Proxeno.Kiln 0.5.0

Kiln

A from-scratch H.264 encoder for .NET. Pure managed, SIMD-accelerated C#, zero native dependencies, Apache-2.0. Feed it raw frames and it hands back a standards-compliant H.264 baseline bitstream — the whole codec (bitstream, transforms, intra/inter prediction, motion search, entropy coding, deblocking) is implemented here, in this repository, against the ITU-T H.264 specification. No native codec to cross-compile, ship, or keep patched.

Status: pre-release (0.x). APIs will change. Every capability listed here is backed by a test in this repository — including smoke tests that decode every produced stream with an independent reference decoder as an oracle — and the What Kiln is not section says plainly what isn't here.

What you can build

Kiln is the encode step: one .NET process turns rendered or captured frames into an H.264 stream you can send anywhere, with no native runtime on the box. It's built for low-latency, real-time video, such as:

• Game & cloud-gaming streaming — render and encode on a server, play in a browser or thin client with well-under-a-second glass-to-glass latency.
• Screen capture & remote desktop — a headless host encoding its own output frame by frame.
• Camera & robotics video — live feeds from cameras, drones, or robots to an operator's screen.
• A source for a WebRTC / RTP pipeline — Kiln emits Annex B access units that drop straight into a stack like Keryx or any RTP packetizer.
• Anywhere you need low-latency managed H.264 inside a .NET process without bundling a native codec or taking on GPL/LGPL linkage.

Goals

• Pure managed. 100% C# on .NET 10 with hardware intrinsics — NEON/AdvSimd on arm64, AVX2 and SSSE3 on x64, scalar fallback everywhere else. No native library to cross-compile, ship, or patch.
• Genuinely open. Apache-2.0, original work that links no copyleft code — embed it in commercial or proprietary products where GPL/LGPL codec linkage is a problem. That's exactly why it exists.
• Faithful to the spec. Written against ITU-T H.264 (ISO/IEC 14496-10); every numeric table that originates in the spec carries its clause/table citation in the source (Table 9-4, §8.5.9, §9.2.1, …).
• Real-time first. Predictable per-frame latency over maximum compression: a steady stream of low-latency frames beats a slow exhaustive search.
• Honest about scope. A 0.x that tells you exactly what is proven and what isn't here yet.

Quick start

using Kiln;
using Kiln.RateControl;

var encoder = new H264BaselineEncoder(1280, 720, new H264BaselineEncoderOptions
{
    QuantizationParameter = 28,
    KeyframeIntervalFrames = 120,
    SliceCount = 4,                         // parallel slice encoding
    SpeedMode = EncoderSpeedMode.Balanced,  // measured speed/quality preset
});

var annexB = new byte[1280 * 720 * 2];

// Planar I420 input; u/v are half-resolution planes.
var written = encoder.EncodeFrame(y, u, v, strideY: 1280, strideUv: 640, annexB);
var wasIdr = encoder.LastFrameWasIdr;
// annexB[0..written] is a complete Annex B access unit (SPS/PPS included on IDR).

What you get

A real encoder, not a toy — the parts a low-latency streaming server actually needs:

• Baseline bitstream that just plays. Constrained baseline profile, IDR + P-frames, CAVLC entropy coding, Annex B output (SPS/PPS carried on every IDR) that streams straight into a WebRTC or RTP packetizer and decodes on browsers and hardware decoders.
• Genuine coding tools. Intra 4×4 / 16×16 with RD mode selection, P-slice inter prediction with sub-pel SATD motion search, P_Skip, and multiple reference frames.
• Quality knobs. In-loop deblocking, optional greedy trellis quantization, variance-based spatial adaptive QP, and per-frame rate control.
• A measured speed ladder. Four SpeedMode presets over the motion-search knobs, each a measured point on the speed/quality curve, plus a deterministic per-frame motion-search work budget that bounds the worst-case frame time without making bitstreams timing-dependent.
• Parallelism built in. Multi-slice frames encode their slices in parallel and bound the region a lost packet can damage.
• SIMD with a safety net. NEON/AdvSimd, AVX2 and SSSE3 kernels selected at runtime, each covered by parity tests against a scalar reference; CI runs the full suite on Linux, Windows and macOS so both architectures stay green.
• A wired adaptation loop. H264StreamingSession connects Kiln.RateControl (low-latency rate controller with network feedback) and Kiln.Recovery (IDR budgeting / keyframe recovery) to the encoder: feed it network feedback per frame and get adaptive QP, bitrate, IDRs, and live speed-mode changes out — deterministically, with no glue code on your side.
• Verified. 2,249 tests — spec-roundtrip decoding, SIMD/scalar parity, golden-frame regression, PSNR fidelity floors, adversarial neighbour-availability sweeps, byte-exact reconstruction-vs-ffmpeg conformance oracles, and independent-decoder smoke tests over every produced stream.

Options reference

Performance

Measured on Apple M5 Max (arm64, NEON/AdvSimd), .NET 10, quiet machine, QP 28, steady P-frames over deterministic synthetic content. Every number is reproducible from the harnesses in bench/Kiln.Benchmarks (--slice-quick, --speed-modes, --speed-modes-timing, --speed-modes-tiers), with competing configurations interleaved in one process so scheduling drift hits every arm equally. Three questions, in the order a deployment asks them: what does the default cost, what can a speed mode buy, and what is the worst case.

Default quality on realistic content

Steady P-frame medians on textured scroll-plus-noise content ("coherent motion" — a camera pan or game scroll; neither a best case nor a stress case), default options:

Slices do not divide the work cleanly. Four slices buy about 2.2x at 1080p — not 4x — and eight buy essentially nothing beyond four: per-slice motion cost doesn't balance perfectly, and the frame still pays serial per-frame work. Slices also cost bits, because slice boundaries reset MV/skip prediction: measured +5% to +26% bitrate at QP 28 going from 1 to 4 slices depending on content (up to ~+40% on cheap coherent frames at QP 23). Choose SliceCount for latency and packet-loss confinement and budget for both costs; do not expect linear returns.

The speed-mode ladder: best achievable and its price

H264BaselineEncoderOptions.SpeedMode selects a measured preset over four motion-search knobs (MaxReferenceFrames, UseMotionSatd, SubPartitionRangeCap, MotionSearchEffortCapPerMb); any of those you assign explicitly wins over the mode. All rungs keep bitstreams deterministic — the effort budgets count algorithmic work, never wall clock. 1080p steady-P medians:

And the quality price, 1080p QP 28, PSNR / bitrate versus HighQuality by content class:

Read it as: on static and coherent content Balanced and Fast are near-free and VeryFast costs about a decibel; when content turns violent, the capped modes hold their frame time and pay in quality and bits exactly there. The price concentrates at low QP, where frames that genuinely need a wide search are cut off hardest — at QP 23 Balanced measures −6.8 dB on the high-motion generator and −3.7 dB on scene cuts. If you run QP ≤ 23 on demanding content, prefer HighQuality, or compose your own point on the curve (e.g. SpeedMode = Balanced with an explicit, higher MotionSearchEffortCapPerMb — the explicit knob wins).

Worst case

The number that breaks a real-time deployment is not the mean but the hostile frame. On the divergent-motion stress generator (opposing half-screen scrolls plus counter-moving blocks) the default configuration measures 205 ms/frame at 1080p single-slice (70 ms at 4 slices) against 27/10 ms on coherent content in the same run — a ~7x content-dependent swing with no bound. The bound is MotionSearchEffortCapPerMb (set by every non-default speed mode): a deterministic per-frame work budget that degrades the search in steps as it depletes, cutting that worst case to 80 ms (Balanced) / 64 ms (Fast) / 20 ms (VeryFast) single-slice, while charging quality only when it actually binds. If your content is unusual, size the cap yourself — the --speed-modes-tiers harness shows how hard a given cap binds per content class.

For most real-time use, bound the tail without taking the quality trade. The default HighQuality is the only mode that leaves MotionSearchEffortCapPerMb at 0, so it is also the only one with no worst-case bound — 10 ms typical at 1080p 4-slice, but 70 ms (14 fps) on a hostile frame. Because an explicitly-set option always beats the mode, you can keep every HighQuality coding decision and add just the bound:

var encoder = new H264BaselineEncoder(1920, 1080, new H264BaselineEncoderOptions
{
    SpeedMode = EncoderSpeedMode.HighQuality,   // 2 refs, SATD ME, full sub-partition range
    MotionSearchEffortCapPerMb = 512,           // explicit assignment overrides the mode's 0
});

That costs about −0.01 dB on coherent content — the cap charges quality only where it binds — and pulls the hostile case in to roughly 35-40 ms at 4 slices. Prefer it over Balanced when you want the bound but not the single-reference trade, which is what costs Balanced its −0.7 to −2.9 dB on high-motion content at QP ≤ 28.

Microbenchmarks and the perf gate

The committed perf-gate baselines (perf/, BenchmarkDotNet):

That 2.24 ms row is measured on near-static synthetic content — size deployments from the realistic-content tables above, not from it. Perf discipline is part of the repo: bench/Kiln.Benchmarks plus scripts/h264-simd-capture-baseline.sh and scripts/h264-simd-perf-gate.sh gate changes against the committed baseline in perf/. See docs/perf-gate.md.

What Kiln is not

Not an x264 competitor. No B-frames, no CABAC, no 8×8 transform, no interlace; 4:2:0 8-bit only. If you need maximum compression at any CPU cost, use a full-profile encoder. If you need clean-licensed, dependency-free, low-latency H.264 inside a .NET process, you are in the right place.

Frame dimensions need not be multiples of 16: sizes like 1920×1080 or 1366×768 are supported via SPS frame cropping — the encoder pads to the 16×16 macroblock grid internally and signals the true display size, which is what decoders output. Dimensions must be even (4:2:0 chroma is subsampled 2×2, so odd extents are unrepresentable). By default the encoder signals the lowest H.264 level whose frame-size limit (MaxFS, Annex A Table A-1) admits the padded picture, floored at Level 3.1 — 1920×1080 codes as 1920×1088 (8160 macroblocks) and signals Level 4.0 automatically. Set H264BaselineEncoderOptions.LevelIdc explicitly to pin a level; an explicit level that is too small for the frame throws, naming the lowest sufficient level. The chosen level is readable from H264BaselineEncoder.LevelIdc.

0.x behavioural change: LevelIdc previously defaulted to 31 (Level 3.1) and the constructor threw for frames above 1280×720. The default is now 0 = auto-select. Streams ≤720p with default options are byte-identical to before (the auto floor is still 3.1); larger frames now construct and encode instead of throwing. EncodeFrame's output span now has a documented recommended size, H264BaselineEncoder.RecommendedOutputBufferSize.

0.x conformance fix: two deblocking bugs made the encoder's reconstruction drift from every conformant decoder's — the luma filter ignored the §8.7.2.2 QP average across macroblock edges, and boundary-strength derivation inverted §8.7.2.1's precedence of coded coefficients over MV differences. Streams using per-MB QP (TargetBitsPerFrame, AdaptiveQuantStrength) and constant-QP streams at QPs where Table 8-17 distinguishes bS 1 from 2 (e.g. 31, 32, 35, 36) produce different — now correct — bytes. Default-option streams and QP 23/28/33/34 constant-QP streams are unaffected. Verified byte-exact against both ffmpeg and VideoToolbox.

On the real-time story, be precise about what is wired and what is not. The adaptation loop is wired: H264StreamingSession owns an encoder plus the rate controller, and per frame turns EncoderNetworkFeedback (loss, RTT, queue depth, PLI/FIR) into applied settings — slice QP, a per-picture bit budget, recovery IDRs, and live SpeedMode changes, including the reference-count component, which swaps mid-GOP without an IDR because the SPS-signalled DPB size is an upper bound the operating count may sit below:

using var session = new H264StreamingSession(1280, 720);
var buffer = new byte[session.RecommendedOutputBufferSize];
// Each frame: pass the latest transport snapshot, get adaptive encoding out.
var result = session.EncodeFrame(y, u, v, strideY, strideUv, buffer, feedback);
// result.WasIdr, result.AppliedSliceQp, result.Decision.TargetBitrateBps, …

The session is deterministic (identical frames + feedback → identical bytes; wall-clock load figures participate only if you pass them in), and it is honest about its limits: resolution decisions are surfaced as recommendations until you can supply rescaled frames and call ChangeResolution (Kiln has no scaler; the session recreates the encoder and the next frame is an IDR with the new SPS), and TargetFps is a pacing contract for your capture loop (the SPS carries no timing info). Gradual intra refresh is implemented: construct with IntraRefreshPeriodFrames = N and a recovery request that lands in the IDR cooldown starts a refresh wave — a band of intra MB columns sweeping the picture over up to N frames, with constrained_intra_pred_flag and motion vectors restricted to the refreshed region, so a decoder joining at the wave start (SPS/PPS and a recovery-point SEI are repeated there) reconstructs byte-exactly once the wave completes, for a bounded per-frame premium instead of an IDR-sized spike. With the option at its default 0 the flag is off and streams are byte-identical to previous releases. Frame pacing and input dropping stay in your capture loop by design (the capture sample shows a latest-frame-wins hand-off; report your drops via EncoderPipelineTimings and the controller sees them). The full taxonomy of what may change mid-stream at which boundary is in docs/architecture.md.

Installing

Published on nuget.org as Proxeno.Kiln. The package id is Proxeno.Kiln; the assembly and namespace stay Kiln, so code uses using Kiln;.

dotnet add package Proxeno.Kiln

Try it

samples/Kiln.Capture records your camera to a playable .m4v — capture, colour conversion, H.264 encode and MP4 muxing, all managed, no native binaries anywhere in the pipeline:

dotnet run --project samples/Kiln.Capture -- list
dotnet run --project samples/Kiln.Capture -- record --seconds 10 --output capture.m4v

Documentation

• samples/Kiln.Capture — camera → .m4v sample, and how the MP4 muxing works
• docs/architecture.md — pipeline stages, SIMD kernel structure, subsystems
• docs/perf-gate.md — benchmark baseline + regression gate workflow
• CONTRIBUTING.md — build, test, and contribution rules
• SECURITY.md — reporting vulnerabilities

License

Apache-2.0 — see LICENSE. © Kiln contributors.
