EasyOcrSharp.Gpu 2.1.1

<div align="center"> <img src="src/EasyOcrSharp/Assets/icon.gif" alt="EasyOcrSharp Logo" width="128" height="128"> <h1>EasyOcrSharp</h1>

High-accuracy, fully-offline OCR for .NET — EasyOCR's neural models running natively on ONNX Runtime. No Python.

</div>

EasyOcrSharp runs EasyOCR's exact CRAFT text detector and CRNN recognizers, exported to ONNX, through Microsoft.ML.OnnxRuntime. You get EasyOCR-grade accuracy in a tiny managed package — no Python interpreter, no PyTorch, no native OCR binaries, and nothing leaves the machine.

Table of contents

• Installation
• Quick start
• The result model
• Input sources
• Recognition options
• Region of interest
• Multiple languages
• Automatic language detection
• Scanned-document preprocessing
• Dependency injection
• GPU acceleration
• Supported languages
• How model downloads work
• Accuracy notes
• Building & testing
• License

Installation

dotnet add package EasyOcrSharp

For NVIDIA GPU acceleration (Windows/Linux x64, CUDA 12+):

dotnet add package EasyOcrSharp.Gpu

Upgrading from 1.x? v2 replaced the ~1.5 GB embedded Python+PyTorch runtime with native ONNX. The public API (EasyOcrService, OcrResult, OcrLine, OcrBoundingBox) is unchanged.

Quick start

using EasyOcrSharp.Services;

await using var ocr = new EasyOcrService();

var result = await ocr.ExtractTextFromImage("sample.png", new[] { "en" });

Console.WriteLine(result.FullText);

foreach (var line in result.Lines)
    Console.WriteLine($"{line.Text}  (confidence {line.Confidence:P0})");

The first call for a language downloads its model (cached afterwards). Detected text is returned as reading-order lines (top-to-bottom), matching EasyOCR's readtext().

The result model

public sealed record OcrResult
{
    public string FullText { get; }                 // all lines joined by newlines
    public IReadOnlyList<OcrLine> Lines { get; }
    public IReadOnlyList<string> Languages { get; }
    public TimeSpan Duration { get; }
    public bool UsedGpu { get; }
}

public sealed record OcrLine
{
    public string Text { get; }
    public double Confidence { get; }                       // 0..1
    public IReadOnlyList<OcrPoint> BoundingPolygon { get; } // 4 corners
    public OcrBoundingBox BoundingBox { get; }              // MinX/MinY/MaxX/MaxY + Width/Height/Center
}

Input sources

OCR from a file path, a Stream, raw encoded bytes, or an already-decoded ImageSharp image:

await ocr.ExtractTextFromImage("photo.jpg",            new[] { "en" });
await ocr.ExtractTextFromImage(stream,                  new[] { "en" });
await ocr.ExtractTextFromImage(File.ReadAllBytes("p"),  new[] { "en" });   // byte[]
await ocr.ExtractTextFromImage(memory,                  new[] { "en" });   // ReadOnlyMemory<byte>
await ocr.ExtractTextFromImage(image,                   new[] { "en" });   // Image<Rgb24> (caller-owned)

All overloads accept an optional RecognitionOptions and a CancellationToken.

Recognition options

var options = new RecognitionOptions
{
    Grouping = TextGrouping.Line,    // Word | Line (default) | Paragraph
    MinConfidence = 0.3,             // drop results below this confidence
    MaxDegreeOfParallelism = 8,      // regions recognized concurrently (default: CPU count)
    AdjustContrast = true,           // low-confidence contrast-retry pass (EasyOCR's 2nd pass)
    Region = null,                   // optional region of interest (see below)
};

var result = await ocr.ExtractTextFromImage("doc.png", new[] { "en" }, options);

Region of interest

Restrict OCR to a rectangle — ideal for a fixed field (price, license plate, banner) and faster than scanning the whole image. Boxes are always reported in the original image's coordinates.

// Absolute pixels:
var roi = new RecognitionOptions { Region = OcrRegion.Pixels(x: 40, y: 320, width: 500, height: 80) };

// Resolution-independent fractions — e.g. the bottom third:
var bottom = new RecognitionOptions { Region = OcrRegion.Fraction(0, 0.66, 1, 0.34) };

var result = await ocr.ExtractTextFromImage("receipt.png", new[] { "en" }, bottom);

Multiple languages

Pass several codes for mixed-script images — each region is read by every requested script pack and the highest-confidence result wins:

var result = await ocr.ExtractTextFromImage("street_sign.png", new[] { "en", "ch_sim", "ru" });

Each additional script family loads its own model, so request only the scripts you expect.

Automatic language detection

Don't know the language? Let the engine detect it — pass no codes and set AutoDetectLanguage:

var result = await ocr.ExtractTextFromImage("unknown.png", Array.Empty<string>(),
    new RecognitionOptions { AutoDetectLanguage = true });

// Or just detect, without recognizing:
IReadOnlyList<string> langs = await ocr.DetectLanguagesAsync("unknown.png");

Detection samples the largest text regions and scores candidate script packs by confidence. Candidates default to a common set (Latin, Cyrillic, Chinese, Japanese, Korean); widen them when you expect heavier scripts:

var opts = new RecognitionOptions
{
    AutoDetectLanguage = true,
    AutoDetectCandidates = new[] { "en", "ar", "hi", "ch_sim" },
};

Scanned-document preprocessing

For photos and scans, enable clean-up via RecognitionOptions.Preprocessing:

var opts = new RecognitionOptions
{
    Preprocessing = new PreprocessingOptions
    {
        Deskew = true,            // straighten small tilt (±15°)
        DetectOrientation = true, // fix 90°/180°/270° rotation (≈4× cost)
        Binarize = true,          // adaptive black/white for uneven lighting
        Denoise = true,           // suppress scanner speckle
    },
};
var result = await ocr.ExtractTextFromImage("scan.jpg", new[] { "en" }, opts);

When Deskew or DetectOrientation rotate the image, bounding boxes are reported in the corrected image's coordinate space.

Dependency injection

services.AddEasyOcrSharp(o =>
{
    o.UseGpu = false;
    o.ModelCachePath = "/var/cache/easyocr";
});

public class ReceiptParser(IEasyOcrService ocr) { /* inject anywhere */ }

Registered as a singleton — ONNX sessions are expensive to build and thread-safe to reuse.

GPU acceleration

await using var ocr = new EasyOcrService(useGpu: true);

Requires the EasyOcrSharp.Gpu package, CUDA 12+ on PATH, and a compatible NVIDIA GPU. Falls back to CPU automatically if CUDA isn't available.

Supported languages

Languages are grouped by script; one recognizer covers an entire group, so ["en","es","fr"] loads a single model. Sizes differ because EasyOCR ships small "generation-2" models for some scripts and only larger "generation-1" models for others — this affects first-run download size only.

That's all 86 languages EasyOCR supports, mapped exactly to the model each was trained on.

Not supported: Greek (el) and Hebrew (he) — upstream EasyOCR ships no model for either script, so they cannot be exported.

How model downloads work

EasyOcrSharp ships no models in the NuGet package. On the first call for a language it downloads, into a local cache:

1. CRAFT detector (craft_mlt_25k.onnx, ~80 MB) — shared by all languages, downloaded once.
2. CRNN recognizer for the language's script pack (e.g. latin_g2.onnx).
3. A small vocabulary sidecar (<pack>.vocab.json).

Every file is SHA256-verified against a checksum baked into the library, so corrupted or tampered downloads are rejected. Models are hosted on Hugging Face.

Default cache: %LOCALAPPDATA%\EasyOcrSharp\models (Windows) or the platform equivalent. Override it:

await using var ocr = new EasyOcrService(modelCachePath: @"D:\MyApp\Models");

EASYOCRSHARP_CACHE=/var/cache/easyocr                          # cache directory
EASYOCRSHARP_MODEL_BASE_URL=https://files.mycorp.example/ocr   # private/offline mirror

Offline / air-gapped: pre-seed your cache directory with the .onnx + .vocab.json files from the model repo — no network is needed at runtime.

Accuracy notes

EasyOcrSharp reproduces EasyOCR's pipeline faithfully — aspect-preserving resize, normalization, a low-confidence contrast-retry pass, CRAFT box dilation, perspective de-warping of rotated text, and CTC greedy decoding — so output matches upstream EasyOCR. As with any OCR:

• Visually identical glyphs (capital I vs lowercase l, $ vs 8) can be confused.
• Handwriting and low-resolution / low-contrast text are harder than clean printed text.
• Right-to-left scripts (Arabic) are returned in the model's character order.

Building & testing

git clone https://github.com/easyocrsharp/EasyOcrSharp.git
cd EasyOcrSharp
dotnet build -c Release

# Unit tests (no model downloads needed):
dotnet test --filter "Category!=Integration"

# Accuracy/integration tests (need models — point the cache at a folder containing them):
EASYOCRSHARP_CACHE=/path/to/onnx_models dotnet test --filter "Category=Integration"

# Interactive console demo:
dotnet run --project test/EasyOcrSharp.Demo

CI (GitHub Actions) builds and runs the unit tests on Linux and Windows for every push and PR. See CHANGELOG.md for release history.

License

MIT — see LICENSE. EasyOCR (the upstream model authors) is also MIT-licensed.

Acknowledgments

• EasyOCR — the underlying CRAFT + CRNN models
• ONNX Runtime — neural network execution
• SixLabors.ImageSharp — image I/O and resizing
