rfIDEAS.ReaderIntegrationKit 1.5.1

rfIDEAS.ReaderIntegrationKit

A .NET library for communicating with rf IDEAS readers using a high-level reader interface. This package wraps the Reader Integration Kit native library, providing easy integration for .NET applications on Windows, Linux (x64, ARM64, and 32-bit ARM hard-float), and macOS 12.0+ (Intel + Apple Silicon).

Features

• High-level reader API for reader operations
• Support for WaveID reader types
• Native library support for Windows (x64), Linux (x64), Linux ARM64 (generic + Raspberry Pi 5), Linux 32-bit ARM (ARMhf), and macOS 12.0+ (Intel x86_64 + Apple Silicon arm64, universal binary)
• .NET 8.0 and .NET 10.0 compatibility
• Distributed via NuGet

Getting Started

1. Install via NuGet:

   dotnet add package rfIDEAS.ReaderIntegrationKit


2. Add the using directives:

   using rfIDEAS.ReaderIntegrationKit;
   using rfIDEAS.ReaderIntegrationKit.Objects;
   using rfIDEAS.ReaderIntegrationKit.Enum;


Prerequisites

• Windows 10/11 (x64), Linux x64, Linux ARM64 / ARMhf (Ubuntu 24.04+ or equivalent), or macOS 12.0 (Monterey) or later (Intel x86_64 or Apple Silicon arm64)
• A connected rf IDEAS reader (USB or serial), e.g. WaveID
• .NET 8.0 or later (the package targets .NET 8.0 and .NET 10.0)
• Windows: No additional setup required
• Linux: Appropriate udev rules may be required for USB reader access

Supported Platforms

Native libraries are included in the NuGet package and are automatically resolved at runtime for supported platforms.

osx-universal fallback: runtimes/osx-universal/native/libReaderIntegrationKit.dylib is included for environments that do not resolve a specific RID.

ARM64: generic vs. Raspberry Pi 5

The package ships two ARM64 builds in runtimes/linux-arm64/native/:

• libReaderIntegrationKit.so — portable aarch64 build, runs on any ARMv8-A device.
• libReaderIntegrationKit.pi5.so — build optimised for the Raspberry Pi 5 (-mcpu=cortex-a76).

At runtime the loader selects the variant via RIK_ARM_VARIANT when set (pi5 or generic); otherwise it reads /proc/device-tree/model and falls back to generic. Set RIK_ARM_VARIANT=pi5 to force the Pi 5-optimised build, or RIK_ARM_VARIANT=generic for the portable build.

Known Issues

1.5.0 — macOS arm64 SIGKILL 137 (fixed in 1.5.1)

The 1.5.0 NuGet package ships a libReaderIntegrationKit.dylib with an invalid code signature on macOS. On Apple Silicon (arm64) with SIP enabled, any call that loads the library — including AbstractReader.GetLibraryInfo() — will be killed by the kernel with SIGKILL (exit code 137).

Root cause: The build system produced an improperly signed binary.

Fix: Upgrade to 1.5.1 or later.

Workaround for 1.5.0: Re-sign the bundled dylib with an ad-hoc signature:

codesign -f -s - \
  "$(dotnet nuget locals global-packages -l | awk '{print $NF}')/rfideas.readerintegrationkit/1.5.0/runtimes/osx-arm64/native/libReaderIntegrationKit.dylib"

Note: dotnet publish -r linux-arm64 flattens native libraries to the publish output root. The runtimes/ directory tree is not present in a RID-targeted publish output. Do not configure your application to look for natives under runtimes/ after a RID-targeted publish.

Usage Example

WaveID Reader

using rfIDEAS.ReaderIntegrationKit;
using rfIDEAS.ReaderIntegrationKit.Objects;
using rfIDEAS.ReaderIntegrationKit.Enum;

var readerDefinition = new ReaderDefinition
{
    DeviceId = new DeviceId { VendorId = 0x0c27, ProductId = 0x3bfa },
    ProtocolType = ProtocolType.FeatureReport
};

using var reader = new Reader(readerDefinition);
reader.Init();

// Get reader metadata (populated lazily on first access)
var metadataStruct = reader.GetMetadata();
Console.WriteLine($"Part Number: {metadataStruct.PartNumber}");

// Force refresh metadata from device
metadataStruct = reader.GetMetadata(forceRefresh: true);

// Beep the reader
reader.Beep(2, BeepDuration.BeepDurationShort);

// Get beeper volume
var volume = reader.GetBeeperVolume();
Console.WriteLine($"Beeper Volume: {volume}");

Documentation

For integration guides and complete API reference, see the rf IDEAS Documentation.

License

This package is distributed under the rf IDEAS End-User License Agreement (EULA). By installing or using this package, you agree to the terms of the EULA included in the package. See the rfIDEAS_EULA.txt file distributed with this package for full terms and conditions.

Copyright rf IDEAS, Inc. All rights reserved.
