NativeCompressions 0.1.5

NativeCompressions

NativeCompressions provides native library bindings, streaming processing, and multi-threading support for LZ4 with its excellent decompression speed, and ZStandard with its superior balance of compression ratio and performance.

Encode silesia.tar corpus(200MB) with default LZ4 options. We will add benchmark for ZStandard, Brotli.

Compression is crucial for any application, but .NET has had limited options. NativeCompressions builds state-of-the-art algorithms (LZ4, ZStandard) with allocation-free, stream-less streaming APIs. Furthermore, by leveraging modern C# APIs (Span<T>, RandomAccess, PipeReader/Writer) to provide high-level multi-threading APIs, we achieve high-performance compression in any environment.

We chose native bindings over Pure C# implementation because compression library performance depends not only on algorithms but also on implementation. LZ4 and ZStandard are actively developed with performance improvements in every release. It's impossible to keep synchronizing advanced memory operations and CPU architecture optimizations with .NET ports. To continuously provide the best and latest performance, native bindings are necessary. Note that .NET's standard System.IO.Compression.BrotliEncoder/Decoder links brotli to libSystem.IO.Compression.Native, meaning we follow the same adoption criteria as .NET official.

LZ4 and ZStandard are created by the same author Cyan4973, showing high performance against competitors in their respective domains (LZ4 vs Snappy / Brotli vs ZStandard), and are widely used as industry standards.

LZ4 API implementation is complete. We are collecting feedback during this preview period.

Getting Started

Install the package from NuGet/NativeCompressions:

dotnet add package NativeCompressions

using NativeCompressions.LZ4;

// Simple compression
byte[] compressed = LZ4.Compress(sourceData);
byte[] decompressed = LZ4.Decompress(compressed);

Install for Unity, see Unity section.

NOTE: As of v0.1, the API is only NativeCompressions.LZ4, but ZStandard will be added soon.

LZ4

LZ4 has both block format and frame format. We adopt frame format for all APIs from the perspective of compatibility, security, and performance flexibility. External dictionary loading is also supported.

Simple Compression

Simple API to convert from ReadOnlySpan<T> to byte[], or write/read to/from Span<T>. These encode/decode in frame format, not block format. Also automatically sets ContentSize in the frame header.

using NativeCompressions.LZ4;

// ReadOnlySpan<byte> convert to byte[]
byte[] compressed = LZ4.Compress(source);
byte[] decompressed = LZ4.Decompress(compressed);

// ReadOnlySpan<byte> write to Span<byte>
var maxSize = LZ4.GetMaxCompressedLength(source.Length);
var destinationBuffer = new byte[maxSize];
var written = LZ4.Compress(source, destinationBuffer);
var destination = destinationBuffer[0..written];

These APIs can be customized by passing LZ4FrameOptions or LZ4CompressionDictionary. When decompressing to byte[], setting the bool trustedData argument to true will trust the ContentSize in the LZ4 frame header if present, pre-allocating the buffer for improved performance. When false, it processes in blocks to an internal buffer then concatenates, which is more resistant to attacks sending malicious data. Default is false.

Low-level Streaming Compression

APIs similar to BrotliEncoder/BrotliDecoder in System.IO.Compression to encode and decode data in a streamless, non-allocating, and performant manner using the LZ4 frame format specification.

using NativeCompressions.LZ4;

// for example, use for IBufferWriter<byte>
IBufferWriter<byte> bufferWriter;

using var encoder = new LZ4Encoder();

// Compress chunks(invoke Compress multiple times)
foreach (var chunk in dataChunks) // dataChunks = byte[][]
{
    // get max size per streaming compress
    var size = encoder.GetMaxCompressedLength(chunk.Length);

    var buffer = bufferWriter.GetSpan(size);

    // written size can be zero, meaning input data was just buffered.
    var written = encoder.Compress(chunk, buffer);

    bufferWriter.Advance(written);
}

// Finalize frame(need to get size of footer with buffered-data)
var fotterWithBufferdDataSize = encoder.GetMaxFlushBufferLength(includingFooter: true);
var finalBytes = bufferWriter.GetSpan(fotterWithBufferdDataSize);

// need to call `Close` to write LZ4 frame footer
var finalWritten = encoder.Close(finalBytes);

bufferWriter.Advance(finalWritten);

Method name is Compress not TryCompress, and returns size not OperationStatus because LZ4's native API differs from Brotli. The source is fully consumed, requiring destination to be at least MaxCompressedLength relative to source. On failure, the internal context state is corrupted, so it cannot be a Try... API and throws LZ4Exception on failure.

For decompression, use LZ4Decoder.

// while(status != OperationStatus.Done && source.Length > 0)
OperationStatus status = decoder.Decompress(source, destination, out int bytesConsumed, out int bytesWritten);
source = source.Slice(bytesConsumed);
destination = destination.Slice(bytesWritten);

In Decompress, both source and destination can receive incomplete data. When OperationStatus.Done is returned, all data is restored. Otherwise, NeedMoreData or DestinationTooSmall is returned.

High-level Streaming Compression

Using CompressAsync or DecompressAsync, you can stream encode/decode from ReadOnlyMemory<byte>, ReadOnlySequence<byte>, SafeFileHandle, Stream, PipeReader to PipeWriter. While internally using LZ4Encoder/LZ4Decoder, a single method call optimally handles complex operations.

The destination PipeWriter can be passed directly or wrapped around a Stream to change where to write.

// to Memory
using var ms = new MemoryStream();
await LZ4.CompressAsync(source, PipeWriter.Create(ms));

// to File
using var fs = new FileStream("foo.lz4", FileMode.OpenOrCreate, FileAccess.Write, FileShare.None, bufferSize: 1, useAsync: true);
await LZ4.CompressAsync(source, PipeWriter.Create(fs));

// to Network
using var fs = new NetworkStream(socket);
await LZ4.CompressAsync(source, PipeWriter.Create(fs));

When source is ReadOnlyMemory<byte>, ReadOnlySequence<byte>, or SafeFileHandle, you can specify int? maxDegreeOfParallelism. If null or 2 or greater, parallel processing occurs when the target source is 1MB or larger. null (default) uses Environment.ProcessorCount. Specifying 1 always results in sequential processing.

// Parallel Compression from File to File
using SafeFileHandle sourceHandle = File.OpenHandle("foo.bin");
using var dest = new FileStream("foo.lz4", FileMode.OpenOrCreate, FileAccess.Write, FileShare.None, bufferSize: 1, useAsync: true);
await LZ4.CompressAsync(sourceHandle, PipeWriter.Create(dest), maxDegreeOfParallelism: null);

When source is a file, passing SafeFileHandle enables parallel processing and can expect higher performance than FileStream. Stream or PipeReader doesn't perform parallel processing because the maximum source length is unknown, preventing estimation of appropriate block size for division.

For ASP.NET servers, we recommend always specifying maxDegreeOfParallelism as 1. Since the server itself processes requests in parallel, increasing CPU load may reduce overall throughput. Parallel processing will be highly effective in client applications or CLI batch processing.

Similarly for Decompress, source can be ReadOnlyMemory<byte>, ReadOnlySequence<byte>, SafeFileHandle, Stream, PipeReader, and destination can be PipeWriter.

using var ms = new MemoryStream();
using SafeFileHandle sourceHandle = File.OpenHandle("foo.lz4");
await LZ4.DecompressAsync(source, PipeWriter.Create(ms));

var decompressed = ms.ToArray();

Decompress parallel processing occurs when the LZ4 frame is compressed with BlockIndependent and maxDegreeOfParallelism is null or 2 or greater. In NativeCompressions, normal LZ4 compression processes with BlockLinked, but only compresses as BlockIndependent when parallel processing in CompressAsync.

Similar to Compress, explicitly specifying maxDegreeOfParallelism as 1 is recommended for ASP.NET servers.

Stream

Compatible with System.IO.Stream for easy integration:

// Compression stream
using var output = new MemoryStream();
using (var lz4Stream = new LZ4Stream(output, CompressionMode.Compress))
{
    await inputStream.CopyToAsync(lz4Stream);
} // Auto-close writes frame footer

// Decompression stream
using var input = new MemoryStream(compressedData);
using var lz4Stream = new LZ4Stream(input, CompressionMode.Decompress);
byte[] buffer = new byte[4096];
int read = await lz4Stream.ReadAsync(buffer);

Options

You can change with operator.

var options = LZ4FrameOptions.Default with
{
    CompressionLevel = 3,
    ContentSize = LZ4FrameOptions.Default with
    {
        ContentSize = source.Length
    }
};

// full-options
var options = new LZ4FrameOptions
{
    CompressionLevel = 9,           // 0-12
    AutoFlush = true,               // Flush after each compress call
    FavorDecompressionSpeed = 1,    // Optimize for decompression
    FrameInfo = new LZ4FrameInfo
    {
        BlockSizeID = BlockSizeId.Max4MB,  // Max64KB, Max256KB, Max1MB, Max4MB
        BlockMode = BlockMode.BlockIndependent,
        ContentChecksumFlag = ContentChecksum.ContentChecksumEnabled,
        BlockChecksumFlag = BlockChecksum.BlockChecksumEnabled,
        ContentSize = (ulong)sourceData.Length  // Pre-declare size
    }
};

Dictionary Compression

Improve compression ratio for similar data:

// Create dictionary from sample data
var dictionary = new LZ4CompressionDictionary(sampleData, dictionaryId: 12345);

// Use dictionary for compression
byte[] compressed = LZ4.Compress(source, LZ4FrameOptions.Default, dictionary);

// Decompression with same dictionary
byte[] decompressed = LZ4.Decompress(compressed, dictionary);

// Dictionary can be reused across multiple operations
using var encoder = new LZ4Encoder(options, dictionary);

Block Compression

For raw LZ4 block compression without frame format:

// Get max compressed size
var maxSize = LZ4.Block.GetMaxCompressedLength(source.Length);

// Compress block
var destination = new byte[maxSize];
var compressedSize = LZ4.Block.Compress(source, destination);
var compressed = destination.AsSpan(0, compressedSize).ToArray();

// Decompress block
destination = new byte[source.Length];
var decompressedSize = LZ4.Block.Decompress(compressed, destination);
var decompressed = destination.AsSpan(0, decompressedSize).ToArray();

Raw API

TODO

ZStandard

Work in progress.

Telemetry

TODO

Unity

TODO

License

This library is licensed under the MIT License.

This library includes precompiled binaries of LZ4 and ZStandard. See LICENSE file for full license texts.

Third-party Notices

• LZ4 - Licensed under BSD 2-Clause license
• ZStandard - Licensed under BSD License
