ExcelDocumentWriter 1.0.2

EXAMPLE

The following code demonstrates how to use MiniExcel to generate an Excel file programmatically. <br> The file "Test.xlsx" will be automatically created and saved when the Dispose method is invoked. <br> This library is built on the Open XML SDK, so it works even without Microsoft Excel installed. Moreover, there are no restrictions unique to the Open XML SDK. <br> MiniExcel is a lightweight, meaning-driven Excel generator designed for clarity, performance, and independence from external dependencies.

Ver.1.0.1<br> Minor fixes, with target OS restrictions removed.

Ver.1.0.2<br> Removed unnecessary library references.

using HimClassLib9.ExcelDocumentWriter;

public void MatrixTest() {
	using (ExcelWorkbook workBook = new(@"C:\Users\MyAccount\.....\Test.xlsx")) {
		ExcelWorkSheet  workSheet1  =  workBook.AddWorksheet("Sheet01");
		//	If a sheet name is duplicated, it will be renamed to ensure it is unique.
		ExcelWorkSheet  workSheet2  =  workBook.AddWorksheet("Sheet01");

		this.HeaderDraw(workSheet1);
		this.HeaderDraw(workSheet2);
		this.SetFormula(workSheet1, true);
		this.SetFormula(workSheet2, false);
		this.SetBorder(workSheet1);
		this.SetBorder(workSheet2);
	}   //	The file is created and saved by the Dispose method.
}

private void HeaderDraw(ExcelWorkSheet workSheet) {
	workSheet.SetFreezePane(1, 1);
	workSheet.ColumnWidth(1, 10, 5.63D);   //	Set columns Width
	workSheet.ShowGridLines = false;       //	Hide the gridlines

	for (int idx = 1; idx < 10; idx++) {
		workSheet.CellValue(idx, (uint)(idx + 1), 1);   //	Set a value in the cell
		workSheet.CellValue(idx, 1, (uint)(idx + 1));   //	Set a value in the cell
	}
}

private void SetFormula(ExcelWorkSheet workSheet, bool mode) {
	workSheet.MoveTopLeft();    //	Reset to 'A1'
	workSheet.MoveDown();       //	Move to the beginning of the next line
	workSheet.MoveRight();      //	Move the cursor one cell to the right
	for (uint row = 1; row < 10; row++) {
		string  rowAddress  =   ExcelBookSheetSupport.GetCellReference(1, row + 1);
		for (uint col = 1; col < 10; col++) {
			string  colAddress  =   ExcelBookSheetSupport.GetCellReference(col + 1, 1);
			if (mode) {
				workSheet.CellFormula($"={colAddress}*{rowAddress}");   //	Set a formula in the cell
			} else {
				workSheet.CellFormula($"={colAddress}+{rowAddress}");   //	Set a formula in the cell
			}
			workSheet.MoveRight();  //	Move the cursor one position to the right
		}
		workSheet.MoveDown();       //	Move to the beginning of the next line
		workSheet.MoveRight();      //	Move the cursor one cell to the right
	}
}

private void SetBorder(ExcelWorkSheet workSheet) {
	workSheet.CellRangeFill(1, 2, 1, 10, "E2EFDA");
	workSheet.CellRangeFill(2, 1, 10, 1, "E2EFDA");
	workSheet.CellRangeFill(2, 2, 10, 10, "D9E1F2");
	//workSheet.CellRangeBorder(2, 2, 10, 10, BorderType.MATRIX, BorderLineValues.Thin);
	workSheet.CellRangeBorder("B2:J10", BorderType.MATRIX, BorderLineValues.Thin);
	//workSheet.CellRangeBorder(2, 2, 10, 10, BorderType.OUTERBOX, BorderLineValues.Thick);
	workSheet.CellRangeBorder("B2:J10", BorderType.OUTERBOX, BorderLineValues.Thick);
	workSheet.CellRangeBorder(1, 2, 1, 10, BorderType.BOTTOM, BorderLineValues.Thin);
	workSheet.CellRangeBorder(1, 2, 1, 10, BorderType.OUTERBOX, BorderLineValues.Thick);
	workSheet.CellRangeBorder(2, 1, 10, 1, BorderType.LEFT, BorderLineValues.Thin);
	workSheet.CellRangeBorder(2, 1, 10, 1, BorderType.OUTERBOX, BorderLineValues.Thick);
	workSheet.CellRangeAlignment(1, 2, 1, 10, VerticalCellAlignment.Center, HorizontalCellAlignment.Center);
	workSheet.CellRangeAlignment(2, 1, 10, 1, VerticalCellAlignment.Center, HorizontalCellAlignment.Center);
	workSheet.CellRangeAlignment(2, 2, 10, 10, VerticalCellAlignment.Center, HorizontalCellAlignment.Center);
}
