", "hi" }, "sample.png");

Console.WriteLine(result.FullText);

Result Structure

The OcrResult object contains:

• FullText: Concatenated text from all detected lines
• Lines: Collection of OcrLine objects with detailed information
• Languages: Languages used during recognition
• Duration: Time taken for OCR processing
• UsedGpu: Whether GPU acceleration was used

Each OcrLine includes:

• Text: Extracted text
• Confidence: Recognition confidence (0.0 to 1.0)
• BoundingBox: Rectangular bounding box coordinates
• BoundingPolygon: Four-point polygon coordinates

Example output format:

- Hello world (confidence: 98.5 %) bbox=([12.1, 34.7] → [220.4, 58.9])

JSON output example:

{
  "fullText": "Hello world\nLorem ipsum",
  "lines": [
    {
      "text": "Hello world",
      "confidence": 0.985,
      "boundingPolygon": [
        { "x": 12.1, "y": 34.7 },
        { "x": 220.4, "y": 34.7 },
        { "x": 220.4, "y": 58.9 },
        { "x": 12.1, "y": 58.9 }
      ],
      "boundingBox": {
        "minX": 12.1,
        "minY": 34.7,
        "maxX": 220.4,
        "maxY": 58.9,
        "width": 208.3,
        "height": 24.2,
        "centerX": 116.25,
        "centerY": 46.8,
        "isEmpty": false
      }
    }
  ],
  "languages": ["en"],
  "duration": "2.45s",
  "usedGpu": false
}

Configuration

Python Runtime

EasyOcrSharp uses the pre-bundled Python runtime from EasyOcrSharp.Runtime:

• No Python installation required!
• Python 3.11 is pre-bundled in EasyOcrSharp.Runtime package
• Used directly from NuGet cache (no copying needed)
• Works out of the box - just use the library
• All required packages are pre-installed: easyocr, torch, torchvision, pillow, numpy, opencv-python-headless

// Uses pre-bundled runtime from NuGet cache automatically
await using var ocr = new EasyOcrService(logger: logger);

Cache Location

• Python Runtime: Used directly from NuGet cache at %USERPROFILE%\.nuget\packages\easyocrsharp.runtime\<version>\tools\python_runtime (Windows) or equivalent on Linux/macOS. No copying required - the runtime is accessed directly from the installed package location.
• Language Models: Downloaded and cached by default in %LOCALAPPDATA%\EasyOcrSharp\models (Windows) or equivalent on Linux/macOS. You can specify a custom path using the modelCachePath parameter in the EasyOcrService constructor.
• Models are cached permanently after first download
• Language models are downloaded automatically on first use (may take a few minutes depending on network speed)

Custom Model Cache Path

You can specify a custom directory for downloading and caching language models:

// Use a custom path for model downloads
await using var ocr = new EasyOcrService(
    modelCachePath: @"D:\MyApp\Models",
    logger: loggerFactory.CreateLogger<EasyOcrService>());

Benefits of custom model cache path:

• Store models in a location with more disk space
• Share models across multiple applications
• Use a network drive for centralized model storage
• Better control over model storage location

If not specified, models are cached in %LOCALAPPDATA%\EasyOcrSharp\models (Windows) or the equivalent location on Linux/macOS.

Logging

EasyOcrSharp uses Microsoft.Extensions.Logging for diagnostic output. Configure any logging provider (console, file, Serilog, NLog, etc.) to capture logs.

Console Logging

var loggerFactory = LoggerFactory.Create(builder =>
{
    builder.AddSimpleConsole();
    builder.SetMinimumLevel(LogLevel.Information);
});
var ocr = new EasyOcrService(logger: loggerFactory.CreateLogger<EasyOcrService>());

File Logging

You can use third-party libraries like Serilog or NLog for file logging:

Serilog Example:

using Serilog;

Log.Logger = new LoggerConfiguration()
    .WriteTo.File("easyocrsharp.log")
    .CreateLogger();

var loggerFactory = LoggerFactory.Create(builder =>
{
    builder.AddSerilog();
});
var ocr = new EasyOcrService(logger: loggerFactory.CreateLogger<EasyOcrService>());

NLog Example:

var loggerFactory = LoggerFactory.Create(builder =>
{
    builder.AddNLog();
});
var ocr = new EasyOcrService(logger: loggerFactory.CreateLogger<EasyOcrService>());

Logging Levels

• Information: Initialization, language grouping, GPU detection, OCR completion, model downloads
• Warning: Language compatibility issues, GPU detection failures
• Debug: Detailed Python initialization, sys.path information

Known Limitations

Python 3.13 Incompatibility

Currently, pythonnet 3.0.5 (used for Python interop) is incompatible with Python 3.13. Python 3.13 removed the PyThreadState_GetUnchecked API that pythonnet requires.

The pre-bundled runtime in EasyOcrSharp.Runtime uses Python 3.11, which is fully compatible.

Example Application

An example console application is included in the repository under test/. To run it:

dotnet run --project test/Test.EasyOcrSharp.csproj

The application provides an interactive menu to:

• Run OCR on images with custom language selection
• View cache location
• Clear console

The application automatically:

• Sets UTF-8 console encoding for proper Unicode display (Hindi, Arabic, etc.)
• Configures JSON serialization to display Unicode characters correctly
• Shows language grouping information in logs

Platform Support

EasyOcrSharp is cross-platform and supports:

• ✅ Windows (x64, ARM64)
• ✅ Linux (x64, ARM64)
• ✅ macOS (x64, ARM64)

Performance Tips

1. GPU Acceleration: The library automatically detects and uses GPU if available. For best performance, ensure CUDA-compatible GPU drivers are installed.

2. Language Selection: Only specify languages you actually need. Processing fewer languages is faster.

3. Model Caching: Models are cached after first download. Subsequent runs are much faster.

4. Parallel Processing: The library automatically processes language groups in parallel for multilingual images.

Contributing

Contributions are welcome! Please feel free to submit a Pull Request.

1. Fork the repository
2. Create your feature branch (git checkout -b feature/AmazingFeature)
3. Commit your changes (git commit -m 'Add some AmazingFeature')
4. Push to the branch (git push origin feature/AmazingFeature)
5. Open a Pull Request

Building from Source

To build the library from source:

git clone https://github.com/easyocrsharp/EasyOcrSharp.git
cd EasyOcrSharp
dotnet build

To create NuGet packages:

dotnet pack src/EasyOcrSharp/EasyOcrSharp.csproj -c Release
dotnet pack src/EasyOcrSharp.Runtime/EasyOcrSharp.Runtime.csproj -c Release

The generated .nupkg files will be placed under src/EasyOcrSharp/bin/Release/ and src/EasyOcrSharp.Runtime/bin/Release/.

Note: The EasyOcrSharp.Runtime package includes the complete Python 3.11 runtime with all required site-packages. Only minimal exclusions are applied (cache files, specific problematic test data paths, and vendor directories with long paths) to ensure all required modules (including torch.testing, numpy._core.tests, etc.) are included.

License

Distributed under the MIT License. See LICENSE for details.

Acknowledgments

• EasyOCR - The underlying OCR engine
• pythonnet - Python.NET interop library

Support

• 📦 NuGet Package: EasyOcrSharp on NuGet
• 🐛 Issues: GitHub Issues
• 📖 Documentation: See this README and inline XML documentation

<div align="center"> Made with ❤️ for the .NET community </div>
