🚀 Lukbes.CommandLineParser

A CommandlineParser used to define command line arguments for projects of small but also bigger sizes.

✨ Features

• Create custom arguments
• Use custom rules for your arguments
• Define custom types and converters for your arguments
• Create dependencies between multiple arguments
• Define how the argument's format should be
• Freedom of choice for Exceptions vs. Error return messages
• Builder pattern for creation of arguments and parser

📦 Installation

Install via cmdline from NuGet or within the Nuget browser in your IDE:

dotnet add package Lukbes.CommandLineParser

Quick setup

The following code shows the minimal setup needed for you to get started:

  CommandLineParser.WithExceptions = false; //Optionally disable Exceptions (false is default)
  string[] args = ["-n='myName'"];
  Argument<string> nameArg = Argument<string>.Builder()
                .Identifier(new("n", "name"))
                .Build();

  CommandLineParser parser = CommandLineParser.Builder()
                .Argument(nameArg)
                .Build();

  List<string> errors = await parser.ParseAsync(args);
  //Retrieve value
  Console.WriteLine(nameArg.Value);

The example code shows a basic Application using -n or --name as an argument of type string. The result of the

The following is a subset of what the argument would allow: -n=MyName, -n="My Other Name", -name=Hello, -name='Lukbes'... . See Allowed formats for more

Preface

We often tend to bloat applications with exceptions, even if they are not necessary at all times.

Therefore, you can turn on or off exceptions whenever you like via CommandLineParser.WithExceptions = true (or false).

If set to false, you can rely on the List<string> of errors returned by all methods.

Arguments

To create and use your arguments you use the class Argument<T>, where T is the type of your argument.

An Argument consists of an identifier ArgumentIdentifier and a Description, a set of rules IRule<T> and a set of dependencies to other Arguments IDependency. An Argument can be Required or optional and have a DefaultValue

• ArgumentIdentifier: The unique identifier for an Argument consisting of a shortIdentifier - and a longIdentifier --. shortIdentifier is not constrained to one char.
• IRule<T>: The rules that will be applied onto this argument. E.g. Must be an HttpLink or Directory. It's checked if and only if the Argument exists and has a value
• IDependency: The Dependency constraints that will be checked after the rules where checked. This contains things such as 'Must exist when xyz exists', 'If this exists, force xyz and abc... to exist' etc. .

Identifier

   var nameArg = Argument<string>.Builder()
                .Identifier(new("n", "name"))
                .Build();

Only Short/Long identifier

   var nameArg = Argument<string>.Builder()
                .ShortIdentifier("n")
                .Build();

   var longNameArg = Argument<string>.Builder()
                .LongIdentifier("name")
                .Build();

Required

    var nameArg = Argument<string>.Builder()
                .Required()
                .ShortIdentifier("n")
                .Build();

DefaultValue

    var nameArg = Argument<string>.Builder()
                .DefaultValue("Tom")
                .ShortIdentifier("n")
                .Build();

Description

    var nameArg = Argument<string>.Builder()
                .Description("The name")
                .ShortIdentifier("n")
                .Build();

Converter

When defining your Argument type as e.g. string or int, a default converter of type IConverter<T> where T is the result type is used behind the scenes.

If you don't like the implementation of the default converters, you have some options to change, add or remove them:

Custom Converter

You can implement the IConverter<T> interface and thus create a new Converter for the type T.

The following example shows a point class and a custom converter for this class:

     private readonly struct CustomPoint
     {
         public readonly int X;
         public readonly int Y;
         public CustomPoint(int x, int y) => (X,Y) = (x, y);
         public override string ToString()
         {
             return "{" + X + ", " + Y + "}";
         }
     }

    private class CustomPointConverter : IConverter<CustomPoint>
    {
        //Return the errors, or null if successfully
        public string? TryConvert(string? value, out CustomPoint result)
        {
            result = default;
            if (string.IsNullOrEmpty(value))
            {
                return "Point must not be null";
            }
            value = value.Trim();
            var values = value.Split(";");
            if (values.Length != 2)
            {
                return "There must be exactly two values";
            }
            bool successX = int.TryParse(values[0], out var x);
            if (!successX)
            {
                return "X value was not valid! Actual: " + values[0];
            }

            bool successY = int.TryParse(values[1], out var y);
            if (!successY)
            {
                return "Y value was not valid! Actual: " + values[1];
            }
            result = new CustomPoint(x, y);
            return null;
        }
    }

Now that we have the converter, we can add it to our argument:

 CommandLineParser.WithExceptions = false;
 /* var pointArg = Argument<CustomPoint>.Builder()
                .Identifier(new("p", "Point"))
                .Description("The coordinate of the block")
                .Build();
                Would not work, because you have to specify a converter for this type
                Certain types are predefined, see DefaultConverterFactory.Types */

 var pointArg = Argument<CustomPoint>.Builder()
     .Identifier(new("p", "Point"))
     .IsRequired()
     .Description("The coordinate of the point")
     .Converter(new CustomPointConverter()) //<- The custom converter
     .Build();

DefaultConverterFactory

The DefaultConverterFactory manages the default converters. The predefined types can be retrieved via

List<Type> types = DefaultConverterFactory.Types;

To complete our CustomPoint example, we could add the CustomPointConverter to the defaults, removing the need to add .Converter(new CustomPointConverter()) to every Argument of type CustomPoint:

   bool success = DefaultConverterFactory.TryAdd(new CustomPointConverter());
   foreach (var type in DefaultConverterFactory.Types) //Demonstrating that the type is actually registered (and the others)
   {
       Console.WriteLine(type.GetFriendlyTypeName()); //Type extension method
   }

   var pointArg = Argument<CustomPoint>.Builder()
       .Identifier(new("p", "Point"))
       .IsRequired()
       .Description("The coordinate of the block")
       .Build(); //No custom converter needed anymore

Converter for Lists:

The default types also have an implementation of IConverter<List<T>>, which means you can use e.g. Argument<List<int>> or Argument<List<string>> etc. without specifiying a converter.

To use a List of our CustomPoint, we have to ensure, that:

1. We Specified a Converter via .Converter(new CustomPointConverter())or added it via DefaultConverterFactory.TryAdd(new CustomPointConverter());
2. We Add a list converter via .ListTypeConverter<CustomPoint>() which enables it to search for our CustomPointConverter that we added in step 1. Or we add a new default converter via DefaultConverterFactory.TryAddList<CustomPoint>();

Step 1 can be skipped if we directly add a new ListConverter<CustomPoint> via .ListTypeConverter<CustomPoint>(new CustomPointConverter()) or via DefaultConverterFactory.TryAddList<CustomPoint>(new CustomPointConverter()). However this approach does not enable us to use Argument<CustomPoint>.Builder()... implicitly, without specifying it explicitly like in the example.

Final example:

DefaultConverterFactory.TryAddList<CustomPoint>(new CustomPointConverter()); //Creating a default only for List<CustomPoint>

var points = Argument<List<CustomPoint>>.Builder()
    .Identifier(new("p", "Points"))
    .IsRequired()
    .Description("The coordinate of the block")
    .Build();

var otherParser = CommandLineParser.Builder().Argument(points).Build();
string[] args = ["-p=10;30,20;40,30;-5"];
var otherErrors = await otherParser.ParseAsync(args);
if (otherErrors.Count == 0)
{
    Console.WriteLine("Worked! ");
    foreach (var point in points.Value)
    {
        Console.WriteLine(point.ToString());
    }
}

Result:

Worked!
{10, 30}
{20, 40}
{30, -5}

Rules

To further constrain your arguments to some rule, you can implement the IRule<T> interface.

Lets say we want our points argument to take at minimum 1 point and at maximum 3 points. For this, we first create a size boundary checking rule for any given Type:

/// <summary>
/// Custom Rule for boundary checks
/// </summary>
private class ListCountBetweenXAndY<T> : IRule<List<T>>
{
    private readonly int _lowerBound;
    private readonly int _upperBound;
    public ListCountBetweenXAndY(int lowerBound, int upperBound)
    {
        _lowerBound = lowerBound;
        _upperBound = upperBound;
    }
    //Returns null on success, an error message otherwise
    public string? Validate(Argument<List<T>> argument)
    {
        if (argument.Value!.Count < _lowerBound || argument.Value.Count > _upperBound)
        {
            return $"Count of list must be between {_lowerBound} and {_upperBound}";
        }
        return null;
    }
}

Now, to have that rule take affect, we can throw it onto the argument:

DefaultConverterFactory.TryAddList<CustomPoint>(new CustomPointConverter());

var points = Argument<List<CustomPoint>>.Builder()
    .Identifier(new("p", "Points"))
    .IsRequired()
    .Rule(new ListCountBetweenXAndY<CustomPoint>(1, 3)) //Setting the boundary to inclusive 1-3
    .Description("The coordinate of the block")
    .Build();

var otherParser = CommandLineParser.Builder().Argument(points).Build();
string[] args = ["-p=10;30,20;40,30;-5,109;2"]; //Will fail, because it has 4 values!
var otherErrors = await otherParser.ParseAsync(args);
if (otherErrors.Count == 0)
{
    Console.WriteLine("Worked! ");
    foreach (var point in points.Value)
    {
        Console.WriteLine(point.ToString());
    }
}
else
{
    foreach (var error in otherErrors)
    {
        Console.WriteLine(error);
    }
}

Result:

Rule failed for '-p, --Points'. Tried value: '10;30,20;40,30;-5,109;2'. Rule: Count of list must be between 1 and 3

Another example may be to Have a CustomPoint be non-negative in our example. There are two ways to solve this:

1. Create a new Rule implementing IRule<List<CustomPoint>>
2. Use the ListRule<CustomPoint> class

Option 1:

private class NonNegativePoints : IRule<List<CustomPoint>>
{
    public string? Validate(Argument<List<CustomPoint>> argument)
    {
        if (argument.Value!.Any(p => p.X < 0 || p.Y < 0))
        {
            return $"X and Y cannot be negative";
        }
        return null;
    }
}

//Then use it like so:

var points = Argument<List<CustomPoint>>.Builder()
                .Identifier(new("p", "Points"))
                .IsRequired()
                .Rule(new ListCountBetweenXAndY<CustomPoint>(1, 3))
                .Rule(new NonNegativePoints()) //<- Our new Rule
                .Description("The coordinate of the block")
                .Build();

Option 2:

var points = Argument<List<CustomPoint>>.Builder()
                .Identifier(new("p", "Points"))
                .IsRequired()
                .Rule(new ListCountBetweenXAndY<CustomPoint>(1, 3))
                .Rule(new ListRule<CustomPoint>(p => p.X > 0 && p.Y > 0)) //<- Our new Rule
                .Description("The coordinate of the block")
                .Build();

Dependencies

Dependencies are useful if you need argument A to depend on argument B or in the other direction in some certain way. They are called even if the arguments arent provided in args, other than IRule<T> (Only validates if arg is provided)

A Handful of default dependencies are predefined and usable directly on the Argument:

A Requires atleast one of B or C or ...

Mathematically: A ⇒ B or C ...

var firstNameArg =  Argument<string>.Builder()
    .Description("The first Name")
    .ShortIdentifier("f")
    .Build();

var ageArg = Argument<int>.Builder()
    .ShortIdentifier("a")
    .Build();

var lastNameArg = Argument<string>.Builder()
    .Description("The Last Name")
    .RequiresOneOf(firstNameArg,  ageArg) //IF last name is present and has a value, first name OR age must have a value
    .ShortIdentifier("l")
    .Build();

A Requires all of B and C and ...

Mathematically: A ⇒ B and C ...

var firstNameArg =  Argument<string>.Builder()
    .Description("The first Name")
    .ShortIdentifier("f")
    .Build();

var ageArg = Argument<int>.Builder()
    .ShortIdentifier("a")
    .Build();

var lastNameArg = Argument<string>.Builder()
    .Description("The Last Name")
    .RequiresAll(firstNameArg,  ageArg) //IF last name is present and has a value, first name AND age must have a value
    .ShortIdentifier("l")
    .Build();

A is bound to B and C (A if and only if B or C or ...)

Bound means:

• If A is present → behaves exactly like RequiresAll
• Else if A is not present, but B OR C OR ... is present → A is also now required.

Mathematically this means: A ⇔ B or C ...

var firstNameArg =  Argument<string>.Builder()
    .Description("The first Name")
    .ShortIdentifier("f")
    .Build();

var ageArg = Argument<int>.Builder()
    .ShortIdentifier("a")
    .Build();

var lastNameArg = Argument<string>.Builder()
    .Description("The Last Name")
    .OnlyWith(firstNameArg, ageArg) lastname if and only if firstname or age
    .ShortIdentifier("l")
    .Build();

Custom dependencies

If you want to, you can create your own dependencies, which may not be already predefined via implementing the IDependency and using it on the argument with .Dependency(new YourDependency()).

IDependency works with IArgument, so you can depend one argument to any other, no matter the type.

Here is an example, creating an IDependency to prevent some argument of being present if the argument it was defined on is present:

 private class NotDependency : IDependency
 {
     private readonly ArgumentIdentifier _notArg;
     public NotDependency(ArgumentIdentifier notArg)
     {
         _notArg = notArg;
     }
     public List<string> Check(IArgument argument, HashSet<IArgument> otherArgs)
     {
         if (!argument.HasValue)
         {
             return [];
         }

         List<string> result = [];
         var foundArg = otherArgs.FirstOrDefault(a => a.Identifier.Equals(_notArg));
         if (foundArg is not null && foundArg.HasValue)
         {
             string errorMessage =
                 $"'{argument.Identifier}' requires '{_notArg}' to not be present";
             if (CommandLineParser.WithExceptions)
             {
                 throw new DependencyException(errorMessage);
             }
             result.Add(errorMessage);
         }
         return result;
     }
 }

var firstNameArg =  Argument<string>.Builder()
    .Description("The first Name")
    .ShortIdentifier("f")
    .Build();

var ageArg = Argument<int>.Builder()
    .ShortIdentifier("a")
    .Build();

var lastNameArg = Argument<string>.Builder()
    .Description("The Last Name")
    .Dependency(new NotDependency(ageArg.Identifier))
    .ShortIdentifier("l")
    .Build();

CommandLineParser

The CommandLineParser (CLP) is the main start for the parsing. Create a new CLP and give it the arguments that you want to parse, with the array of actual args:

CommandLineParser parser = CommandLineParser.Builder()
    .Arguments(firstNameArg, ageArg, lastNameArg)
    .Build();

Help-argument

The CLP has a standard built in optional help Argument with the ArgumentIdentifier -h or --help. It shows all Arguments and how they can be used. You can change the help argument with .CustomHelpArg(yourNewHelpArg). So if you wish to change the ArgumentIdentifier, require help, or have it depend on something you can do this.

Custom help Formatting is currently not supported.

Formatting and ValuesExtractor

By default, every argument is expected to match a huge compiled regexp:

@"^\s*(?<dashType>--?)(?<key>[A-Za-z][A-Za-z0-9_-]*)(?:=(?<value>""[^""]*""|'[^']*'|[^ \t""']+))?\s*$"

The following table lists the valid and invalid command-line argument forms recognized by the parser (the regexp at the top in particular).

Key Rules Summary

Custom ValuesExtractor

If you wish to allow something other than the current regexp, just implement IValuesExtractor interface and use it like so:

private class CustomValuesExtractor : IValuesExtractor
{
    //Return type: All Identifier and value combos, errors if they exist. Values are not expected to be parsed at this point.
    public (Dictionary<ArgumentIdentifier, string?> identifierAndValues, List<string> errors) Extract(string[] args)
    {
        //Your implementation...
        throw new NotImplementedException();
    }
}

var parser = CommandLineParser.Builder()
    .Arguments(firstNameArg, ageArg, lastNameArg)
    .CustomValuesExtractor(new CustomValuesExtractor())
    .Build();

Handler

You can set handlers for certain combinations of your arguments. You first specify the handler with the params being all your desired arguments. Then you give with it the arguments that you wish to be involved in the handler. The handler will only be called if all arguments are provided and have a value.

Handlers will never be called, if errors occurred on the way, e.g., An argument was required but not given.

Let's say you want to print out the name of the user if he provides a name:

string[] args = ["--name='Linus Torvalds'"];

var nameArg = Argument<string>.Builder()
    .LongIdentifier("name")
    .IsRequired()
    .Build();

var parser = CommandLineParser.Builder()
    .Argument(nameArg)
    .Handler((string name) =>
    {
        Console.WriteLine("Your name is: " + name);
    }, nameArg) // Per default, the handler will only be called if name is provided
    .Build();

await parser.ParseAsync(args);

Result:

Your name is: Linus Torvalds

If you want to call a handler even if no argument was given, set allRequired:false:

string[] args = [];

var nameArg = Argument<string>.Builder()
    .LongIdentifier("name")
    .Build();

var parser = CommandLineParser.Builder()
    .Argument(nameArg)
    .Handler((string name) =>
    {
        Console.WriteLine("Your name is: " + name);
    }, allRequired:false, nameArg) // Will always be called now, if no error happened during extraction and validation
    .Build();

Default handler

If you specify no arguments, you can use the default handler that gets called always, if no errors occurred during extraction or validation:

var nameArg = Argument<string>.Builder()
    .LongIdentifier("name")
    .Build();

var parser = CommandLineParser.Builder()
    .Argument(nameArg)
    .Handler((string name) =>
    {
        Console.WriteLine("Your name is: " + name);
    }, nameArg)
    .Handler(() =>
    {
        Console.WriteLine("I got called!");
    }) //Even if no arg was provided, the handler will be called.
    .Build();

The only benefit you'll get from this is, that it will only be called upon a clean extraction and validation. Therefore, you do not have to check for errors after parsing yourself.
