SerializerFoundation 1.1.0

SerializerFoundation

High performance serialization infrastructure for C#. The package targets netstandard2.0, netstandard2.1 and net9.0 or greater.

SerializerFoundation is extracted from the MessagePack-CSharp v4 rewrite; its performance that outclasses other serializers is built on this foundation. A serializer needs a forward-only buffer, and it needs to support several input and output types such as Span<byte>, IBufferWriter<byte> and ReadOnlySequence<byte>. SerializerFoundation abstracts these behind IWriteBuffer and IReadBuffer, and provides a buffer layer optimized so that the JIT can specialize code per buffer type.

Beyond serializers, it is also suited to any binary reading and writing, such as implementing a network protocol or laying out a database format.

dotnet add package SerializerFoundation

Serializers write into an IWriteBuffer and read from an IReadBuffer. Both are deliberately small.

public interface IWriteBuffer : IDisposable
{
    long BytesWritten { get; }

    // a writable span of at least sizeHint bytes (sizeHint == 0: some non-empty span)
    Span<byte> GetSpan(int sizeHint = 0);

    // commits bytes written into the span from GetSpan
    void Advance(int bytesWritten);

    // pushes buffered bytes to the underlying destination, when there is one
    void Flush();
}

public interface IReadBuffer : IDisposable
{
    long BytesConsumed { get; }
    long BytesRemaining { get; }

    // the unread part of the current contiguous window, never throws, empty only at end of data
    ReadOnlySpan<byte> GetUnreadSpan();

    // a contiguous window of at least sizeHint bytes, or false if fewer bytes remain
    // copies across segment seams as needed; does not consume bytes
    bool TryGetSpan(int sizeHint, out ReadOnlySpan<byte> span);

    // consumes bytes
    void Advance(int bytesConsumed);

    // copies the next destination.Length bytes without consuming them
    void CopyTo(Span<byte> destination);
}

The write side is the familiar GetSpan / Advance pair from IBufferWriter<byte>. The read side has the same shape, reading from a span and then advancing past it, but for optimization it offers several ways to read: GetUnreadSpan for whatever is contiguous right now, TryGetSpan for a window of a required size across segment seams, and CopyTo for copying out without building a contiguous window.

The basic pattern is to build your serializer's definitions on these interfaces, like the following.

// basic interface

public interface IFormatter<TWriteBuffer, TReadBuffer, T>
    where TWriteBuffer : struct, IWriteBuffer, allows ref struct
    where TReadBuffer : struct, IReadBuffer, allows ref struct
{
    void Serialize(ref TWriteBuffer buffer, T value);
    T Deserialize(ref TReadBuffer buffer);
}

public readonly record struct Point(int X, int Y);

public sealed class PointFormatter<TWriteBuffer, TReadBuffer> : IFormatter<TWriteBuffer, TReadBuffer, Point>
    where TWriteBuffer : struct, IWriteBuffer, allows ref struct
    where TReadBuffer : struct, IReadBuffer, allows ref struct
{
    public void Serialize(ref TWriteBuffer buffer, Point value)
    {
        buffer.WriteInt32(value.X);
        buffer.WriteInt32(value.Y);
    }

    public Point Deserialize(ref TReadBuffer buffer)
    {
        var x = buffer.ReadInt32();
        var y = buffer.ReadInt32();
        return new Point(x, y);
    }
}

// Reader/Writer for IReadBuffer/IWriteBuffer

using System.IO;
using System.Buffers.Binary;
using SerializerFoundation;

public static class BufferExtensions
{
    extension<TWriteBuffer>(ref TWriteBuffer buffer)
        where TWriteBuffer : struct, IWriteBuffer, allows ref struct
    {
        public void WriteInt32(int value)
        {
            BinaryPrimitives.WriteInt32LittleEndian(buffer.GetSpan(4), value);
            buffer.Advance(4);
        }
    }

    extension<TReadBuffer>(ref TReadBuffer buffer)
        where TReadBuffer : struct, IReadBuffer, allows ref struct
    {
        public int ReadInt32()
        {
            var span = buffer.GetUnreadSpan();
            if (span.Length < 4 && !buffer.TryGetSpan(4, out span))
            {
                throw new EndOfStreamException();
            }

            var value = BinaryPrimitives.ReadInt32LittleEndian(span);
            buffer.Advance(4);
            return value;
        }
    }
}

A serializer writes by requesting the space it needs with GetSpan and reporting how much it wrote with Advance, and a single serialization may make these calls hundreds or even thousands of times. Keeping the overhead of each call as close to zero as possible is therefore essential. A serializer also has to support both returning a byte[] and streaming writes to an IBufferWriter<byte>, which is what PipeWriter uses. IWriteBuffer ships with three implementations, ArrayPoolListWriteBuffer, BufferWriterWriteBuffer and SpanWriteBuffer, each handling its destination efficiently. By defining and calling code in terms of TWriteBuffer, GetSpan and Advance can be devirtualized and inlined regardless of the destination, keeping the overhead minimal.

When deserializing, the buffer has to support ReadOnlySpan<byte> as well as ReadOnlySequence<byte>, which is what PipeReader uses. Both are abstracted as IReadBuffer, so they are driven by the same code and can be inlined.

Unlike writing, when deserializing the required buffer size is sometimes unknown until reading begins: integers are commonly variable-length encoded in 1 to 5 bytes, and the length of a string is unknown until its header has been read. In addition, when the source is a ReadOnlySequence<byte>, the span you need may not be available as a whole when it straddles a segment boundary. So the flow is to take GetUnreadSpan first, call TryGetSpan only when it falls short, and finally call Advance.

Span lifetime is the one rule to keep in mind. A span from GetSpan, GetUnreadSpan or TryGetSpan stays valid until the next call that hands out a span (or Flush / Dispose), because that call may hand the window to the destination, return it to a pool, or replace it with a larger one. Advance and CopyTo do not invalidate a held span. Anything that may touch the buffer, such as a nested formatter, can request a window, so re-request the span after such calls instead of holding on to it.

Write Buffers

ArrayPoolListWriteBuffer supports byte[] Serialize<T>(T value) style APIs. It starts with the scratch span you provide, typically stackalloc memory. When the next requested window no longer fits, it rents another segment from ArrayPool<byte> without copying previously written bytes. Minimum segment sizes grow exponentially, with larger size hints accommodated as needed. ToArray() makes the final contiguous copy. This avoids the allocations and copying that a naive implementation incurs by growing through repeated Array.Resize calls.

Span<byte> scratch = stackalloc byte[512];
var buffer = new ArrayPoolListWriteBuffer(scratch);
try
{
    formatter.Serialize(ref buffer, value);
    return buffer.ToArray();
}
finally
{
    buffer.Dispose();
}

When the message has to be post-processed before it reaches its destination, GetWrittenSegments() returns a BufferSegments: a borrowed, zero-copy view of the written message, valid until the next write or Dispose. Each segment is a non-empty ReadOnlySpan<byte>, so a compressor or framing layer that accepts segmented input can consume it directly. Iterate with TryGetNext; Reset() restarts from the first segment. SegmentCount gives the number of segments up front, so a header that depends on it (a block count, a length table) can be written without a counting pass, and Length gives the total byte count.

var segments = buffer.GetWrittenSegments();
while (segments.TryGetNext(out var segment))
{
    stream.Write(segment);
}

BufferWriterWriteBuffer connects to the existing IBufferWriter<byte> ecosystem, including PipeWriter and ArrayBufferWriter<byte>. Call Flush() when the serializer is done to commit the staged bytes through IBufferWriter<byte>.Advance. With a PipeWriter, the caller must also call FlushAsync() to publish those bytes and observe backpressure.

var buffer = new BufferWriterWriteBuffer(pipeWriter);
try
{
    formatter.Serialize(ref buffer, value);
    buffer.Flush();
}
finally
{
    buffer.Dispose();
}
await pipeWriter.FlushAsync();

SerializerFoundation.WriteBufferExtensions.GetReference is a by-reference shortcut for GetSpan with the same contract. For example, an encoder can write a little-endian integer through Unsafe.WriteUnaligned:

ref byte destination = ref writer.GetReference(sizeof(int));
Unsafe.WriteUnaligned(ref destination, BitConverter.IsLittleEndian ? value : BinaryPrimitives.ReverseEndianness(value));
writer.Advance(sizeof(int));

Read Buffers

Wrapping a byte[] in ReadOnlySpanReadBuffer lets it be consumed as an IReadBuffer. The wrapper is very thin, so performance is on par with working directly on a ReadOnlySpan<byte> with Slice.

Slicing a ReadOnlySequence<byte> directly is slow, so processing its internal chain of segments efficiently is critical for performance. ReadOnlySequenceReadBuffer does exactly that, and automatically stitches the bytes together when a read straddles a segment boundary. This matters a great deal in binary processing that has to work with spans directly.

Span<byte> scratch = stackalloc byte[512];
var buffer = new ReadOnlySequenceReadBuffer(sequence, scratch);
try
{
    var value = formatter.Deserialize(ref buffer);
    long consumed = buffer.BytesConsumed;
    return value;
}
finally
{
    buffer.Dispose();
}

CopyTo(Span<byte>) copies the next bytes without consuming them, and a multi-segment implementation copies straight out of its segments without building a contiguous window first. It is the right call for fixed-size payloads such as a byte[] body or a blittable struct, where a contiguous window would only be an intermediate copy.

Building a Serializer

The top-level entry points then choose the buffer for the job and hand it to the formatter. In these method excerpts, GetFormatter<TWriteBuffer, TReadBuffer, T>() stands for your serializer's resolver, returning an IFormatter<TWriteBuffer, TReadBuffer, T>.

public static byte[] Serialize<T>(T value)
{
    Span<byte> scratch = stackalloc byte[256];
    var buffer = new ArrayPoolListWriteBuffer(scratch);
    try
    {
        GetFormatter<ArrayPoolListWriteBuffer, ReadOnlySpanReadBuffer, T>().Serialize(ref buffer, value);
        return buffer.ToArray();
    }
    finally
    {
        buffer.Dispose();
    }
}

public static void Serialize<T>(IBufferWriter<byte> output, T value)
{
    var buffer = new BufferWriterWriteBuffer(output);
    try
    {
        GetFormatter<BufferWriterWriteBuffer, ReadOnlySpanReadBuffer, T>().Serialize(ref buffer, value);
        buffer.Flush();
    }
    finally
    {
        buffer.Dispose();
    }
}

public static T Deserialize<T>(ReadOnlySpan<byte> source)
{
    var buffer = new ReadOnlySpanReadBuffer(source);
    try
    {
        return GetFormatter<ArrayPoolListWriteBuffer, ReadOnlySpanReadBuffer, T>().Deserialize(ref buffer);
    }
    finally
    {
        buffer.Dispose();
    }
}

public static T Deserialize<T>(in ReadOnlySequence<byte> source)
{
    Span<byte> scratch = stackalloc byte[256];
    var buffer = new ReadOnlySequenceReadBuffer(source, scratch);
    try
    {
        return GetFormatter<ArrayPoolListWriteBuffer, ReadOnlySequenceReadBuffer, T>().Deserialize(ref buffer);
    }
    finally
    {
        buffer.Dispose();
    }
}

Keep one owner for each buffer. A serializer entry point normally constructs it, passes it by ref to formatters, and disposes it in finally. A using local cannot be passed by ref (compiler error CS1657), so the entry points below use try / finally. Caller-provided scratch, input memory and underlying writers are borrowed; disposing a buffer releases its own rented storage or commits its staged writes, without disposing those external resources.

Async and Streaming Interfaces

SerializerFoundation provides synchronous interfaces only. Asynchronous operations inside frequently called code degrade performance, and the established approach in such cases is to buffer a reasonable amount of data and then process it synchronously in one go. The core of SerializerFoundation is designed for definitions inside that synchronous processing. For a serializer, memory-conscious asynchronous streaming is only needed when processing a sequence of values, such as an array or JSON Lines. The recommended design is therefore to provide dedicated interfaces for those cases and to await on the outside.

Target Frameworks and the Compatible Tier

The package ships a net9.0 asset with allows ref struct support and netstandard2.0/2.1 assets for older targets. allows ref struct requires C# 13 and the .NET 9 runtime, which is exactly where the net9.0 asset starts, so NET9_0_OR_GREATER is the condition for selecting between the two tiers.

The ref struct buffers exist on every target and can be used directly. Generic serializer code targeting netstandard uses the Compatible* tier, because a ref struct cannot be a type argument without allows ref struct.

The Compatible* structs implement the same interfaces with the same semantics. CompatibleArrayPoolListWriteBuffer starts with pooled storage and takes no scratch span; CompatibleReadOnlySequenceReadBuffer uses a rented temporary array when stitching is necessary. The span-based variants (CompatibleSpanWriteBuffer, CompatibleReadOnlySpanReadBuffer) take a byte* and length instead of a span. Keep that memory valid for the buffer's lifetime, and pin it when it belongs to a managed object.

The netstandard assets cover compatible .NET Framework and engine runtimes such as Unity and Godot. Runtime compatibility and compiler support are separate: older compilers can use the Compatible* structs, while defining the extension-block syntax in this README requires C# 14. The equivalent traditional syntax is public static void WriteInt32<TBuffer>(this ref TBuffer buffer, int value) where TBuffer : struct, IWriteBuffer.

A formatter that multi-targets writes its constraints once with a conditional allows ref struct.

public sealed class PointFormatter<TWriteBuffer, TReadBuffer> : IFormatter<TWriteBuffer, TReadBuffer, Point>
    where TWriteBuffer : struct, IWriteBuffer
#if NET9_0_OR_GREATER
    , allows ref struct
#endif
    where TReadBuffer : struct, IReadBuffer
#if NET9_0_OR_GREATER
    , allows ref struct
#endif
{
    // the body is identical on every target
}

Use the same conditional constraints on IFormatter and on generic helper methods. The serializer's entry points then pick the tier per target. A serializer that loads formatter assemblies built for different targets also needs a resolver strategy for selecting a compatible formatter; that policy belongs to the serializer.

public static byte[] Serialize<T>(T value)
{
#if NET9_0_OR_GREATER
    Span<byte> scratch = stackalloc byte[256];
    var buffer = new ArrayPoolListWriteBuffer(scratch);
    try
    {
        GetFormatter<ArrayPoolListWriteBuffer, ReadOnlySpanReadBuffer, T>().Serialize(ref buffer, value);
        return buffer.ToArray();
    }
    finally
    {
        buffer.Dispose();
    }
#else
    var buffer = new CompatibleArrayPoolListWriteBuffer();
    try
    {
        GetFormatter<CompatibleArrayPoolListWriteBuffer, CompatibleReadOnlySpanReadBuffer, T>().Serialize(ref buffer, value);
        return buffer.ToArray();
    }
    finally
    {
        buffer.Dispose();
    }
#endif
}

public static unsafe T Deserialize<T>(ReadOnlySpan<byte> source)
{
#if NET9_0_OR_GREATER
    var buffer = new ReadOnlySpanReadBuffer(source);
    try
    {
        return GetFormatter<ArrayPoolListWriteBuffer, ReadOnlySpanReadBuffer, T>().Deserialize(ref buffer);
    }
    finally
    {
        buffer.Dispose();
    }
#else
    fixed (byte* pointer = source)
    {
        var buffer = new CompatibleReadOnlySpanReadBuffer(pointer, source.Length);
        try
        {
            return GetFormatter<CompatibleArrayPoolListWriteBuffer, CompatibleReadOnlySpanReadBuffer, T>().Deserialize(ref buffer);
        }
        finally
        {
            buffer.Dispose();
        }
    }
#endif
}

BufferSegments is the same type on every target, so message processors (compressors, encryptors, framers) that consume it multi-target without any #if.

Custom IWriteBuffer / IReadBuffer Implementations

Beyond the built-in IWriteBuffer / IReadBuffer implementations, you can provide your own specialized buffer by implementing the interfaces yourself. Follow the contract of each member below. Implementations must be structs (ref struct allowed) and are single-owner: they are passed by ref and never copied. Dispose releases only what the buffer itself rented or staged, never caller-provided scratch, input memory or the underlying writer.

RequireOverride

When a multi-targeted base class adds a generic buffer method only on its net9.0 target, making that method abstract would break subclasses compiled against its netstandard target: they have no implementation of the new abstract method. A virtual method with a bridge body keeps those subclasses usable, while newly compiled subclasses can override it with a direct implementation.

[RequireOverride] marks such a virtual method as conceptually abstract. The bundled SF003 analyzer requires every non-abstract derived type that can access the method to override it, directly or through a base class. Downlevel compilations never see the method, so they have no override requirement. The following MessageProcessor is an example base class for your serializer.

using System.Buffers;
using SerializerFoundation;
using SerializerFoundation.CodeAnalysis;

public abstract class MessageProcessor
{
    // every target: the interface-shaped entry
    public abstract bool TryEncode(ref BufferSegments message, IBufferWriter<byte> output);

#if NET9_0_OR_GREATER
    // net9.0 and later: writes straight into the target buffer.
    // virtual so netstandard subclasses keep loading; [RequireOverride] so modern subclasses cannot forget it.
    [RequireOverride]
    public virtual bool TryEncode<TWriteBuffer>(ref BufferSegments message, ref TWriteBuffer output)
        where TWriteBuffer : struct, IWriteBuffer, allows ref struct
    {
        // bridge for netstandard subclasses: encode through the interface overload, then copy (one extra copy)
        var staging = new ArrayBufferWriter<byte>();
        if (!TryEncode(ref message, staging)) return false;
        if (staging.WrittenCount > 0)
        {
            staging.WrittenSpan.CopyTo(output.GetSpan(staging.WrittenCount));
            output.Advance(staging.WrittenCount);
        }
        return true;
    }
#endif
}

The attribute is not inherited. An override satisfies the requirement for everything below it, and an intermediate override that should itself be overridden again applies the attribute anew.

Analyzers

The package bundles Roslyn analyzers that check the buffer contract at compile time. All three diagnostics have error severity by default: SF001 catches buffer implementations that cannot satisfy a serializer's struct constraint, SF002 catches common ownership mistakes, and SF003 enforces explicitly required overrides.

SF002 is the one you will meet. Implementing a buffer interface is the non-copyable marker, no attribute needed. The analyzer catches common copy mistakes in serializer code: by-value parameters and extension receivers, in / ref readonly parameters (the callee mutates a defensive copy), local and field initialization from another buffer, boxing, capture in a tuple or array initializer, foreach, pattern matching, with, by-value properties, yielding an existing buffer, and mutation through a readonly reference. It is a guard against common mistakes, not a complete ownership checker: callers still need to keep buffers single-owner and pass them by ref.

void ByValue(ArrayPoolListWriteBuffer buffer) { }    // SF002
void ByReadonlyRef(in ArrayPoolListWriteBuffer buffer) { } // SF002
void ByRef(ref ArrayPoolListWriteBuffer buffer) { }  // OK

var buffer = new ArrayPoolListWriteBuffer(scratch); // OK: constructed in place
var copy = buffer;                                 // SF002: copied by assignment

The analyzers ship inside the SerializerFoundation package under analyzers/dotnet/cs and require a host compatible with Roslyn 4.3.1 or later. Standard NuGet PackageReference integration loads them automatically, including through transitive package references unless analyzer assets are excluded. When importing DLLs manually or through an engine-specific workflow, configure that host to load the analyzer DLL as well.

License

This library is under the MIT License.
