ISZSharp 1.0.1

ISZSharp

ISZSharp is a managed C# library for decompressing UltraISO ISZ disc images back to the plain images they were made from. It reads whole images and split sets, all four chunk storage kinds (zero-elided, stored, zlib, bzip2), the obfuscated tables and stripped bzip2 headers real UltraISO files carry, and validates UltraISO's own checksum when the file provides one.

The library is the ISZ decompression engine used by Batch Convert to CHD, where it restores an ISZ to a plain image before converting it to CHD with chdman or CHDSharp.

• Repository: https://github.com/purelogiccode/BatchConvertToCHD
• Package: https://www.nuget.org/packages/ISZSharp

Table of contents

• Features
• Requirements
• Installation
• Quick start
• Usage examples
  • Inspect a header without decoding
  • Decompress with progress and cancellation
  • Locate the segments of a split image
• Error handling
• API reference
  • IszDecoder
  • IszHeader
  • IszChunkType
  • IszSegment
  • IszDecodeResult
• Supported ISZ layouts
• How it works
• Building from source
• References
• License

Features

• Whole and split images — .isz on its own, or a set split across .i01, .i02, … segments, all read as one logical stream.
• Every segment naming scheme in the wild — the specification's game.isz/game.i01/game.i02, plus the game.part01.isz and game.part001.isz forms other writers use.
• All four chunk kinds — all-zero chunks (ADI_ZERO), stored data (ADI_DATA), zlib (ADI_ZLIB) and bzip2 (ADI_BZ2).
• Real-file behaviours the specification omits — the segment and chunk tables are stored obfuscated and are de-obfuscated on read; bzip2 chunks are stored without their BZh stream header and it is restored before decompression; a zero pointer offset means there is no chunk table and the image is one raw run.
• Checksum validation — when the file carries UltraISO's 64-byte header, the CRC32 of the restored image is verified and a mismatch fails the decode.
• Refuses rather than guesses — encrypted images (AES-128/192/256 or password) are reported by name, truncated files and damaged tables are reported, and a failed decode deletes its partial output because a short image would convert and look fine.
• No native dependencies — pure managed code; bzip2 comes from SharpCompress, zlib from the BCL.

Requirements

The package contains a separate assembly for each target framework, so the correct build is selected automatically by NuGet.

Read-only: ISZSharp can open, inspect and decompress ISZ files. It cannot create or modify them, and it cannot decrypt an encrypted image — UltraISO itself has to save one as a plain ISO first.

Installation

dotnet add package ISZSharp

or with the Package Manager console:

Install-Package ISZSharp

Quick start

using ISZSharp;

var iszPath = @"C:\Games\Breath of Fire IV.isz";
var isoPath = @"C:\Games\Breath of Fire IV.iso";

var header = await IszDecoder.TryReadHeaderAsync(iszPath, CancellationToken.None);
if (header is null)
{
    Console.Error.WriteLine("Not an ISZ image.");
    return;
}

var unusable = header.GetUnusableReason();
if (unusable is not null)
{
    Console.Error.WriteLine($"Cannot decode it: {unusable}");
    return;
}

var result = await IszDecoder.DecodeAsync(
    iszPath,
    isoPath,
    message => Console.WriteLine(message),
    CancellationToken.None
);

Console.WriteLine(result.Success ? $"Wrote {result.OutputPath}" : $"Failed: {result.FailureReason}");

Usage examples

Inspect a header without decoding

TryReadHeaderAsync reads only the first 64 bytes, so a file can be checked before any space is committed to the restored image. It returns null when the file does not start with an ISZ header.

using ISZSharp;

var header = await IszDecoder.TryReadHeaderAsync(iszPath, CancellationToken.None);
if (header is not null)
{
    Console.WriteLine($"Version:           {header.Version}");
    Console.WriteLine($"Sector size:       {header.SectorSize} bytes ({header.TotalSectors:N0} sectors)");
    Console.WriteLine($"Restored size:     {header.ImageSizeBytes:N0} bytes");
    Console.WriteLine($"Chunks:            {header.ChunkCount:N0} x {header.ChunkSize:N0} bytes");
    Console.WriteLine($"Pointer width:     {header.PointerLength} bytes");
    Console.WriteLine($"Split:             {header.IsSegmented}");
    Console.WriteLine($"Encrypted:         {header.IsEncrypted} ({header.EncryptionDescription})");
    Console.WriteLine($"UltraISO checksum: {(header.HasChecksums ? "present" : "absent")}");

    // What the decoder would say about it, or null when it can be decoded.
    Console.WriteLine($"Usable:            {header.GetUnusableReason() ?? "yes"}");
}

The header's offsets are absolute file offsets into the first segment, so ChunkTableOffset, SegmentTableOffset and DataOffset can be inspected directly.

Decompress with progress and cancellation

DecodeAsync writes the restored image and reports progress through the log callback roughly every 10%, plus notes about the header and any split. Cancellation is checked between chunks; a cancelled or failed decode deletes the partial output before returning or throwing.

using ISZSharp;

var result = await IszDecoder.DecodeAsync(
    iszPath,
    isoPath,
    message => Console.WriteLine(message),
    cancellationToken
);

if (result.Success)
{
    // result.SectorSize tells you how the restored image should be classified:
    // 2048 is a plain ISO/DVD image, 2352 is a raw CD image, and so on.
    Console.WriteLine($"Restored {result.OutputPath} ({result.SectorSize}-byte sectors).");
}
else
{
    Console.Error.WriteLine(result.FailureReason);
}

Locate the segments of a split image

GetSegmentPath returns the file that holds segment n (the .isz itself is segment 0), following whichever naming scheme the first segment uses. GetDecodedFileName gives the restored image's name.

using ISZSharp;

foreach (var path in new[] { @"D:\roms\Game.isz", @"D:\roms\Game.part001.isz" })
{
    for (var segment = 0; segment < 3; segment++)
        Console.WriteLine(IszDecoder.GetSegmentPath(path, segment));
}

// D:\roms\Game.isz
// D:\roms\Game.i01
// D:\roms\Game.i02
// D:\roms\Game.part001.isz
// D:\roms\Game.part002.isz
// D:\roms\Game.part003.isz

Console.WriteLine(IszDecoder.GetDecodedFileName(@"D:\roms\Game.part001.isz")); // Game.part001.iso

Segments must sit in the same folder as the first file. Missing segments are named in the failure reason, and a segment whose volume serial number does not match the first file's is refused rather than spliced in.

Error handling

DecodeAsync never throws for file-content problems; it returns an IszDecodeResult whose FailureReason is written for the end user (it says what to do about the problem, not just what went wrong). An OperationCanceledException still propagates when the token is cancelled.

A decode that fails after writing has started deletes the partial image before returning, so a failed DecodeAsync never leaves a short image behind.

API reference

All types live in the ISZSharp namespace.

IszDecoder

The entry point. A static class, because an ISZ is decoded in one pass to a file.

DecodeAsync reads the whole chunk table up front but streams the chunk data, so memory use is bounded by the chunk size, not by the image size.

IszHeader

The parsed header of the first segment. A read-only record.

IszChunkType

How one chunk is stored, from the top two bits of its table entry:

IszSegment

One entry of a split image's segment table: Size, ChunkCount, FirstChunkNumber, ChunkOffset, LeftSize, and IsTerminator for the zero-size entry that ends the table.

IszDecodeResult

Supported ISZ layouts

ISZ files from UltraISO and its imitators vary in ways the published specification does not describe; the behaviours below come from comparing the two independent open-source readers, libMirage's ISZ filter and isz-tool, both of which were checked against real files.

• Obfuscated tables — the segment and chunk tables are XORed with the complement of IsZ! (B6 8C A5 DE, cycling). ISZSharp de-obfuscates every table it reads.
• Stripped bzip2 header — a bzip2 chunk is stored with its first three bytes cleared; ISZSharp writes BZh back before decompressing, exactly as the reference readers do.
• No chunk table — a zero pointer offset means the data is one uncompressed run; the chunk count and size in the header drive the read.
• Split naming — game.isz/game.i01, game.part01.isz/game.part02.isz and game.part001.isz/game.part002.isz.
• Zero chunks — the entry may or may not record the uncompressed length; either way a whole chunk (or the correct partial final chunk) of zeros is produced and no data bytes are consumed.
• Encrypted images — recognised (AES-128, AES-192, AES-256, password) and refused by name. Decryption would need the user's password and is deliberately not implemented.

How it works

An ISZ file starts with a 48-byte header, which UltraISO extends to 64 bytes:

A split image follows with a segment table of 24-byte entries (size, chunk count, first chunk, chunk offset, left-over bytes), terminated by a zero-size entry. Then comes the chunk table: one little-endian entry per chunk whose top two bits are the storage kind and whose remaining bits are the stored length. The rest of the file is chunk data, stored back to back; a chunk may straddle a segment boundary, which is why ISZSharp reads all segments as one stream. A file with no chunk table has no table at all and its data begins straight after the header.

Decoding walks the chunk table once, decompresses each chunk, and writes the image capped at TotalSectors × SectorSize, so a writer that padded its final chunk cannot lengthen the image. The bytes written are counted and checked against the declared size, and fed to the CRC32 when the header carries one; either mismatch deletes the output and reports the file as truncated or damaged.

Building from source

The library lives in the Batch Convert to CHD repository under ISZSharp/.

git clone https://github.com/purelogiccode/BatchConvertToCHD.git
cd BatchConvertToCHD
dotnet build ISZSharp/ISZSharp.csproj -c Release
dotnet pack ISZSharp/ISZSharp.csproj -c Release -o artifacts

The test suite for the library lives in BatchConvertToCHD.Tests/:

dotnet test BatchConvertToCHD.Tests/BatchConvertToCHD.Tests.csproj -c Release --filter "FullyQualifiedName~Isz"

References

• EZB Systems' ISZ File Format Specification 1.00 — the published format the header, segment table and chunk table layouts come from.
• libMirage's ISZ filter (GPL-2+) and isz-tool (GPL-3) — the independent readers the real-file behaviours (obfuscated tables, stripped bzip2 header, no chunk table, checksum calculation) were checked against.

License

ISZSharp is released under the MIT license.
