ShellSyntaxTree 0.1.5

ShellSyntaxTree

A focused .NET library that parses bash command strings into a structured AST. Purpose-built for tools that need to reason about shell commands without running them — approval gates for LLM-emitted commands, CI/CD script auditors, sandbox policy generators, audit-log analytics.

Hand-rolled, AOT-trim friendly, zero native dependencies. Multi-targets netstandard2.0 and net8.0.

dotnet add package ShellSyntaxTree --version 0.1.0-alpha

What you get

For an input like cd /repo && rm /etc/passwd, ShellSyntaxTree produces:

flowchart TD
    classDef bad fill:#fee,stroke:#b00,stroke-width:2px
    A[cd /repo<br/>📁 /repo] -- "&&" --> B[rm<br/>📁 /etc/passwd<br/>cwd: /repo]
    class B bad

A two-clause AST where the second clause's Args includes a synthetic /repo attribution arg (so consumers can see "this rm is implicitly operating in /repo") and /etc/passwd is resolved and marked IsPath = true. Hard-deny rules over /etc/* fire immediately; no substring matching, no shelling out, no false positives.

Things you can do with it

• Approval gates for AI agents — given a command emitted by an LLM, decide ALLOW / PROMPT / DENY before invoking the shell.
• CI/CD pipeline audits — scan shell steps in GitHub Actions / Jenkinsfile / Azure Pipelines for writes outside the workspace, curl | bash from non-allowlisted hosts, hardcoded credential echoes.
• Sandbox / container policy — derive the minimum-viable volume mount set or AppArmor profile from a build script.
• Pre-commit linters — flag dangerous patterns (rm -rf /, chmod 777 /etc/*) in shell scripts at commit time.
• Shell history / audit-log analytics — ingest ~/.bash_history or auditd records into structured form for SIEM-style insights.
• Documentation / explainers — convert complex one-liners into readable structure for tutorials and runbooks.

The original consumer is Netclaw's approval policy; the library is built to be reusable beyond that.

Quick start

using ShellSyntaxTree;

var parser = new BashParser();
var parsed = parser.Parse("cd /repo && rm /etc/passwd");

if (parsed.IsUnparseable)
{
    // Safe-fail: prompt the user, deny the command, etc.
    Console.WriteLine($"can't model: {parsed.UnparseableReason}");
    return;
}

foreach (var clause in parsed.Clauses)
{
    Console.WriteLine($"{clause.Operator} {clause.Verb.Joined}");

    foreach (var arg in clause.Args.Where(a => a.IsPath))
    {
        var marker = arg.IsCwdAttribution ? "↳ cwd" : "  path";
        Console.WriteLine($"    {marker}: {arg.Resolved}");
    }

    foreach (var redirect in clause.Redirects.Where(r => !r.IsDynamicSkip))
    {
        Console.WriteLine($"    {redirect.Direction}: {redirect.Target}");
    }
}

Run that against the example input and you get:

None cd
      path: /repo
AndIf rm
    ↳ cwd: /repo
      path: /etc/passwd

Public API surface (locked for v0.1)

namespace ShellSyntaxTree;

public interface IShellParser { ParsedCommand Parse(string command); }
public sealed class BashParser : IShellParser { /* … */ }
public sealed record BashParserOptions { /* HomeDirectory, WorkingDirectory */ }

public sealed record ParsedCommand { /* Source, Clauses, IsUnparseable, … */ }
public sealed record Clause        { /* Operator, Verb, Args, Redirects, … */ }
public sealed record VerbChain     { /* Tokens, Joined */ }
public sealed record Arg           { /* Raw, Resolved, Kind, IsPath, IsCwdAttribution, IsFlag */ }
public sealed record Redirect      { /* Direction, Target, IsDynamicSkip */ }

public enum ArgKind            { Literal, EnvVar, Glob, Tilde, DynamicSkip }
public enum RedirectDirection  { In, Out, Append, ErrOut, ErrAppend }
public enum CompoundOperator   { None, AndIf, OrIf, Sequence, Pipe }

PowerShell and Windows cmd parsers are deferred to later versions; the IShellParser seam is in place so consumers don't refactor when they ship.

Full behavioral contract: SPEC.md.

Samples

Two runnable samples live under samples/.

ShellSyntaxTree.Cli.Sample — terminal explainer + audit policy

dotnet run --project samples/ShellSyntaxTree.Cli.Sample -- explain "cd /repo && rm /etc/passwd"
dotnet run --project samples/ShellSyntaxTree.Cli.Sample -- audit "cd /repo && rm /etc/passwd"

explain pretty-prints the AST with [flag] / [path] / [cwd-attr] / [dyn-skip] / [glob] markers per arg. audit runs a small built-in policy ("deny writes in /etc, /usr, /bin, /sbin, /lib", "warn on curl | bash", "warn on dynamic args in path slots") and exits 0 / 1 / 2 by severity. See samples/ShellSyntaxTree.Cli.Sample/Commands/AuditPolicy.cs for the policy code — ~50 lines.

ShellSyntaxTree.Web.Sample — Blazor WebAssembly Mermaid visualizer

Paste a bash script, watch the parsed AST render as a Mermaid flowchart in your browser. Everything runs client-side — pasted scripts never leave your machine. Useful for "what does this script actually do?" moments and for understanding how the library models constructs like subshells and bash -c recursion.

dotnet run --project samples/ShellSyntaxTree.Web.Sample
# → http://localhost:5239

The visualizer ships preset scripts demonstrating compound commands, subshell isolation, bash -c recursion, dynamic-cwd attribution, and unparseable inputs (control-flow, function definitions). Each preset shows what the library produces in a single click.

Building from source

dotnet tool restore
dotnet build -c Release
dotnet test  -c Release
dotnet pack  -c Release -o ./bin/nuget

global.json pins the SDK; you need .NET 10 SDK or later for the .slnx solution format.

Versioning

Tags are bare SemVer version numbers — no v prefix. The release workflow asserts this and fails fast on misformatted tags.

• 0.1.0-alpha — first publishable cut. Bash-only.
• 0.1.x — additive (more verb table entries, more corpus, bug fixes).
• 0.2.0 — first PowerShell parser.
• 1.0.0 — when an external consumer beyond Netclaw ships against it without finding API gaps.

License

Apache-2.0. Copyright © 2026 Aaron Stannard.
