ilrepl 0.3.0

ilrepl

An interactive CIL REPL. Type IL one instruction at a time, watch the evaluation stack change under your fingers, and run the cell on the real JIT.

il[1]> ldc.i4 6
  ┊ [int32]
il[1]> ldc.i4 7
  ┊ [int32, int32] ◂ top
il[1]> mul
  ┊ [int32]
il[1]> ret
  = 42 : int32

Documentation and a live session in your browser: https://ilrepl.dev/

Install

dotnet tool install -g ilrepl
ilrepl

ilrepl needs the .NET 10 SDK or runtime. The front-end is a Native AOT executable on Windows, Linux, and macOS; the part that compiles and runs IL is a small framework-dependent host that ships in the package and runs on your dotnet.

What it does

Every line you type is checked against a typed model of the evaluation stack before it is accepted, so underflows and arity mistakes show up at the prompt. ret, or an empty line, compiles the cell with Reflection.Emit, runs it, and prints whatever single value was left on the stack with its runtime type.

It takes all of IL: every opcode, exception blocks (.try {, } catch T {, } filter {, } finally {, } fault {), calli, varargs and arglist, pinned locals, cell arguments, generic parameters with !!T, and ldtoken for types, methods, and fields. Methods defined with .method persist across cells and are called by name, so recursion, ldftn over your own code, and delegates over it all work. Types defined with .class persist too: structs and classes with constructors, virtual and abstract members, interfaces, enums, layout, generics, and nested types, each one runtime type across cells, shown by its fields when a cell returns one. Member references use ILAsm syntax, and the return type and [assembly] prefix are optional. Types, methods, and cells can be saved to disk as real assemblies with .save, or shown as ILAsm with .il. .dis reads any method back, the framework's or your own, with the same stack column beside each instruction.

il[2]> .locals init (string m)
il[2]> .try {
il[2]> ldstr "boom"
il[2]> newobj instance void InvalidOperationException::.ctor(string)
il[2]> throw
il[2]> } catch InvalidOperationException {
  ┊ [InvalidOperationException]
il[2]> callvirt instance string Exception::get_Message()
il[2]> stloc m
il[2]> leave DONE
il[2]> }
il[2]> DONE: ldloc m
il[2]> ret
  = "boom" : string

A method stays for the rest of the session:

il[3]> .method int32 Fib(int32 n) {
  method int32 Fib(int32 n)
il[3]> ldarg n
il[3]> ldc.i4 2
il[3]> blt BASE
il[3]> ldarg n
il[3]> ldc.i4 1
il[3]> sub
il[3]> call int32 Fib(int32)
il[3]> ldarg n
il[3]> ldc.i4 2
il[3]> sub
il[3]> call int32 Fib(int32)
il[3]> add
il[3]> ret
il[3]> BASE: ldarg n
il[3]> ret
il[3]> }
  end of method Fib
il[4]> ldc.i4 10
il[4]> call int32 Fib(int32)
il[4]> ret
  = 55 : int32

A type stays too, and a value of it is shown by its fields:

il[5]> .class public sequential ansi sealed Point extends [System.Runtime]System.ValueType {
  struct Point
il[5]> .field public int32 X
il[5]> .field public int32 Y
il[5]> .method public instance void .ctor(int32 x, int32 y) {
il[5]> ldarg.0
il[5]> ldarg x
il[5]> stfld int32 Point::X
il[5]> ldarg.0
il[5]> ldarg y
il[5]> stfld int32 Point::Y
il[5]> ret
il[5]> }
  end of method .ctor
il[5]> }
  end of struct Point
il[6]> ldc.i4 3
il[6]> ldc.i4 4
il[6]> newobj instance void Point::.ctor(int32, int32)
il[6]> box Point
il[6]> ret
  = Point { X = 3, Y = 4 } : Point

Enter continues a block while its braces are open and sends it, line by line, once they balance; a pasted block waits for Enter, and a line the engine refuses brings the whole block back with that line selected. Tab completes opcodes and commands, with a palette that shows each candidate's stack transition. Up and Down walk history, which keeps a block as one entry in ~/.config/ilrepl/history between runs. .help lists the commands and .ops lists the opcodes.

Batch mode

ilrepl -e 'ldc.i4 6; ldc.i4 7; mul; ret'
ilrepl samples/Transcripts/exceptions.il
printf 'ldstr "piped"\nret\n' | ilrepl --no-color

How it works

Reflection.Emit needs a JIT, and the Native AOT front-end has none, so ilrepl is two processes: the front-end owns the terminal UI, the transcript, and completion; the host owns the session and answers over JSON-RPC on its standard streams. The same engine runs in the browser on the docs site, where the .NET runtime is compiled to WebAssembly.

Building

Requires the .NET 10 SDK. The browser build also needs the wasm-tools workload, and the docs need Node 22 with pnpm.

dotnet build
dotnet test
dotnet run --project src/IlRepl

dotnet build publishes the host into host/ beside the front-end. The tests cover the engine in-process on the real JIT, the sample library in samples/Greeter, every transcript in samples/Transcripts, the terminal UI on a headless terminal emulator, the front-end as a process in a PTY, and the docs site's live session in a real browser.

Repository utilities are file-based apps under scripts/:

dotnet run --file scripts/Generate-OpcodeReference.cs
dotnet run --file scripts/Publish-Wasm.cs
dotnet run --file scripts/Publish-NativeAot.cs -- --rid osx-arm64 --package-version 0.3.0

License

MIT
