WorkflowForge.Extensions.Persistence 2.1.1

WorkflowForge.Extensions.Persistence

Persistence extension for WorkflowForge enabling resumable workflows via a pluggable provider (bring your own storage). Zero-dependency core integration.

Bring Your Own Storage

This extension defines the abstractions and middleware for workflow persistence. You implement IWorkflowPersistenceProvider to plug in your chosen storage (SQL Server, Cosmos DB, Redis, file system, etc.).

There are no built-in providers -- this is by design to keep the extension dependency-free and storage-agnostic.

Installation

dotnet add package WorkflowForge.Extensions.Persistence

Requires: .NET Standard 2.0 or later

Quick Start

1. Implement the Provider Interface

using WorkflowForge.Extensions.Persistence.Abstractions;

public class SqlPersistenceProvider : IWorkflowPersistenceProvider
{
    private readonly string _connectionString;

    public SqlPersistenceProvider(string connectionString)
    {
        _connectionString = connectionString;
    }

    public async Task SaveAsync(
        WorkflowExecutionSnapshot snapshot,
        CancellationToken cancellationToken = default)
    {
        // Serialize and store the snapshot in your database
    }

    public async Task<WorkflowExecutionSnapshot?> TryLoadAsync(
        Guid foundryExecutionId,
        Guid workflowId,
        CancellationToken cancellationToken = default)
    {
        // Load the snapshot from your database; return null if not found
    }

    public async Task DeleteAsync(
        Guid foundryExecutionId,
        Guid workflowId,
        CancellationToken cancellationToken = default)
    {
        // Remove the snapshot from your database
    }
}

2. Enable Persistence on the Foundry

using WorkflowForge;
using WorkflowForge.Extensions.Persistence;

IWorkflowPersistenceProvider provider = new SqlPersistenceProvider("Server=...");

var smith = WorkflowForge.CreateSmith();
var workflow = WorkflowForge.CreateWorkflow("MyWorkflow")
    .AddOperation(/* your operations */)
    .Build();

using var foundry = WorkflowForge.CreateFoundry("OrderService");
foundry.UsePersistence(provider);

await smith.ForgeAsync(workflow, foundry);

3. Enable with Stable Keys (for Cross-Process Resume)

using WorkflowForge.Extensions.Persistence;

var options = new PersistenceOptions
{
    InstanceId = "order-service-instance",
    WorkflowKey = "process-order-v1"
};

foundry.UsePersistence(provider, options);

When InstanceId and WorkflowKey are set, deterministic GUIDs are derived from those strings so the same workflow can be found across process restarts.

Key Features

• Pluggable Storage: IWorkflowPersistenceProvider interface -- bring any storage backend
• Checkpoint & Resume: Automatically checkpoints after each operation and skips completed steps on resume
• Index-Based Tracking: O(1) operation tracking with no dictionary lookups
• Stable Keys: Deterministic IDs for cross-process recovery
• Thread-Safe: Safe for concurrent workflow execution
• Zero Dependencies: No external packages beyond WorkflowForge core

How It Works

The PersistenceMiddleware wraps each operation in the pipeline:

1. Before each operation: Calls TryLoadAsync to check for a saved snapshot
2. If snapshot exists and operation already completed: Restores properties, skips the operation
3. If not resumed: Calls the next middleware/operation normally
4. After success: Builds a WorkflowExecutionSnapshot with NextOperationIndex incremented and calls SaveAsync
5. When all operations complete: Calls DeleteAsync to clean up

Snapshot Structure

public sealed class WorkflowExecutionSnapshot
{
    public Guid FoundryExecutionId { get; set; }
    public Guid WorkflowId { get; set; }
    public string WorkflowName { get; set; }
    public int NextOperationIndex { get; set; }
    public Dictionary<string, object?> Properties { get; set; }
}

• NextOperationIndex: -1 means not started; N means operation at index N is next
• Properties: Arbitrary key-value state from foundry.Properties -- store only what you need for resumption

Configuration

Via appsettings.json

{
  "WorkflowForge": {
    "Extensions": {
      "Persistence": {
        "Enabled": true,
        "PersistOnOperationComplete": true,
        "PersistOnWorkflowComplete": true,
        "PersistOnFailure": true,
        "MaxVersions": 10,
        "InstanceId": "my-instance-id",
        "WorkflowKey": "my-workflow-key"
      }
    }
  }
}

Via Code

using WorkflowForge.Extensions.Persistence;

var options = new PersistenceOptions
{
    Enabled = true,
    PersistOnOperationComplete = true,
    PersistOnWorkflowComplete = true,
    PersistOnFailure = true,
    MaxVersions = 10,
    InstanceId = "my-instance-id",
    WorkflowKey = "my-workflow-key"
};

foundry.UsePersistence(provider, options);

Via Dependency Injection

using Microsoft.Extensions.Configuration;
using Microsoft.Extensions.DependencyInjection;
using WorkflowForge.Extensions.Persistence;

services.AddPersistenceConfiguration(configuration);
var options = serviceProvider.GetRequiredService<IOptions<PersistenceOptions>>().Value;

See Configuration Guide for complete options.

Provider Interface

public interface IWorkflowPersistenceProvider
{
    Task SaveAsync(WorkflowExecutionSnapshot snapshot, CancellationToken cancellationToken = default);

    Task<WorkflowExecutionSnapshot?> TryLoadAsync(Guid foundryExecutionId, Guid workflowId,
        CancellationToken cancellationToken = default);

    Task DeleteAsync(Guid foundryExecutionId, Guid workflowId,
        CancellationToken cancellationToken = default);
}
