Microsoft.KernelMemory.Postgres 0.3.231224.1

Kernel Memory with Postgres + pgvector

Kernel Memory (KM) is an open-source service specialized in Retrieval Augmented Generation (RAG) and the efficient indexing of datasets through custom continuous data hybrid pipelines. KM offers also a plugin for Semantic Kernel and OpenAPI wev service for maximum ease of integration and compatibility.

This package contains the Postgres adapter allowing to use Kernel Memory with Postgres.

To use Postgres with Kernel Memory:

1. Verify your Postgres instance supports vectors, e.g. run SELECT * FROM pg_extension

2. add to appsettings.json (or appsettings.development.json) Postgres connection string, for example:

   {
     "KernelMemory": {
       "Services": {
         "Postgres": {
           "ConnectionString": "Host=localhost;Port=5432;Username=myuser;Password=mypassword"
         }
       }
     }
   }


3. configure KM builder to store memories in Postgres, for example:

   // using Microsoft.KernelMemory;
   // using Microsoft.KernelMemory.Postgres;
   // using Microsoft.Extensions.Configuration;

   var postgresConfig = new PostgresConfig();

   new ConfigurationBuilder()
       .AddJsonFile("appsettings.json")
       .AddJsonFile("appsettings.Development.json", optional: true)
       .Build()
       .BindSection("KernelMemory:Services:Postgres", postgresConfig);

   var memory = new KernelMemoryBuilder()
       .WithPostgres(postgresConfig)
       .WithAzureOpenAITextGeneration(azureOpenAIConfig)
       .WithAzureOpenAITextEmbeddingGeneration(azureOpenAIConfig)
       .Build();


Neighbor search indexes, quality and performance

The connector does not create IVFFlat or HNSW indexes on Postgres tables, and uses exact nearest neighbor search. HNSW (Hierarchical Navigable Small World) has been introduced in pgvector 0.5.0 and is not available in some Postgres instances.

Depending on your scenario you might want to create these indexes manually, considering precision and performance trade-offs, or you can customize the SQL used to create tables via configuration.

An IVFFlat index divides vectors into lists, and then searches a subset of those lists that are closest to the query vector. It has faster build times and uses less memory than HNSW, but has lower query performance (in terms of speed-recall tradeoff).

SQL to add IVFFlat: CREATE INDEX ON %%table_name%% USING ivfflat (embedding vector_cosine_ops) WITH (lists = 1000);

An HNSW index creates a multilayer graph. It has slower build times and uses more memory than IVFFlat, but has better query performance (in terms of speed-recall tradeoff). There’s no training step like IVFFlat, so the index can be created without any data in the table.

SQL to add HNSW: CREATE INDEX ON %%table_name%% USING hnsw (embedding vector_cosine_ops);

See https://github.com/pgvector/pgvector for more information.

Memory Indexes and Postgres tables

The Postgres memory connector will create "memory indexes" automatically, one DB table for each memory index.

Table names have a configurable prefix, used to filter out other tables that might be present. The prefix is mandatory, cannot be empty, we suggest using the default km- prefix.

Overall we recommend not mixing external tables in the same DB used for Kernel Memory.

Column names and table schema

The connector uses a default schema with predefined columns and indexes.

You can change the field names, and if you need to add additional columns or indexes, you can also customize the CREATE TABLE SQL statement. You can use this approach, for example, to use IVFFlat or HNSW.

See PostgresConfig class for more details.

Here's an example where PostgresConfig is stored in appsettings.json and the table schema is customized, with custom names and additional fields.

The SQL statement requires two special placeholders:

• %%table_name%%: replaced at runtime with the table name
• %%vector_size%%: replaced at runtime with the embedding vectors size

Also:

• TableNamePrefix is mandatory string added to all KM tables
• Columns is a required map describing where KM will store its data. If you have additional columns you don't need to list them here, only in SQL statement.
• CreateTableSql is your optional custom SQL statement used to create tables. The column names must match those used in Columns.

{
  "KernelMemory": {
    "Services": {
      "Postgres": {

        "TableNamePrefix": "memory_",

        "Columns": {
          "id":        "_pk",
          "embedding": "embedding",
          "tags":      "labels",
          "content":   "chunk",
          "payload":   "extras"
        },

        "CreateTableSql": [
          "BEGIN;                                                                     ",
          "CREATE TABLE IF NOT EXISTS %%table_name%% (                                 ",
          "  _pk         TEXT NOT NULL PRIMARY KEY,                                   ",
          "  embedding   vector(%%vector_size%%),                                      ",
          "  labels      TEXT[] DEFAULT '{}'::TEXT[] NOT NULL,                        ",
          "  chunk       TEXT DEFAULT '' NOT NULL,                                    ",
          "  extras      JSONB DEFAULT '{}'::JSONB NOT NULL,                          ",
          "  my_field1   TEXT DEFAULT '',                                             ",
          "  _update     TIMESTAMP WITH TIME ZONE DEFAULT CURRENT_TIMESTAMP           ",
          ");                                                                         ",
          "CREATE INDEX ON %%table_name%% USING GIN(labels);                           ",
          "CREATE INDEX ON %%table_name%% USING ivfflat (embedding vector_cosine_ops); ",
          "COMMIT;                                                                    "
        ]

      }
    }
  }
}
