WorkflowForge.Extensions.Persistence 2.1.2

WorkflowForge.Extensions.Persistence

Save and resume workflows through IWorkflowPersistenceProvider: you choose SQL, Cosmos, Redis, files, or anything else. The package ships abstractions and middleware only, no built-in database driver.

Install

dotnet add package WorkflowForge.Extensions.Persistence

Targets .NET Standard 2.0 or later.

Quick Start

1. Implement the provider interface

using WorkflowForge.Extensions.Persistence.Abstractions;

public class SqlPersistenceProvider : IWorkflowPersistenceProvider
{
    private readonly string _connectionString;

    public SqlPersistenceProvider(string connectionString)
    {
        _connectionString = connectionString;
    }

    public async Task SaveAsync(
        WorkflowExecutionSnapshot snapshot,
        CancellationToken cancellationToken = default)
    {
        // Serialize and store the snapshot in your database
    }

    public async Task<WorkflowExecutionSnapshot?> TryLoadAsync(
        Guid foundryExecutionId,
        Guid workflowId,
        CancellationToken cancellationToken = default)
    {
        // Load the snapshot from your database; return null if not found
    }

    public async Task DeleteAsync(
        Guid foundryExecutionId,
        Guid workflowId,
        CancellationToken cancellationToken = default)
    {
        // Remove the snapshot from your database
    }
}

2. Enable persistence on the foundry

using WorkflowForge;
using WorkflowForge.Extensions.Persistence;

IWorkflowPersistenceProvider provider = new SqlPersistenceProvider("Server=...");

var smith = WorkflowForge.CreateSmith();
var workflow = WorkflowForge.CreateWorkflow("MyWorkflow")
    .AddOperation(/* your operations */)
    .Build();

using var foundry = WorkflowForge.CreateFoundry("OrderService");
foundry.UsePersistence(provider);

await smith.ForgeAsync(workflow, foundry);

3. Enable with stable keys (for cross-process resume)

using WorkflowForge.Extensions.Persistence;

var options = new PersistenceOptions
{
    InstanceId = "order-service-instance",
    WorkflowKey = "process-order-v1"
};

foundry.UsePersistence(provider, options);

When InstanceId and WorkflowKey are set, deterministic GUIDs are derived from those strings so the same workflow can be found across process restarts.

Key points

• No default provider on purpose: stay storage-neutral (you implement IWorkflowPersistenceProvider). Beyond core, depends only on Microsoft.Extensions.* for options/DI.
• Checkpoints after each successful operation; resume skips completed steps via NextOperationIndex.
• Optional stable keys tie executions to logical instances across restarts.
• Middleware is written to be safe under concurrent workflows.

How it works

The PersistenceMiddleware wraps each operation in the pipeline:

1. Before each operation: Calls TryLoadAsync to check for a saved snapshot
2. If snapshot exists and operation already completed: Restores properties, skips the operation
3. If not resumed: Calls the next middleware/operation normally
4. After success: Builds a WorkflowExecutionSnapshot with NextOperationIndex incremented and calls SaveAsync
5. When all operations complete: Calls DeleteAsync to clean up

Snapshot structure

public sealed class WorkflowExecutionSnapshot
{
    public Guid FoundryExecutionId { get; set; }
    public Guid WorkflowId { get; set; }
    public string WorkflowName { get; set; }
    public int NextOperationIndex { get; set; }
    public Dictionary<string, object?> Properties { get; set; }
}

• NextOperationIndex: -1 means not started; N means operation at index N is next
• Properties: Arbitrary key-value state from foundry.Properties; store only what you need for resumption

Configuration

Via appsettings.json

{
  "WorkflowForge": {
    "Extensions": {
      "Persistence": {
        "Enabled": true,
        "PersistOnOperationComplete": true,
        "PersistOnWorkflowComplete": true,
        "PersistOnFailure": true,
        "MaxVersions": 10,
        "InstanceId": "my-instance-id",
        "WorkflowKey": "my-workflow-key"
      }
    }
  }
}

Via code

using WorkflowForge.Extensions.Persistence;

var options = new PersistenceOptions
{
    Enabled = true,
    PersistOnOperationComplete = true,
    PersistOnWorkflowComplete = true,
    PersistOnFailure = true,
    MaxVersions = 10,
    InstanceId = "my-instance-id",
    WorkflowKey = "my-workflow-key"
};

foundry.UsePersistence(provider, options);

Via dependency injection

using Microsoft.Extensions.Configuration;
using Microsoft.Extensions.DependencyInjection;
using WorkflowForge.Extensions.Persistence;

services.AddPersistenceConfiguration(configuration);
var options = serviceProvider.GetRequiredService<IOptions<PersistenceOptions>>().Value;

Persistence configuration

Provider interface

public interface IWorkflowPersistenceProvider
{
    Task SaveAsync(WorkflowExecutionSnapshot snapshot, CancellationToken cancellationToken = default);

    Task<WorkflowExecutionSnapshot?> TryLoadAsync(Guid foundryExecutionId, Guid workflowId,
        CancellationToken cancellationToken = default);

    Task DeleteAsync(Guid foundryExecutionId, Guid workflowId,
        CancellationToken cancellationToken = default);
}
