WorkflowForge Core

<p align="center"> <img src="https://raw.githubusercontent.com/animatlabs/workflow-forge/main/icon.png" alt="WorkflowForge" width="120" height="120"> </p>

Zero-dependency workflow orchestration framework for .NET

Overview

WorkflowForge Core is the foundational workflow orchestration library providing industrial-strength workflow capabilities with zero external dependencies. Built on the forge/foundry/smith metaphor, it delivers microsecond-level performance, built-in compensation (Saga pattern), and a flexible middleware pipeline.

Key Features

• Zero Dependencies: Absolutely no external NuGet packages required
• Microsecond Performance: Sub-20μs operation execution in high-performance scenarios
• Saga Pattern: Built-in compensation/rollback support via RestoreAsync
• Middleware Pipeline: Extensible Russian Doll pattern for cross-cutting concerns
• Dictionary-Based Data Flow: Thread-safe ConcurrentDictionary for shared context
• Type-Safe Operations: Optional IWorkflowOperation<TInput, TOutput> for explicit data contracts
• Configurable Output Chaining: Pass operation output to next input via WorkflowForgeOptions.EnableOutputChaining
• Event System: SRP-compliant lifecycle events (Workflow, Operation, Compensation)
• Builder Pattern: Fluent API for workflow construction
• .NET Standard 2.0: Compatible with .NET Framework 4.6.1+, .NET Core 2.0+, .NET 5+

Installation

dotnet add package WorkflowForge

Requirements: .NET Standard 2.0 or later

Quick Start

1. Create Your First Workflow

using WorkflowForge;
using WorkflowForge.Extensions;

// Create workflow
var workflow = WorkflowForge.CreateWorkflow("OrderProcessing")
    .AddOperation("ValidateOrder", new ValidateOrderOperation())
    .AddOperation("ChargePayment", new ChargePaymentOperation())
    .AddOperation("ReserveInventory", new ReserveInventoryOperation())
    .AddOperation("CreateShipment", new CreateShipmentOperation())
    .Build();

// Create execution environment
using var foundry = WorkflowForge.CreateFoundry("Order-12345");
foundry.SetProperty("OrderId", "12345");
foundry.SetProperty("CustomerId", "CUST-001");

// Execute workflow
using var smith = WorkflowForge.CreateSmith();
await smith.ForgeAsync(workflow, foundry);

// Read results
var shipmentId = foundry.GetPropertyOrDefault<string>("ShipmentId");

2. Inline Operations (Quick Prototyping)

var workflow = WorkflowForge.CreateWorkflow("QuickDemo")
    .AddOperation("Step1", async (foundry, ct) =>
    {
        foundry.Logger.LogInformation("Executing Step 1");
        foundry.SetProperty("Result", "Success");
        await Task.CompletedTask;
    })
    .AddOperation("Step2", async (foundry, ct) =>
    {
        var result = foundry.GetPropertyOrDefault<string>("Result");
        foundry.Logger.LogInformation("Step 2 received: {Result}", result);
        await Task.CompletedTask;
    })
    .Build();

using var smith = WorkflowForge.CreateSmith();
using var foundry = WorkflowForge.CreateFoundry("QuickDemo");
await smith.ForgeAsync(workflow, foundry);

Architecture

The Industrial Metaphor

WorkflowForge uses an industrial manufacturing metaphor:

• Forge (WorkflowForge static class): Main factory for creating workflows and components
• Foundry (IWorkflowFoundry): Execution environment with shared data/context
• Smith (IWorkflowSmith): Orchestrator that executes workflows through foundries
• Operation (IWorkflowOperation): Individual executable task

Data Flow: All workflow data lives in foundry.Properties (ConcurrentDictionary) by default. Use type-safe operations (IWorkflowOperation<TInput, TOutput>) only when explicit contracts are needed.

Core Abstractions

IWorkflowFoundry - Execution Context

public interface IWorkflowFoundry :
    IWorkflowExecutionContext,
    IWorkflowMiddlewarePipeline,
    IOperationLifecycleEvents,
    IDisposable
{
    Task ForgeAsync(CancellationToken cancellationToken = default);
    void ReplaceOperations(IEnumerable<IWorkflowOperation> operations);
    bool IsFrozen { get; }
}

IWorkflowSmith - Orchestration Engine

public interface IWorkflowSmith : IDisposable,
    IWorkflowLifecycleEvents,
    ICompensationLifecycleEvents
{
    Task ForgeAsync(IWorkflow workflow, CancellationToken cancellationToken = default);
    Task ForgeAsync(IWorkflow workflow, ConcurrentDictionary<string, object?> data, CancellationToken cancellationToken = default);
    Task ForgeAsync(IWorkflow workflow, IWorkflowFoundry foundry, CancellationToken cancellationToken = default);

    IWorkflowFoundry CreateFoundry(IWorkflowForgeLogger? logger = null, IServiceProvider? serviceProvider = null);
    IWorkflowFoundry CreateFoundryFor(IWorkflow workflow, IWorkflowForgeLogger? logger = null, IServiceProvider? serviceProvider = null);
    IWorkflowFoundry CreateFoundryWithData(ConcurrentDictionary<string, object?> data, IWorkflowForgeLogger? logger = null, IServiceProvider? serviceProvider = null);

    void AddWorkflowMiddleware(IWorkflowMiddleware middleware);
}

IWorkflowOperation - Executable Task

public interface IWorkflowOperation : IDisposable
{
    Guid Id { get; }
    string Name { get; }
    bool SupportsRestore { get; }

    Task<object?> ForgeAsync(object? inputData, IWorkflowFoundry foundry, CancellationToken cancellationToken);
    Task RestoreAsync(object? outputData, IWorkflowFoundry foundry, CancellationToken cancellationToken);
}

Built-in Operations

1. DelegateWorkflowOperation

var workflow = WorkflowForge.CreateWorkflow("DelegateExample")
    .AddOperation("Process", async (foundry, ct) =>
    {
        var input = foundry.GetPropertyOrDefault<string>("Input");
        foundry.Logger.LogInformation("Processing: {Input}", input);
        await Task.Delay(100, ct);
        foundry.SetProperty("Output", $"Processed: {input}");
    })
    .Build();

2. ActionWorkflowOperation

var workflow = WorkflowForge.CreateWorkflow("ActionExample")
    .AddOperation("LogStep", async (foundry, ct) =>
    {
        foundry.Logger.LogInformation("Executing step");
        foundry.SetProperty("Timestamp", DateTime.UtcNow);
        await Task.CompletedTask;
    })
    .Build();

3. ConditionalWorkflowOperation

var conditionalOp = ConditionalWorkflowOperation.Create(
    condition: foundry => foundry.GetPropertyOrDefault<bool>("IsPremium"),
    trueOperation: new PremiumProcessingOperation(),
    falseOperation: new StandardProcessingOperation()
);

workflow.AddOperation("ProcessByTier", conditionalOp);

4. ForEachWorkflowOperation

// Execute multiple operations concurrently (shared input to all)
var forEachOp = ForEachWorkflowOperation.CreateSharedInput(
    new[] { new ProcessItemOperation(), new ValidateOperation() },
    maxConcurrency: 4,
    name: "ProcessItems"
);

// Or split input collection among operations
var splitOp = ForEachWorkflowOperation.CreateSplitInput(
    itemOperations,
    maxConcurrency: 2
);

5. DelayOperation

var delayOp = new DelayOperation(TimeSpan.FromSeconds(5));
workflow.AddOperation("Wait", delayOp);

6. LoggingOperation

var logOp = new LoggingOperation("Order processing completed", logger);
workflow.AddOperation("LogCompletion", logOp);

Custom Operations

Method 1: Inherit WorkflowOperationBase

public class CalculateTotalOperation : WorkflowOperationBase
{
    public override string Name => "CalculateTotal";
    public override bool SupportsRestore => false;

    protected override async Task<object?> ForgeAsyncCore(
        object? inputData,
        IWorkflowFoundry foundry,
        CancellationToken cancellationToken = default)
    {
        var items = foundry.GetPropertyOrDefault<List<OrderItem>>("Items");
        var total = items.Sum(x => x.Price * x.Quantity);

        foundry.SetProperty("Total", total);
        foundry.Logger.LogInformation("Calculated total: {Total}", total);

        return total;
    }
}

Method 2: Type-Safe Operations (Optional)

public class ValidateOrderOperation : WorkflowOperationBase<Order, ValidationResult>
{
    public override string Name => "ValidateOrder";

    protected override async Task<ValidationResult> ForgeAsyncCore(
        Order input,
        IWorkflowFoundry foundry,
        CancellationToken cancellationToken = default)
    {
        if (input == null || input.Items.Count == 0)
        {
            return new ValidationResult { IsValid = false, Errors = ["No items in order"] };
        }

        return new ValidationResult { IsValid = true };
    }
}

Compensation (Saga Pattern)

Implement RestoreAsync for rollback capabilities:

public class ChargePaymentOperation : WorkflowOperationBase
{
    public override string Name => "ChargePayment";
    public override bool SupportsRestore => true;

    protected override async Task<object?> ForgeAsyncCore(
        object? inputData,
        IWorkflowFoundry foundry,
        CancellationToken cancellationToken)
    {
        var orderId = foundry.GetPropertyOrDefault<string>("OrderId");
        var amount = foundry.GetPropertyOrDefault<decimal>("Total");

        var paymentId = await _paymentService.ChargeAsync(orderId, amount, cancellationToken);

        foundry.SetProperty("PaymentId", paymentId);
        foundry.Logger.LogInformation("Payment charged: {PaymentId}", paymentId);

        return paymentId;
    }

    public override async Task RestoreAsync(
        object? outputData,
        IWorkflowFoundry foundry,
        CancellationToken cancellationToken)
    {
        var paymentId = foundry.GetPropertyOrDefault<string>("PaymentId");

        if (!string.IsNullOrEmpty(paymentId))
        {
            await _paymentService.RefundAsync(paymentId, cancellationToken);
            foundry.Logger.LogInformation("Payment refunded: {PaymentId}", paymentId);
        }
    }
}

Middleware

Add cross-cutting concerns using the middleware pipeline:

public class TimingMiddleware : IWorkflowOperationMiddleware
{
    private readonly IWorkflowForgeLogger _logger;

    public TimingMiddleware(IWorkflowForgeLogger logger)
    {
        _logger = logger;
    }

    public async Task<object?> ExecuteAsync(
        IWorkflowOperation operation,
        IWorkflowFoundry foundry,
        object? inputData,
        Func<CancellationToken, Task<object?>> next,
        CancellationToken cancellationToken)
    {
        var sw = Stopwatch.StartNew();

        try
        {
            return await next(cancellationToken).ConfigureAwait(false);
        }
        finally
        {
            sw.Stop();
            _logger.LogInformation(
                "Operation {Name} completed in {Duration}ms",
                operation.Name,
                sw.Elapsed.TotalMilliseconds);
        }
    }
}

// Add to foundry
foundry.AddMiddleware(new TimingMiddleware(logger));

Event System

Subscribe to lifecycle events:

// Workflow-level events (from Smith)
smith.WorkflowStarted += (s, e) =>
    Console.WriteLine($"Started: {e.WorkflowName}");
smith.WorkflowCompleted += (s, e) =>
    Console.WriteLine($"Completed in {e.Duration.TotalMilliseconds}ms");
smith.WorkflowFailed += (s, e) =>
    Console.WriteLine($"Failed: {e.Exception.Message}");

// Operation-level events (from Foundry)
foundry.OperationStarted += (s, e) =>
    Console.WriteLine($"Op started: {e.OperationName}");
foundry.OperationCompleted += (s, e) =>
    Console.WriteLine($"Op completed: {e.OperationName}");
foundry.OperationFailed += (s, e) =>
    Console.WriteLine($"Op failed: {e.OperationName}");

// Compensation events (from Foundry)
foundry.CompensationTriggered += (s, e) =>
    Console.WriteLine("Rollback triggered");
foundry.OperationRestoreStarted += (s, e) =>
    Console.WriteLine($"Restoring: {e.OperationName}");

Configuration

WorkflowForgeOptions inherits from WorkflowForgeOptionsBase, providing Enabled, SectionName, Validate(), and Clone() for consistent options behavior.

Programmatic Configuration

var options = new WorkflowForgeOptions
{
    Enabled = true,
    MaxConcurrentWorkflows = 10,
    ContinueOnError = false,
    FailFastCompensation = false,
    ThrowOnCompensationError = true,
    EnableOutputChaining = true
};

var foundry = WorkflowForge.CreateFoundry("MyWorkflow", options: options);

Options Pattern (appsettings.json)

{
  "WorkflowForge": {
    "Enabled": true,
    "MaxConcurrentWorkflows": 10,
    "ContinueOnError": false,
    "FailFastCompensation": false,
    "ThrowOnCompensationError": true,
    "EnableOutputChaining": true
  }
}

services.AddWorkflowForge(configuration);
var smith = services.BuildServiceProvider().GetRequiredService<IWorkflowSmith>();

Performance

WorkflowForge Core is optimized for production workloads (12 scenarios benchmarked, 50 iterations):

• Execution Speed: 11-540x faster than competitors
• State Machine: Up to 540x faster (highest advantage)
• Memory: 9-573x less allocation than competitors
• Concurrency: Near-perfect linear scaling (16x speedup for 16 workflows)

See Performance Documentation for all 12 scenarios.

Testing

All interfaces are mockable for comprehensive testing:

using Moq;
using Xunit;

public class WorkflowTests
{
    [Fact]
    public async Task Should_Execute_Operations_In_Order()
    {
        // Arrange
        var executionOrder = new List<string>();

        var workflow = WorkflowForge.CreateWorkflow("Test")
            .WithOperation("Step1", async (foundry) => executionOrder.Add("Step1"))
            .WithOperation("Step2", async (foundry) => executionOrder.Add("Step2"))
            .WithOperation("Step3", async (foundry) => executionOrder.Add("Step3"))
            .Build();

        using var foundry = WorkflowForge.CreateFoundry("Test");
        using var smith = WorkflowForge.CreateSmith();

        // Act
        await smith.ForgeAsync(workflow, foundry);

        // Assert
        Assert.Equal(new[] { "Step1", "Step2", "Step3" }, executionOrder);
    }
}

Documentation

• Getting Started Guide - Step-by-step tutorial
• Architecture - Design principles and patterns
• Operations Guide - All operation types and patterns
• Events System - Lifecycle events and monitoring
• Configuration - All configuration options
• Extensions - Available extensions
• Samples - 33 hands-on examples
• API Reference - Complete API documentation

Extensions

While Core has zero dependencies, extend functionality with official packages:

• WorkflowForge.Testing - Unit testing utilities (FakeWorkflowFoundry)
• WorkflowForge.Extensions.Logging.Serilog - Structured logging
• WorkflowForge.Extensions.Resilience - Retry strategies (zero dependencies)
• WorkflowForge.Extensions.Resilience.Polly - Advanced resilience with Polly
• WorkflowForge.Extensions.Validation - DataAnnotations-based validation
• WorkflowForge.Extensions.Audit - Comprehensive audit logging
• WorkflowForge.Extensions.Persistence - Workflow state persistence
• WorkflowForge.Extensions.Persistence.Recovery - Recovery coordinator
• WorkflowForge.Extensions.Observability.Performance - Performance monitoring
• WorkflowForge.Extensions.Observability.HealthChecks - Health check integration
• WorkflowForge.Extensions.Observability.OpenTelemetry - Distributed tracing

Dependency isolation: Extensions internalize third-party libraries with ILRepack where appropriate, while keeping Microsoft/System assemblies external.

License

MIT License - see LICENSE for details.
