WorkflowForge.Extensions.Observability.Performance 2.1.2

WorkflowForge.Extensions.Observability.Performance

Measure per-operation timing and memory from middleware, and read aggregate stats when the foundry exposes IFoundryPerformanceStatistics.

Install

dotnet add package WorkflowForge.Extensions.Observability.Performance

Targets .NET Standard 2.0. Beyond WorkflowForge core, it depends on System.Diagnostics.DiagnosticSource and System.ComponentModel.Annotations (both provided by the runtime on modern .NET).

Quick Start

Call EnablePerformanceMonitoring() before running the workflow, then read the aggregated statistics afterward with GetPerformanceStatistics():

using WorkflowForge;
using WorkflowForge.Extensions.Observability.Performance;

using var foundry = WorkflowForge.CreateFoundry("PerformanceMonitored");
foundry.EnablePerformanceMonitoring();

using var smith = WorkflowForge.CreateSmith();
var workflow = WorkflowForge.CreateWorkflow("PerformanceMonitored")
    .AddOperation(new ActionWorkflowOperation("Step1", async (input, foundry, ct) => { /* ... */ }))
    .Build();

// Pass the SAME foundry you enabled monitoring on so the stats survive the run.
await smith.ForgeAsync(workflow, foundry);

var stats = foundry.GetPerformanceStatistics();
Console.WriteLine($"Operations: {stats!.TotalOperations}, success rate: {stats.SuccessRate:P0}");
foreach (var op in stats.GetAllOperationStatistics())
    Console.WriteLine($"{op.OperationName}: avg {op.AverageExecutionTime.TotalMilliseconds:F2} ms");

EnablePerformanceMonitoring() registers a PerformanceStatisticsMiddleware and stores a FoundryPerformanceStatistics on the foundry; the middleware records timing, success/failure, and approximate memory per operation. For custom needs you can add your own middleware instead (see Custom Timing Middleware).

Key points

• Middleware can log durations, flag slow calls, and track allocations per operation.
• IFoundryPerformanceStatistics and IOperationStatistics describe the contract when a foundry exposes built-in counters.
• Toggle or tune behavior in code; there is no separate JSON schema in this package.

Configuration

• Ships middleware types and IFoundryPerformanceStatistics / IOperationStatistics for foundries that expose statistics.
• Typical pattern: timing middleware on the foundry:

using var foundry = WorkflowForge.CreateFoundry("PerformanceMonitored");
foundry.AddMiddleware(new DetailedTimingMiddleware(foundry.Logger, TimeSpan.FromMilliseconds(500)));

• IFoundryPerformanceStatistics and IOperationStatistics define the contract for built-in performance statistics on a foundry.

Performance extension

Advanced usage

Custom timing middleware

public class DetailedTimingMiddleware : IWorkflowOperationMiddleware
{
    private readonly IWorkflowForgeLogger _logger;
    private readonly TimeSpan _slowThreshold;

    public DetailedTimingMiddleware(IWorkflowForgeLogger logger, TimeSpan slowThreshold)
    {
        _logger = logger;
        _slowThreshold = slowThreshold;
    }

    public async Task<object?> ExecuteAsync(
        IWorkflowOperation operation,
        IWorkflowFoundry foundry,
        object? inputData,
        Func<CancellationToken, Task<object?>> next,
        CancellationToken cancellationToken = default)
    {
        var sw = Stopwatch.StartNew();

        try
        {
            var result = await next(cancellationToken).ConfigureAwait(false);
            sw.Stop();

            if (sw.Elapsed > _slowThreshold)
            {
                _logger.LogWarning(
                    "SLOW: Operation {Name} took {Duration}ms (threshold: {Threshold}ms)",
                    operation.Name,
                    sw.Elapsed.TotalMilliseconds,
                    _slowThreshold.TotalMilliseconds);
            }
            else
            {
                _logger.LogInformation(
                    "Operation {Name} completed in {Duration}ms",
                    operation.Name,
                    sw.Elapsed.TotalMilliseconds);
            }

            return result;
        }
        catch (Exception ex)
        {
            sw.Stop();
            _logger.LogError(ex,
                "Operation {Name} failed after {Duration}ms",
                operation.Name,
                sw.Elapsed.TotalMilliseconds);
            throw;
        }
    }
}

Memory tracking

public class MemoryTrackingMiddleware : IWorkflowOperationMiddleware
{
    public async Task<object?> ExecuteAsync(
        IWorkflowOperation operation,
        IWorkflowFoundry foundry,
        object? inputData,
        Func<CancellationToken, Task<object?>> next,
        CancellationToken cancellationToken = default)
    {
        var gen0Before = GC.CollectionCount(0);
        var memoryBefore = GC.GetTotalMemory(false);

        var result = await next(cancellationToken).ConfigureAwait(false);

        var gen0After = GC.CollectionCount(0);
        var memoryAfter = GC.GetTotalMemory(false);

        foundry.Logger.LogInformation(
            "Operation {Name}: Memory delta {MemoryDelta} bytes, Gen0 collections: {Gen0Collections}",
            operation.Name,
            memoryAfter - memoryBefore,
            gen0After - gen0Before);

        return result;
    }
}

Available statistics

Foundry-level (IFoundryPerformanceStatistics)

• TotalOperations / SuccessfulOperations / FailedOperations: Operation counts
• SuccessRate: Percentage of successful operations
• AverageDuration / MinimumDuration / MaximumDuration: Timing statistics
• TotalMemoryAllocated / AverageMemoryPerOperation: Memory metrics
• OperationsPerSecond: Throughput
• StartTime / EndTime / TotalDuration: Workflow timing

Per-operation (IOperationStatistics)

var stats = foundry.GetPerformanceStatistics();
foreach (var opStats in stats.GetAllOperationStatistics())
{
    Console.WriteLine($"{opStats.OperationName}: avg {opStats.AverageExecutionTime.TotalMilliseconds:F2}ms");
}
