SocketJack 2.0.0

SocketJack

A batteries-included .NET networking stack for object transport, browser-native HTTP/WebSocket apps, WPF control sharing, and local AI model orchestration.

SocketJack handles framing, segmentation, serialization, compression, routing, and protocol detection so the application code can stay boring: Send(myObject) on one side, register a typed callback on the other, and let the transport worry about the bytes.

One library. Many transports. A surprisingly capable local AI control plane.

Targets: SocketJack core: .NET Standard 2.1 | SocketJack.WPF: net10.0-windows7.0

What's New in v2.0.0?

• LmVsProxy Web Console - a full browser workspace for LM Studio-backed chat, sessions, model selection, file uploads, prompt intellisense, service routing, diagnostics, and per-client permissions.
• Remote Admin for WPF hosts - view and control the LmVsProxy GUI from the web console through SocketJack.WPF capture/input providers without moving the real Windows cursor.
• WebAuth and host-local administration - token/basic auth, registration approvals, administrator roles, host-IP admin detection, and CORS-friendly local LLM client APIs.
• Per-client capability gates - enable or disable agent access, internet search, VS Copilot tools, file transfer, SQL admin, FTP, terminal commands, image uploads, and downloads by owner key.
• Session and artifact persistence - SocketJack's embedded data server now backs chat sessions, auth records, usage costs, filesystem access lists, and uploaded/downloaded files.
• Architecture upgrades - MutableTcpServer is now the shared front door for HTTP, WebSocket, SocketJack protocols, SQL admin, FTP configuration, LLM client endpoints, and the web UI.

Features

Supported Transports

TCP

The core transport. TcpClient and TcpServer provide reliable, ordered, stream-oriented communication with automatic message segmentation for arbitrarily large payloads. TLS is supported via SslStream and X509Certificate.

UDP

UdpClient and UdpServer mirror the TCP API but use connectionless datagrams. The same NetworkOptions, serialization, compression, peer-to-peer, and callback systems work identically. Payloads are limited by MaxDatagramSize (default 65,507 bytes).

HTTP

HttpServer and HttpClient layer a familiar HTTP API on top of the TCP transport. Route mapping (Map, Map<T>, MapStream, MapUploadStream), static file serving (MapDirectory), .htaccess security, typed callbacks, chunked transfer-encoding, RTMP ingest, HTTPS/TLS, and automatic redirects are all built in.

WebSocket

WebSocketClient and WebSocketServer implement RFC 6455 while sharing the same serialization, compression, P2P, and callback systems. The server handles the HTTP upgrade handshake automatically and can generate JavaScript class constructors for browser clients.

WPF Live Control Sharing

Requires the SocketJack.WPF NuGet package.

The SocketJack.WPF library lets you share any WPF FrameworkElement over a TcpClient or UdpClient connection. The sharer captures JPEG frames at a configurable frame rate and streams them to a remote peer. The viewer displays those frames in an Image control and automatically forwards mouse input back, so the remote user can interact with the shared element as if it were local.

LmVsProxy – Local AI Model Bridge

LmVsProxy bridges Visual Studio's GitHub Copilot tool-calling interface with locally-hosted language models via LM Studio. Instead of paying per API call to cloud providers, run open-source models (Qwen, Mistral, Phi, and others) on your own hardware and only pay for electricity.

How it works:

1. Visual Studio sends GitHub-format tool requests to the proxy
2. LmVsProxy translates schemas and method calls to OpenAI-compatible format
3. Requests forward to LM Studio's /v1/chat/completions endpoint
4. Responses convert back to VS-compatible SSE format
5. Multi-turn conversations seamlessly relay tool results back to the model

Features:

• Full protocol translation (GitHub format ↔ OpenAI format)
• Built-in browser-based chat web UI via ChatServer property (automatically hosted)
• Streaming and non-streaming request support
• Single-port multiplexing with SocketJack's MutableTcpServer
• Support for any LM Studio-compatible model

Getting Started:

1. Install LM Studio and download your preferred model (Qwen, Mistral, Phi, etc.)
2. Start LM Studio on its default port (e.g., localhost:1234)
3. In your application, create and start the proxy:

var proxy = new LmVsProxy("localhost", 1234, 11434);
proxy.Start();

// Enable the built-in web chat UI (optional)
if (!proxy.ChatServer.IsListening)
{
    proxy.ChatServer.Listen();
}

Console.WriteLine("Proxy running at http://localhost:11434/v1/chat/completions");
Console.WriteLine("Chat web UI available at http://localhost:" + proxy.ChatServerPort);

4. Configure Visual Studio to use the proxy as your Copilot endpoint at http://localhost:11434/v1/chat/completions
5. Open the chat UI in your browser: http://localhost:{chatServerPort} to interact with your local model directly
6. All tool calls from Visual Studio now execute against your local model — no cloud bills, just electricity

Use Cases

• Real-time multiplayer games — low-latency communication with dynamic peer discovery.
• Distributed chat — P2P messaging with metadata-driven room discovery.
• IoT device networks — efficient, secure communication across flexible topologies.
• Remote control & automation — event-driven command/control of remote systems.
• Custom protocols — build domain-specific protocols on top of any transport with full control over serialization and peer management.
• Local AI model serving — run enterprise-grade open-source LLMs (Qwen, Mistral, Phi) via LM Studio on your own hardware with zero cloud costs through LmVsProxy.

Getting Started

Install via NuGet:

Install-Package SocketJack

Examples

TCP — Server & Client

// Create and start a server
var server = new TcpServer(port: 12345);
server.Listen();

// Connect a client
var client = new TcpClient();
await client.Connect("127.0.0.1", 12345);

// Send any serializable object
client.Send(new CustomMessage("Hello!"));

// Handle it with a typed callback
server.RegisterCallback<CustomMessage>((args) =>
{
    Console.WriteLine($"Received: {args.Object.Message}");

    // Echo back to the sender
    args.Connection.Send(new CustomMessage("10-4"));
});

TCP — Default Options

Must be set before creating any Client or Server instance.

NetworkOptions.DefaultOptions.UsePeerToPeer = true;

TCP — Attach Metadata (Server-Side)

// Inside a server callback or ClientConnected handler:
connection.SetMetaData("room", "Lobby1");

UDP — Server & Client

var server = new UdpServer(port: 12345);
server.Listen();

var client = new UdpClient();
await client.Connect("127.0.0.1", 12345);

// Same Send / RegisterCallback pattern as TCP
client.Send(new CustomMessage("Hello via UDP!"));

server.RegisterCallback<CustomMessage>((args) =>
{
    Console.WriteLine($"Received: {args.Object.Message}");
});

UDP — Peer-to-Peer & Broadcasting

// Send to a specific peer (relayed through the server)
client.Send(remotePeer, new CustomMessage("P2P over UDP"));

// Broadcast to all peers
client.SendPeerBroadcast(new CustomMessage("Hello everyone!"));

// Server broadcasts to all connected clients
server.SendBroadcast(new CustomMessage("Server announcement"));

// Server sends to a specific client by Identifier
server.Send(clientIdentifier, new CustomMessage("Direct message"));

UDP — Options

var options = new NetworkOptions();
options.MaxDatagramSize      = 1400;     // Safe MTU (default 65,507)
options.ClientTimeoutSeconds = 60;       // Default 30
options.UdpReceiveBufferSize = 131072;   // Default 65,535
options.EnableBroadcast      = true;     // Default false
options.ClientTimeoutCheckIntervalMs = 10000; // Default 5,000

var server = new UdpServer(options, port: 12345);
var client = new UdpClient(options);

HTTP — Server

var server = new HttpServer(port: 8080);
server.Listen();

// Custom index page
server.IndexPageHtml = "<html><body><h1>Welcome!</h1></body></html>";

// Route mapping
server.Map("GET", "/hello", (connection, request, ct) =>
{
    return "Hello, World!";
});

server.Map("POST", "/echo", (connection, request, ct) =>
{
    return new EchoResponse(request.Body);
});

server.RemoveRoute("GET", "/hello");

// Fallback for unmatched routes
server.OnHttpRequest += (connection, ref context, ct) =>
{
    context.Response.Body = "Custom response";
    context.Response.ContentType = "text/plain";
    context.StatusCode = "200 OK";
};

HTTP — Typed Routes

Automatically deserialize the request body to a typed parameter:

server.Map<LoginRequest>("POST", "/login", (connection, body, request, ct) =>
{
    // body is already deserialized to LoginRequest
    return new LoginResponse(body.Username);
});

HTTP — Static File Serving

Map a local directory to a URL prefix to serve static files with automatic MIME type detection:

// Serve files from C:\wwwroot at /static
server.MapDirectory("/static", @"C:\wwwroot");

// Enable auto-generated directory listings for directories without index.html
server.AllowDirectoryListing = true;

server.RemoveDirectoryMapping("/static");

HTTP — .htaccess Security

Use the HtAccessBuilder fluent API to configure per-directory access rules:

server.MapDirectory("/secure", @"C:\data", htaccess =>
{
    htaccess
        .DenyDirectoryListing()
        .AllowFrom("192.168.1.0/24")
        .DenyFiles("*.log", "*.bak")
        .RequireBasicAuth("Admin Area", "admin:secret")
        .AddHeader("X-Frame-Options", "DENY");
});

HTTP — Streaming Routes

Keep a connection open for server-sent events or long-lived responses:

// Chunked streaming response
server.MapStream("GET", "/events", async (connection, request, chunkedStream, ct) =>
{
    for (int i = 0; i < 10; i++)
    {
        chunkedStream.WriteLine("event: " + i);
        await Task.Delay(1000, ct);
    }
});

// Upload streaming (e.g., continuous video ingest)
server.MapUploadStream("POST", "/upload", (connection, request, uploadStream, ct) =>
{
    byte[] chunk;
    while ((chunk = uploadStream.ReadAsync(ct).GetAwaiter().GetResult()) != null)
    {
        // Process each incoming data chunk
    }
});

HTTP — RTMP Ingest

Accept RTMP publish connections (e.g., from OBS) directly on the HTTP server port:

server.MapRtmpPublish("live", async (connection, app, streamKey, uploadStream, ct) =>
{
    byte[] chunk;
    while ((chunk = await uploadStream.ReadAsync(ct)) != null)
    {
        // Process RTMP media chunks (prefixed with type byte: 8=audio, 9=video)
    }
});

HTTP — Client

using var client = new HttpClient();

// GET
HttpResponse response = await client.GetAsync("http://localhost:8080/hello");
Console.WriteLine(response.Body);

// POST
byte[] body = Encoding.UTF8.GetBytes("{\"message\":\"hi\"}");
HttpResponse postResp = await client.PostAsync(
    "http://localhost:8080/echo",
    "application/json",
    body);

// Full control
HttpResponse resp = await client.SendAsync(
    "PUT",
    "https://example.com/api/resource",
    new Dictionary<string, string> { ["Authorization"] = "Bearer token" },
    body);

// Streaming
using var fileStream = File.Create("download.bin");
await client.GetAsync("http://example.com/largefile", responseStream: fileStream);

HTTP — Client Options

var client = new HttpClient();
client.Timeout    = TimeSpan.FromSeconds(60); // Default 30
client.MaxRedirects = 10;                     // Default 5
client.DefaultHeaders["Accept"] = "application/json";

HTTP — Live Streaming with BroadcastServer

BroadcastServer turns any HttpServer into a live video relay. Point OBS (or any RTMP encoder) at the server and viewers can watch in a browser or VLC — no additional dependencies required.

using SocketJack.Net;

// Create the HTTP server
var server = new HttpServer(port: 8080);

// Attach BroadcastServer and register the default streaming routes:
//   GET  /stream       — HTML player page (mpegts.js)
//   GET  /stream/data  — raw FLV relay for the player / VLC
//   PUT  /Upload       — OBS Custom Output (HTTP)
//   POST /Upload       — OBS Custom Output (HTTP)
//   RTMP rtmp://host:port/live  — OBS RTMP publish
var broadcast = new BroadcastServer(server);
broadcast.Register();

// Start listening
server.Listen();

// The stream key is auto-generated. In OBS set:
//   Server:     rtmp://localhost:8080/live
//   Stream Key: <broadcast.StreamKey>
Console.WriteLine("Stream Key: " + broadcast.StreamKey);

// Viewers open http://localhost:8080/stream in a browser,
// or play http://localhost:8080/stream/data directly in VLC.

// Optional: poll stats once per second
while (true) {
    var stats = broadcast.UpdateStats();
    if (stats.Active) {
        Console.WriteLine(
            stats.BitrateKbps.ToString("N0") + " kbps | " +
            stats.VideoFrames + " video | " +
            stats.AudioFrames + " audio | " +
            BroadcastServer.FormatBytes(stats.TotalBytes));
    }
    Thread.Sleep(1000);
}

WebSocket — Server & Client

var server = new WebSocketServer(port: 9000);
server.Listen();

// Optional TLS
server.SslCertificate = new X509Certificate2("cert.pfx", "password");
server.Options.UseSsl = true;
server.Listen();

// Connect a client
var client = new WebSocketClient();
await client.Connect("127.0.0.1", 9000);

// Or with a full URI
await client.ConnectAsync(new Uri("ws://127.0.0.1:9000/path"));

WebSocket — Send, Receive & Broadcast

client.Send(new CustomMessage("Hello via WebSocket!"));

server.RegisterCallback<CustomMessage>((args) =>
{
    Console.WriteLine($"Received: {args.Object.Message}");
});

server.Send(clientConnection, new CustomMessage("Reply"));
server.SendBroadcast(new CustomMessage("Announcement"));

WebSocket — Peer-to-Peer

var options = new NetworkOptions();
options.UsePeerToPeer = true;

var client = new WebSocketClient(options);
await client.Connect("127.0.0.1", 9000);

client.Send(remotePeer, new CustomMessage("P2P over WebSocket"));
client.SendBroadcast(new CustomMessage("Hello everyone!"));

WebSocket — Events

// Server
server.ClientConnected  += (e) => Console.WriteLine($"Client connected: {e.Connection.Identity.ID}");
server.ClientDisconnected += (e) => Console.WriteLine($"Client disconnected: {e.Connection.Identity.ID}");
server.OnReceive += (ref e) => Console.WriteLine($"Received: {e.Obj}");

// Client
client.OnConnected    += (e) => Console.WriteLine("Connected!");
client.OnDisconnected += (e) => Console.WriteLine("Disconnected.");
client.PeerConnected    += (sender, peer) => Console.WriteLine($"Peer joined: {peer.ID}");
client.PeerDisconnected += (sender, peer) => Console.WriteLine($"Peer left: {peer.ID}");

MutableTcpServer — Multi-Protocol on a Single Port

MutableTcpServer extends HttpServer and auto-detects the protocol for each incoming connection. HTTP, SocketJack, WebSocket, and RTMP connections can all share a single listening port. Custom protocols are supported via the IProtocolHandler interface.

var server = new MutableTcpServer(port: 9000);

// HTTP routes are configured through the Http property
server.Http.Map("GET", "/api/status", (connection, request, ct) =>
{
    return "{ \"status\": \"ok\" }";
});

// Serve static files through the HTTP handler
server.Http.MapDirectory("/www", @"C:\wwwroot");

// Serve an individual file at a specific URL
server.Http.MapFile("/js/app.js", @"C:\Pages\app.js");

// SocketJack clients connect to the same port and are routed automatically
server.SocketJackClientConnected += (connection) =>
{
    Console.WriteLine($"SocketJack client connected: {connection.ID}");
};

// WebSocket clients are detected via the HTTP Upgrade handshake
server.WebSocketClientConnected += (connection) =>
{
    Console.WriteLine($"WebSocket client connected: {connection.ID}");
};

// Normal SocketJack callbacks work for both SocketJack and WebSocket clients
server.RegisterCallback<CustomMessage>((args) =>
{
    Console.WriteLine($"Received: {args.Object.Message}");
});

server.Listen();

// SocketJack clients connect normally:
var client = new TcpClient();
await client.Connect("127.0.0.1", 9000);
client.Send(new CustomMessage("Hello!"));

// WebSocket clients connect to the same port:
var wsClient = new WebSocketClient();
await wsClient.ConnectAsync(new Uri("ws://127.0.0.1:9000"));
wsClient.Send(new CustomMessage("Hello from browser!"));

// HTTP clients hit the same port:
// curl http://localhost:9000/api/status

MutableTcpServer — Custom Protocol Handler

Implement IProtocolHandler to add support for any binary protocol:

public class MyProtocolHandler : IProtocolHandler
{
    public string Name => "MyProtocol";

    public bool CanHandle(byte[] data)
    {
        // Detect your protocol by inspecting the first bytes
        return data.Length >= 4 && data[0] == 0xAB;
    }

    public void ProcessReceive(MutableTcpServer server, NetworkConnection connection, ref IReceivedEventArgs e)
    {
        // Handle incoming data for this protocol
    }

    public void OnDisconnected(MutableTcpServer server, NetworkConnection connection)
    {
        // Clean up when a connection using this protocol disconnects
    }
}

server.RegisterProtocol(new MyProtocolHandler());

WPF — Sharing a Control

These examples require the SocketJack.WPF NuGet package, not SocketJack.

using SocketJack.Net;
using SocketJack.Net.P2P;
using SocketJack.WPF;

// Share any FrameworkElement (Canvas, Grid, Border, Window, etc.)
IDisposable shareHandle = myCanvas.Share(client, peer, fps: 10);

// Stop sharing
shareHandle.Dispose();

WPF — Viewing a Shared Control

using System.Windows.Controls;
using SocketJack.Net;
using SocketJack.WPF;

var viewer = client.ViewShare(sharedImage, sharerPeer);

// Dispose when finished
viewer.Dispose();

WPF — Full Example

XAML (both instances):

<Image x:Name="SharedImage" Stretch="Uniform" />

Sharer (Instance A):

Identifier remotePeer = client.Peers.FirstNotMe();
IDisposable shareHandle = GameCanvas.Share(client, remotePeer, fps: 10);

Viewer (Instance B):

Identifier remotePeer = client.Peers.FirstNotMe();
var viewer = client.ViewShare(SharedImage, remotePeer);

Documentation

• API Reference
• Examples & Tutorials

License

SocketJack is open source and licensed under the MIT License.

Contributing

Contributions, bug reports, and feature requests are welcome! See CONTRIBUTING.md for details.

SocketJack — Fast, flexible, and modern networking for .NET.

NuGet · GitHub · Examples
