🚀 SheetStream

A lightning-fast, zero-dependency, 100% MIT-licensed .NET library for creating and reading Excel (.xlsx) files.

Stop paying thousands of dollars in commercial developer subscriptions just to write a spreadsheet. SheetStream uses a highly optimized, streaming XML engine to build massive Excel files with ultra-low memory allocation and absolute legal freedom.

✨ Why SheetStream?

• ⚖️ Zero Financial & Legal Friction: 100% MIT Licensed. Free for commercial use, personal use, startups, and massive enterprises alike. No license keys, no tier audits, and no required subscriptions.
• 📦 Zero Dependencies: Built entirely on native .NET System.IO.Compression and System.Xml APIs. Targets netstandard2.0 and net8.0, so it runs on .NET Framework 4.7.2+ as well as modern .NET.
• ⚡ High-Performance Streaming: Rows go straight through an XmlWriter into the zip archive. 10 million cells write in about 5 seconds with a 41 MB peak working set, whether the sheet is long or wide.
• 🧰 The features real reports use: tables, charts, pictures, conditional formatting, data validation, hyperlinks, comments, rich text, protection, print setup, outlining, AutoFit, and a streaming reader for imports.
• ✅ Verified ECMA-376 output: Every feature is validated against the OpenXML schema with the official Open XML SDK validator, and the showcase workbook is opened in real Excel to confirm nothing triggers a repair.

📦 Installation

dotnet add package SheetStream

Install-Package SheetStream

💻 Quick Start

using SheetStream;
using SheetStream.Styles;

using (var package = ExcelPackage.Create("FinancialReport.xlsx"))
{
    var workbook = package.Workbook;
    var sheet = workbook.Worksheets.Add("Q1 Report");

    sheet.Column(1).SetWidth(10);
    sheet.Column(2).SetWidth(28);
    sheet.Column(3).SetWidth(18);
    sheet.FreezePanes(rows: 1);

    var headerStyle = workbook.Styles.Create(o =>
    {
        o.Font.Bold = true;
        o.Font.Color = "#FFFFFF";
        o.Fill.BackgroundColor = "#4F81BD";
        o.Border.Style = BorderStyle.Thin;
    });
    var currencyStyle = workbook.Styles.Create(o => o.NumberFormat = "$#,##0.00");

    sheet.Row(1)
        .WriteCell("ID", headerStyle)
        .WriteCell("Product Name", headerStyle)
        .WriteCell("Revenue (USD)", headerStyle);

    for (int i = 1; i <= 100; i++)
    {
        sheet.Row(i + 1)
            .WriteCell(i)
            .WriteCell($"Enterprise SKU-{i}")          // Shared string (auto-deduplicated)
            .WriteCell(1500.50 * i, currencyStyle);
    }

    sheet.Row(102).WriteCell("Total", headerStyle).WriteEmpty(headerStyle).WriteFormula("SUM(C2:C101)", currencyStyle);
    package.Save(); // Also happens automatically when the package is disposed
}

Need bytes for a web download, like EPPlus' GetAsByteArray()?

byte[] bytes = ExcelPackage.CreateBytes(wb => wb.Worksheets.Add("Export").LoadFromCollection(orders));

🧭 Feature tour

Load data in one call

var result = sheet.LoadFromCollection(orders, new LoadOptions
{
    HeaderStyle = headerStyle,
    TableName = "Orders",              // Becomes an Excel table with filter buttons and banding
    TableStyle = "TableStyleMedium2",
});
sheet.LoadFromDataTable(dataTable);
sheet.LoadFromDataReader(sqlCommand.ExecuteReader()); // Streams a large query row by row

Control columns with attributes: [SheetColumn("Invoice #", Order = 0, NumberFormat = "$#,##0.00")], [SheetColumn(Ignore = true)], or [DisplayName("...")]. IDictionary<string, object> rows (ExpandoObject, Dapper) work too.

Tables, conditional formatting and validation

var table = sheet.AddTable("Sales", "A1:D101");      // Add before writing the header row
table.StyleName = "TableStyleMedium9";

var bad = workbook.Styles.CreateDifferential(o => { o.Font.Color = "#9C0006"; o.Fill.BackgroundColor = "#FFC7CE"; });
sheet.AddConditionalFormatting("D2:D101")
     .CellValue(ConditionalOperator.LessThan, "0", bad)
     .DataBar("#638EC6");
sheet.AddConditionalFormatting("E2:E101").IconSet(IconSetType.ThreeTrafficLights);

sheet.AddDataValidation("C2:C101").List("Open", "Closed", "On hold").WithError("Invalid", "Pick from the list.");
sheet.AddDataValidation("F2:F101").WholeNumber(ValidationOperator.Between, 1, 100);

Conditional formatting covers cell value, expression, contains text, duplicates, unique, top / bottom N, above / below average, two- and three-colour scales, data bars and icon sets. Validation covers lists (inline or from a range), whole numbers, decimals, dates, text length and custom formulas.

Charts and pictures

var chart = sheet.AddChart(ChartType.Column, "H2:P20");
chart.Title = "Revenue by month";
chart.YAxisTitle = "USD";
chart.ValueAxisNumberFormat = "$#,##0";
chart.AddSeries(values: "C2:C13", categories: "A2:A13", name: "=C1", color: "#4F81BD");

sheet.AddPicture("logo.png", row: 1, column: 8, widthPixels: 160);

Chart types: column, bar (clustered, stacked, 100%), line, line with markers, stacked line, area, stacked area, pie, doughnut, scatter and scatter with lines. Pictures: PNG, JPEG and GIF.

Links, comments, rich text and formulas

sheet.Row()
     .WriteHyperlink("Open the portal", "https://example.com/orders/42")
     .WriteInternalLink("Go to summary", "'Summary'!A1")
     .WriteRichText("Status: ", new RichText("LATE") { Bold = true, Color = "#C00000" })
     .WriteFormula("B2*TaxRate", cachedValue: 7.0);   // Cached result for viewers that do not calculate
sheet.AddComment(2, 3, "Checked by finance", author: "Glenn");
workbook.DefinedNames.Add("TaxRate", "'Settings'!B2");

Layout, printing and protection

sheet.AutoFitColumns();                       // Widths sized to content at save time
sheet.TabColor = "#C00000";
sheet.ShowGridLines = false;
sheet.Columns(5, 8).SetOutlineLevel(1);       // Collapsible column group
sheet.Row(10, new RowOptions { OutlineLevel = 1, Hidden = true });

sheet.PageSetup.Orientation = PageOrientation.Landscape;
sheet.PageSetup.FitToWidth = 1;
sheet.PageSetup.PrintTitleRows = (1, 1);
sheet.PageSetup.Footer = "Page &P of &N";

var input = workbook.Styles.Create(o => o.Protection.Locked = false);
sheet.Protect("password", o => o.AllowSort = true);   // Salted SHA-512, like Excel 2013+
workbook.Protect("password");                         // Lock the sheet structure
sheet.Visibility = SheetVisibility.Hidden;

Random access, EPPlus style

sheet.Cells[3, 2].Value = 42;          // Any order
sheet.Cells["B4"].Formula = "SUM(B1:B3)";
sheet.Cells["B4"].Style = boldStyle;

Random-access mode keeps the sheet's cells in memory until it is saved, which is convenient for small, irregular layouts. Use Row() streaming for big exports. A sheet uses one mode or the other.

Reading workbooks

using SheetStream.Reading;

using var reader = ExcelReader.Open("import.xlsx");
foreach (var row in reader.ReadRows("Products"))           // Streams; constant memory
    Console.WriteLine($"{row.GetString(0)}: {row.GetDouble(2)}");

List<Product> products = reader.Read<Product>("Products").ToList();   // Header row maps to properties
DataTable table = reader.ReadDataTable("Products");

Dates come back as DateTime (built-in and custom date formats, 1904 date system included), elapsed times as TimeSpan, errors as ExcelErrorValue, and formula cells as their cached result.

📚 API overview

⚖️ SheetStream vs EPPlus 8

Migrating from EPPlus

Streaming rules

SheetStream writes directly into the zip archive, which is what keeps memory flat. Each rule is enforced with a clear exception:

1. One sheet at a time. Adding a worksheet seals the previous one.
2. Rows ascend. Row(n) must be the current row or a later one. Gaps are fine. Use Cells[r, c] on a sheet that needs random access.
3. Layout first. Column widths, frozen panes, tab colour, gridlines and fit-to-page live before the data in the file, so set them before the first row. AutoFitColumns() and Cells[...] defer the header, which lifts this rule for that sheet.
4. Dispose saves. Leaving a using block without calling Save() still finishes the file. A save that fails is not retried by Dispose, so the original exception is the one you see.

🛠️ Architecture

1. Package (ExcelPackage): owns the ZipArchive, streams each worksheet part as it is written, and on save emits the content types, relationships, workbook, styles, shared strings and document properties.
2. Streaming writer (Worksheet / RowWriter): rows go through an XmlWriter into the compressed stream. Column letters are cached and the row number is formatted once per row, so writing a cell allocates nothing. Tables, drawings, charts and comments are separate parts written right after their sheet.
3. Shared strings (SharedStringTable): de-duplicates text across all sheets, as Excel does.
4. Styles (StyleSheet): de-duplicates fonts, fills, borders, number formats, cell formats and differential formats, written in the exact element order Excel demands.
5. Reader (ExcelReader): an XmlReader pass over each sheet that resolves shared strings and date styles, with DTD processing disabled for untrusted files.

🧪 Building and testing

dotnet build
dotnet test
dotnet run --project samples/SheetStream.Sample                         # FinancialReport.xlsx
dotnet run --project samples/SheetStream.Sample -- showcase              # Showcase.xlsx: every feature
dotnet run -c Release --project samples/SheetStream.Sample -- 1000000    # 1M-row stress run
dotnet run -c Release --project samples/SheetStream.Sample -- 5000 2000  # 10M-cell wide stress run

🚢 Releasing

Bump <Version> in src/SheetStream/SheetStream.csproj, add a CHANGELOG.md entry, commit, then:

git tag v0.2.0
git push --tags

The Release workflow refuses to run if the tag and the csproj version disagree. It publishes through nuget.org Trusted Publishing, so no API key is stored in the repository.

🤝 Contributing

We welcome the .NET community to help build the best free spreadsheet engine out there! See CONTRIBUTING.md.

📄 License

This project is licensed under the MIT License - see the LICENSE file for details.
