Canvas and Open GL Stock and Financial Charts

Generic real-time charts for WPF apps.

The main purpose of this app is to be used as a charting tool for real-time financial applications, e.g. backtesters for trading strategies. Here is the most comprehensive guide dedicated to charting in .NET that I have seen so far. Nevertheless, trying various options from that guide I wasn't able to find anything flexible enough for my needs, so created my own.

Drawing Methods

Currently available controls.

• CanvasControl - extended WPF Canvas control exposing DrawingContext used with Shapes and Geometries
• CanvasImageControl - a wrapper around SkiaSharp and Open GL

In order to add a different type of panel, e.g. GDI+ or Direct2D, you need to implement ICanvasControl interface.

Chart Types

At the moment, there are four built-in chart types.

• Line - line
• Bar - polygon
• Area - polygon
• Candle - OHLC box, a mix of a line and a rectangle polygon

If there is a need to create a new chart type, then you need to implement IShape interface.

Pan and Zoom

The chart is completely data-centric, thus in order to scale the chart you need to change the data source. By default, the chart displays last 100 data points, as defined in IndexCount property.

MinIndex = Items.Count - IndexCount
MaxIndex = Items.Count

To pan the chart to the left, subtract arbitrary value from both MinIndex and MaxIndex.

MinIndex -= 1
MaxIndex -= 1

To pan the chart to the left, do the opposite.

MinIndex += 1
MaxIndex += 1

To zoom in, increase MinIndex and decrease MaxIndex to decrease number of visible points.

MinIndex += 1
MaxIndex -= 1

To zoom out, do the opposite.

MinIndex -= 1
MaxIndex += 1

Data source sample

To simplify sycnhronization of multiple charts, data source has format of a list where each entry point has a time stamp and a set of Areas and Series that will be rendered in the relevant viewport.

[
  DateTime
  {
    Area A
    {
      Line Series => double,
      Candle Series => OHLC
    },
    Area B
    {
      Line Series => double,
      Line Series => double
    },
    Area C
    {
      Bar Series => double
    }
  },
  DateTime,
  DateTime,
  DateTime
]

• Area is a viewport, an actual chart, each viewport can show several types of series, e.g. a mix of candles and lines.
• Series is a single chart type to be displayed in the viewport, e.g. lines.
• Model is a data point of dynamic type, can accept different type of inputs, e.g. double or OHLC box.

At this moment, Painter supports only horizontal orientation, so the axis X is used as an index scale that picks data points from the source list and axis Y is a value scale that represents the actual value of each data point.
