Icod.DCurses 0.5.0

Icod.DCurses

Icod.DCurses is a managed, cross-platform curses-like terminal UI library for .NET.

The library sits above Icod.TermInfo and Icod.Terminal. Icod.TermInfo remains the immutable terminal-capability authority; Icod.Terminal owns the live terminal session, host mode, dimensions, lifecycle, input decoding, and reversible presentation and input-protocol leases. Icod.DCurses owns curses-shaped events, virtual screens and windows, pads and viewports, terminal cells and styles, rendition policy, and refresh/damage synchronization.

Status

Icod.DCurses 0.4.0 is the current published stable release.

Development toward 1.0.0 continues on the 0.5.0 pads and large-surfaces line. The source version and package version are now stable 0.5.0; publication remains post-merge until the matching main commit passes the Release matrix and v0.5.0 is created.

T501-T503 established the pad backing surface and direct rectangular presentation. A CursesPad owns a large off-screen logical surface and exposes a normal CursesWindow through ContentWindow, so the stable Unicode, editing, composition, drawing, and damage contracts are reused rather than reimplemented.

T504 added independently pannable CursesPadViewport instances with SetSource, PanBy, and Present. One pad may be shown through multiple viewports without a global pad scroll position.

T505 deliberately reuses ContentWindow.CreateSubwindow(...) as the shared derived-pad-view contract instead of adding a redundant CursesSubpad type. T506 adds independent per-viewport HasVisiblePadChanges observation. There is no public global pad-clean/acknowledge operation, so one viewport cannot hide changes from another.

T507 is complete and green on Windows, Linux, macOS, and package-only validation. It covers destination resize/reposition, all pad corners, wide-cell boundaries, very tall and wide pads, repeated panning, editor-like mutations, and fresh package consumption.

T508 is complete. The 0.5 public surface is feature-frozen and machine-guarded; per-cell viewport revision tracking is internal and enabled only for pad backing surfaces, so ordinary logical screens retain their pre-0.5 memory profile. The complete alpha.4 contract passed Windows, Linux, macOS, and canonical package/fresh-consumer validation without a public-contract correction.

T509 release-candidate validation is also complete: 0.5.0-rc.1 passed Windows, Linux, macOS, and canonical package/fresh-consumer validation without requiring a correction. The unchanged contract has been promoted to stable 0.5.0 source for one final PR gate before merge.

Earlier stable releases established:

• 0.4.0: Unicode-safe window geometry, editing, composition, drawing, and damage-range operations;
• 0.3.0: Unicode 17 terminal-cell semantics and column-safe text helpers;
• 0.2.0: complete stable Icod.Terminal 1.0.0 semantic input parity.

The dependency baseline remains:

• Icod.Terminal 1.0.0
• Icod.TermInfo 1.10.0

The retired DCurses backend, native mode, lifecycle-source, input-decoder, and pre-Terminal session implementations remain removed. DCurses does not add a mouse parser, paste reader, protocol escape emitter, keyboard decoder, or second input loop.

The first release line was driven by the requirements of top, slabtop, and watch. The 1.0 development train broadens that foundation into a general managed TUI contract.

See Icod.DCurses-1.0.0-Development-Roadmap.md for the authoritative release train through 1.0.0, and Icod.DCurses-0.5.0-Development-Roadmap.md for the active pad/large-surface tranche. Current 0.5 decisions and gates are recorded in:

• docs/T504-Stateful-Pad-Viewport-and-Panning.md
• docs/T505-T506-Derived-Pad-Views-and-Damage.md
• docs/T507-Resize-Clipping-and-Large-Surface-Acceptance.md
• docs/T508-Public-API-Documentation-and-Package-Regret-Gate.md
• docs/T509-0.5.0-Stable-Release-Closure.md
• docs/Public-API-Baseline-0.5.md

The completed 0.4 window-editing release is recorded in Icod.DCurses-0.4.0-Development-Roadmap.md, its T402-T409 documents, and docs/Public-API-Baseline-0.4.md.

The completed 0.3 Unicode release is recorded in Icod.DCurses-0.3.0-Development-Roadmap.md, its T302-T308 documents, and docs/Public-API-Baseline-0.3.md.

Icod.DCurses-0.2.0-Development-Roadmap.md and docs/Public-API-Baseline-0.2.md record the stable semantic-input release. docs/Dependency-Baseline-0.1.1.md retains the Terminal/TermInfo ownership baseline inherited by later releases.

Icod.DCurses-Development-Roadmap.md retains the original project roadmap and 0.1 development history. Historical integration checkpoints remain under docs/.

Architecture

top / slabtop / watch / editors / pagers / other TUIs
                         |
                    Icod.DCurses
       windows / pads / cells / refresh
         rendition / curses events
                         |
                    Icod.Terminal
      session / input / lifecycle / dimensions
       presentation / input-protocol leases
                         |
                    Icod.TermInfo
             terminal capability model
                         |
                  terminal / tty

Icod.DCurses does not hard-code one terminal family. Terminal-specific output continues to be selected through Icod.TermInfo, while live session ownership and reversible terminal state are centralized in Icod.Terminal.

Target

The implementation targets:

• .NET 8
• .NET 9
• .NET 10
• C# 13
• Windows
• Linux
• macOS

Installation

The current published stable package is:

dotnet add package Icod.DCurses --version 0.4.0

Quick start

using Icod.DCurses;

await using CursesSession session = await CursesSession.OpenAsync();
CursesWindow screen = session.StandardScreen;

screen.Clear();
screen.Move(
    0,
    0
);
screen.Write(
    "Hello from Icod.DCurses",
    new CursesStyle(
        CursesColor.Default,
        CursesColor.Default,
        CursesTextAttributes.Bold
    )
);
await session.RefreshAsync();

CursesEvent terminalEvent = await session.ReadEventAsync();

The session owns the presentation state it enters and restores that state when disposed. Applications should consume terminal input and lifecycle activity through CursesSession rather than adding a parallel terminal reader.

Pads and large surfaces (0.5)

Pads are in-memory off-screen logical surfaces. They reuse ordinary CursesWindow editing semantics and can be larger than the destination terminal screen:

CursesPad pad = new( 200, 5_000 );
CursesWindow content = pad.ContentWindow;

content.Move( 100, 20 );
content.Write( "A界B — large logical document" );

CursesWindow editor = session.StandardScreen;
CursesPadViewport viewport = pad.CreateViewport(
    editor,
    padRow: 95,
    padColumn: 10,
    rows: 20,
    columns: 70,
    destinationRow: 1,
    destinationColumn: 2
);

viewport.Present();
await session.RefreshAsync();

viewport.PanBy( 10, 0 );
if ( viewport.HasVisiblePadChanges ) {
    viewport.Present();
    await session.RefreshAsync();
}

HasVisiblePadChanges reports whether the currently visible pad source moved or changed since that viewport last presented. It does not claim ownership of the destination. Present() remains authoritative and will restore the viewport if another logical window overwrote its destination region.

Multiple viewports can observe one pad independently. Presenting one does not acknowledge changes for another. Shared pad-local views use pad.ContentWindow.CreateSubwindow(...); no separate subpad hierarchy is required.

Pads do not own terminal sessions or physical refresh state, and they do not resize merely because the terminal resizes. Viewport geometry is revalidated against the current destination on every presentation.

Window editing and composition (0.4)

The 0.4 line adds window-local editing and composition while retaining the shared-view model:

CursesScreen logical = new( 80, 24 );
CursesWindow editor = logical.CreateWindow( 2, 4, 18, 60 );

editor.Reposition( 3, 5 );
editor.FillRectangle( 0, 0, 18, 60, CursesCell.Blank() );
editor.Move( 1, 2 );
editor.Write( "A界B" );
editor.InsertCells( 2 );

CursesWindow status = logical.CreateWindow( 21, 5, 1, 60 );
editor.CopyRectangleTo( status, 1, 0, 1, 20, 0, 0 );

editor.DrawHorizontalLine( 16, 1, 58, new CursesCell( "-" ) );
editor.TouchRegion( 0, 0, 18, 60 );
bool needsRefresh = editor.IsRegionTouched( 0, 0, 18, 60 );

CopyRectangleTo includes source blanks; OverlayRectangleTo treats ordinary source blanks as transparent. Overlapping copies snapshot the source before any destination write. Editing and drawing preserve the cursor and retain the 0.3 wide-cell invariants.

Drawing methods accept caller-supplied one-column cells in 0.4. Capability-aware Unicode/alternate-character-set line-glyph selection is intentionally deferred to the 0.6 presentation tranche.

Unicode column helpers (0.3)

Applications can measure or trim printable text using the same terminal-column contract as window writes:

int columns = CursesText.MeasureColumns( "A界B" );
string prefix = CursesText.TruncateToColumns( "A界B", 3 );
string slice = CursesText.SliceByColumns( "A界B", 1, 2 );

The default provider uses Unicode 17.0.0 data and treats East Asian Ambiguous characters as narrow. Applications that deliberately require wide-Ambiguous semantics can pass UnicodeCursesTextWidthProvider.WideAmbiguousInstance to a CursesScreen or to the CursesText helpers.

Column helpers normalize malformed UTF-16 before text-element segmentation, reject terminal controls, and never return half of a two-column text element.

Modern keyboard input (0.2)

Applications which want key-event phases can request them through the curses protocol lease without using Terminal protocol types directly:

var keyboard = await session.AcquireInputProtocolsAsync(
    new CursesInputProtocolOptions {
        KeyboardReportingMode = CursesKeyboardReportingMode.EventTypes
    }
);

if ( keyboard.IsAvailable ) {
    await using CursesInputProtocolLease lease = keyboard.GetRequiredValue();
    CursesEvent current = await session.ReadEventAsync();

    if ( current.Input is {
        Kind: CursesInputEventKind.Key
    } input ) {
        CursesKey key = input.Key;
        CursesKeyEventPhase? phase = input.KeyPhase;
        CursesKeyModifiers modifiers = input.Modifiers;
    }
}

Keyboard reporting is optional. A terminal which cannot provide the requested mode returns a controlled unavailable result; applications can continue using the ordinary curses input stream.

Build

From the repository root:

build.cmd

or:

./build.sh

Both wrappers delegate to packaging/Invoke-Build.ps1 and use the Debug configuration for local development. With no section argument they perform restore, build, test, pack, and package validation. They also accept clean, restore, build, test, pack, or validate; prerequisite phases are run automatically where needed.

Pull-request validation promotes the build to Staging. Pushes to main and release tags use Release. Package validation exercises the packed artifact and a fresh package-only consumer rather than relying only on the repository project references.

The Unicode width-data generator is a maintainer tool outside the solution. See tools/unicode-width-generator/README.md; normal builds do not fetch Unicode data from the network.

Authors

Timothy J. Bruce.

Copyright

Copyright (c) 2026 Timothy J. Bruce

License

Licensed under the GNU Lesser General Public License v3.0 or later. See LICENSE.

The NuGet package declares license acceptance as required. Package clients which honor NuGet's requireLicenseAcceptance metadata must obtain acceptance of the license terms before installation.
